ISS Technology Update
How to make a request for power supply information
To return topology information about the respective enclosure where iLO is located:
1. Execute the first request:
http://<ilo_ip_address_or_dns_name>/xmldata?item=all
2. Once the request completes, examine the output to identify the power supplies in the topology:
Look for a PROD_ID of 0x0003 or 0x0005 in the output (see the yellow highlight in Figure 2-1).
•
• Use the ICMB address located next to the PROD_ID as an input into the second request template (see the "How to make
a request for power enclosure information" section).
Figure 2-1. Sample output from the first request
<?xml version="1.0" ?>
<RIMP>
<HSI>
<SPN>ProLiant BL35p
<SBSN>M00SNC2146</SBSN>
<UUID />
</HSI>
<MP>
<ST>1</ST>
<PN>Integrated Lights-Out
<FWRI>1.91</FWRI>
<BBLK>3; Oct 2 2006</BBLK>
<HWRI>ASIC: 2</HWRI>
<SN>ILOM00SNC2146</SN>
<UUID>ILO</UUID>
</MP>
<INFRA>
<RACK>TestMyRack</RACK>
<ENCL>CPQEnclosure222</ENCL>
<ICMB_ADDR>A6BB</ICMB_ADDR>
<ENCL_SN>SERIAL0004</ENCL_SN>
<UUID>07SERIAL0004</UUID>
<MAX_NUMBER_SLOTS_X>8</MAX_NUMBER_SLOTS_X>
<MAX_NUMBER_SLOTS_Y>2</MAX_NUMBER_SLOTS_Y>
<BLADE CNT="1">
<SLOT>2</SLOT>
<NUM_SLOTS_X>1</NUM_SLOTS_X>
<NUM_SLOTS_Y>1</NUM_SLOTS_Y>
<HMM>119</HMM>
<WMM>43</WMM>
<DMM>477</DMM>
<BSN>M00SNC2146</BSN>
<UUID />
</BLADE>
</INFRA>
<RK_TPLGY CNT="6">
<RUID>D232KJP3D008</RUID>
<ICMB ADDR="A6BB" MFG="232" PROD_ID="0x0007" SER="SERIAL0004"
<LEFT ADDR="CCE1" SER="SERIAL0001" UUID="07SERIAL0001"
<RIGHT />
</ICMB>
<ICMB ADDR="54BC" MFG="232" PROD_ID="0x0003"
<LEFT ADDR="AA5E" SER="D242JTK7D021"
<RIGHT ADDR="CCE1" SER="SERIAL0001" UUID="07SERIAL0001"
</ICMB>
<ICMB ADDR="CEA" MFG="232" PROD_ID="0x0002"
<LEFT ADDR="4CBB" SER="D232KJP3D008"
<RIGHT ADDR="AA5E" SER="D242JTK7D021"
G1</SPN>
(iLO)</PN>
/>
/>
/>
UUID="07SERIAL0004">
/>
SER="D303JTK5D103">
/>
SER="D230JTK7D008">
Volume 6, Number 7
5
