the number of servers budgeted using faceplate, power calculator, and Dynamic Power Capping
represents the capital cost recovery potential of the Dynamic Power Capping solution. The
SpecJBB benchmark was used to generate load for the Dynamic Power Capping portion of the
TCO analysis.
4
Data for the analysis was gathered in the following fashion:
1. Document Faceplate Values: The maximum power in Watts (faceplate power) was
taken from the QuickSpecs for each of the server models discussed above. Faceplate
value represents the maximum possible input power required for a given server model.
The value describes an extreme condition where the server is configured with a maximum
number of CPUs, memory, drives, and internal peripherals operating at maximum
performance on a continuous basis.
2. Generate Power Calculator/BladeSystem Sizer Estimates: HP Power
Calculator and HP BladeSystem Sizer allow customers to size server power requirements
more accurately based on the configuration of the server and the anticipated intensity of
the server workload as measured by CPU utilization. For the purposes of this paper, the
default settings of 100% CPU utilization have been used. The server configurations tested
represent those typically found in enterprise computing environments.
3. Measure Peak Power Consumption and Cap: Server power consumption was
measured at 100% CPU utilization running the SPECjbb benchmark with the same
configuration used for the power calculator estimate. A Dynamic Power Cap was then
applied to the test servers and test enclosures to verify that applying the cap at the 100%
SPECjbb load did not impact performance.

The results of the data-gathering exercise appear in the following section.

Case 1. HP ProLiant DL380 G5 Server

Comparisons of faceplate, power calculator, and SPECjbb benchmark with Dynamic Power
Capping for the DL380 G5 are listed below (Table 1). By leveraging Dynamic Power Capping at
100% load, test results showed that, for a typical DL380 G5 configuration, users can potentially
increase the number of servers deployed per circuit from 7servers, using faceplate, to 23 servers,
using Dynamic Power Capping at max power, an increase of nearly 230%. Using the Uptime
Institute estimate of $25,000 per kW of redundant power infrastructure, Dynamic Power Capping
causes per server power infrastructure cost to drop from $30,714 per server to $9,348 per
server, a decrease of 69%.
Table 1. HP ProLiant DL 380 G5 Power and Costs Projections
Server Power
Maximum Number of
Servers in Circuit
Power Provisioning
Cost Per Server
@ $25k per kW
HP Note
Tests assume a 30AMP, 208V 3-phase circuit for a usable
total of 8.6kW of capacity.
4 The Standard Performance Evaluation Corporation develops SpecJBB. More information can be found at the following URL:
http://www.spec.org/.
Faceplate
1,193 W
7
$29,825
Power Calculator
435 W
19
$11,316
Load Testing and
Dynamic Power Capping
368 W
23
$9,348
