Summary of Contents for EAST OAK APH22001
- Page 1 3000W Arch Design Electric Patio Heater Owner’s Manual APH22001...
- Page 3 eastoak.com Question? Comments? Reach out to us to get expert support! support@eastoak.com eastoak.com 1-833-EAST-OAK (USA) (1-833-327-8625) Follow eastoakliving on Claim 3-year warranty at eastoak.com/warranty EASTOAK.COM 3000W ARCH DESIGN ELECTRIC HEATER...
-
Page 4: Important Caution
IMPORTANT CAUTION Please verify all parts and components present and check for any damaged pieces before assembly. If you have any damaged or missing parts, please contact customer service at support@eastoak.com. • Some parts may contain sharp edges and may cause injury or property damage. - Page 5 It can be adjusted by remote control. It can use in open bars, courtyards, plazas, and stations. Welcome warmth and the perfect amount of heat into your life now with East Oak’s Infrared Electric Heater. EASTOAK.COM 3000W ARCH DESIGN ELECTRIC HEATER...
-
Page 6: Safety Guide
SAFETY GUIDE When using any electrical appliance, including this infrared heater, basic safety precautions must be followed to reduce the risk of fire, shock, or injury. Please read all instructions before using this appliance: • This heater becomes extremely hot when in use. To minimize risk of burns or injury, do not touch any part of the heater when in use. -
Page 7: Care And Maintenance
• All parts of this heater may become extremely hot when in use. Do not touch the appliance and ensure there is no combustible material around the product. Misuse may result in fire, shock, damage, or injury. In case of an emergency, such as shock or fire, turn off the heater and •... -
Page 8: Function Instruction
SAVE THESE INSTRUCTIONS FUNCTION INSTRUCTION 1-833-327-8625 SUPPORT@EASTOAK.COM... -
Page 9: Parts List
PARTS LIST REMOTE CONTROL GUIDE Remote control distance works up to 9.8 - 16.4 in (3-5m). For optimal usage, align the remote to the receiver as illustrated here. 9.8 - 16.4 in (3-5m) Max. remote distance: 16.4 IN (5M) NOTICE •... - Page 10 OPERATION INSTRUCTION The heater must be installed appropriately before it is used. Open the outer carton, and remove all the packing materials(including heating lamp shaking protection packing). Inspect all components, including the main unit, supply cord, and plugs, for any signs of damage. Take off all screws. Take out the heating mold, heater stand, base, screws and assembling tools.
- Page 11 Connect the whole poles to the round base with 4pcs M8x30 screws. Screw 4 cap nuts onto the exposed screws. Connect the heating mold to the stand with M8x50 and 2pcs M8x10 screws. Connect the easy-fitting plug devices between the heating mold and the stand, and tighten them.
- Page 12 Tips for more stability: The chassis can be fixed on the ground through supporting expansion screws. 1-833-327-8625 SUPPORT@EASTOAK.COM...
- Page 13 • Don’t move or cover the heater while it is working. THIS IS NOT A TOY, DO NOT CLIMB. • • Plug in power, and turn on the heater to check if the heater can work well. • Pay attention to the mounting place and all mounting material (dowels, screws).
-
Page 14: Grounding Instructions
WARRANTY GUARANTEED 3-YEAR WARRANTY Thank you for choosing East Oak. This product is covered by our company warranty for up to 3 years from its original purchase date. CLAIM WARRANTY To claim your product’s warranty, register your new product on our website at www.eastoak.com/warranty. - Page 16 support@eastoak.com eastoak.com 1-833-EAST-OAK (USA)
