ISS Technology Update
</ICMB>
<ICMB ADDR="AA5E" MFG="232" PROD_ID="0x0002"
<LEFT ADDR="CEA" SER="D230JTK7D008"
<RIGHT ADDR="54BC" SER="D303JTK5D103"
</ICMB>
<ICMB ADDR="CCE1" MFG="232" PROD_ID="0x0007" SER="SERIAL0001"
<LEFT ADDR="54BC" SER="D303JTK5D103"
<RIGHT ADDR="A6BB" SER="SERIAL0004" UUID="07SERIAL0004"
</ICMB>
<ICMB ADDR="4CBB" MFG="232" PROD_ID="0x0003"
<LEFT />
<RIGHT ADDR="CEA" SER="D230JTK7D008"
</ICMB>
</RK_TPLGY>
</RIMP>
How to make a request for power enclosure information
Using the ICMB address information collected from the first request output, you c
executing a second request. A template for the second request is as follows:
http://<ilo_ip_address_or_dns_name>/xmldata?item=icmb&addr=<addr>
Where <addr> is the ICMB address of the power enclosure to be viewed.
Th e data returned contains information about the current generated by each supply
yellow highlight in Figure 2-2). This value can be used to calculate power produced. The power supplies are 51.4 volt.
Figure 2-2 is an example of the second request output. This request examines the power enclosures for only the first pow
supply identified in Figure 2-1.
Figure 2-2. Sample output from the second request
<?xml version="1.0" ?>
<RIMP>
<Enclosure>
<ENCL>D303JTK5D103</ENCL>
<ICMB_ADDR>54BC</ICMB_ADDR>
<ENCL_SN>D303JTK5D103</ENCL_SN>
<UUID>D303JTK5D103</UUID>
<FWRI>2.30</FWRI>
<HWRI>5</HWRI>
<MAX_NUMBER_SLOTS_X>6</MAX_NUMBER_SLOTS_X>
<MAX_NUMBER_SLOTS_Y>1</MAX_NUMBER_SLOTS_Y>
<pwrZone>4</pwrZone>
<uidStatus>On</uidStatus>
<Temperature>33</Temperature>
<TemperatureA>31</TemperatureA>
<TemperatureB>30</TemperatureB>
<RedundancyBits>0000</RedundancyBits>
<LoadBalWire>Not
<PowerComponents>
<PowerComponent>
<Location>1</Location>
<FWRI>1.70</FWRI>
<acInput>Good</acInput>
<Current>14.973</Current>
<MaxCurrent>57.000</MaxCurrent>
<InputTemp>26</InputTemp>
<InputTempTrip>35</InputTempTrip>
Present</LoadBalWire>
SER="D242JTK7D021">
/>
/>
/>
/>
SER="D232KJP3D008">
/>
Volume 6, Number 7
UUID="07SERIAL0001">
an gather power enclosure information by
in the <powerComponent> tag (see the
er
