65" Floor
Standing Digital
Signage with
Android 11 OS,
Non-Touch
U S E R M A N U A L
SKU: DF065NLB, DF065NLBS
V1.3
FCC ID: 2ASCB- DF065NLB
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Any changes/modifications to this equipment not approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Displays2go DF065NLBS
Summary of Contents for Displays2go DF065NLBS
- Page 1 Android 11 OS, Non-Touch U S E R M A N U A L SKU: DF065NLB, DF065NLBS V1.3 FCC ID: 2ASCB- DF065NLB This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 2 Thank you for purchasing this product from Displays2go. It’s our mission to help you connect with the world and build your brand with products that are personalized to your needs. Your product has been manufactured with great care using only the finest quality materials and expert workmanship.
- Page 3 TA B L E O F C O N T E N TS BEFORE USE Safety and Warnings Packing List Assembly OPERATION Remote Control Interface Diagram Power On/Off HDMI Connection Settings Android 1 1 Quick Start Guide DIVIEX Add Media to USB DiViEX App Settings REFERENCE Technical Specifications...
- Page 4 B E F O R E U S E Safety Warnings and Precautions Thank you for purchasing the high-performance multi-functional LED backlight Digital Signage from Displays2Go. We have considered the factors to ensure personal safety in product design and have tested rigorously at the factory.
- Page 5 WARNING • Cut off the power supply before connecting or disconnecting any cables. • Do not place the Digital Signage on any instable positions, or else it may be damaged or cause fire. • Do not place the Digital Signage in the positions such as: •...
- Page 6 Towel and Glove Cross head pad screw M6*12 (16) Base screw package: L-Shaped Wrench (1) Hex Screws M10*30 (12) Shim M10 (12) If you have any questions regarding our products, please visit us at www.displays2go.com or contact Displays2go customer service at 844-221-3388.
- Page 7 Assembly NOTE: Two people required for safe assembly of product. U N PAC K I N G Open the top cover. Remove base from package Have 2 people carefully remove unit from the package. and carefully set aside. Set it down on the shipping box to avoid scratches. ASS E M B L I N G U N I T Flip base over.
- Page 8 O P E R AT I O N Remote Control Power (No Function) Mute To control the unit, aim the remote control at the unit’s Volume Down/Up receiver, located at the right Navigation Arrows corner below the screen. Select For best performance, avoid exposing the receiver window to direct sunlight or placing objects Home...
- Page 9 Interface Diagram USB Interface (3) Ethernet (RJ45) Port HDMI IN Power Port I/O Switch Power On/Off CAUTION: Disconnect the power plug before assembling or disassembling the unit! NOTE: For the safety of your product, we recommend use of a surge protector when connecting to power. •...
- Page 10 Settings Once turned on, the unit automatically displays the home screen, which includes the navigation bar and the App Drawer. NOTE: The Navigation bar can be minimized. To restore the Display navigation bar, go into Display settings and enable Navigation. App Drawer Background Applications Back...
- Page 11 Our DiViEX Slideshow App comes pre-installed on this digital product to provide convenience for your business content management. Easily upload your videos and images to a USB and insert into the unit. Then, open the app to launch a slideshow or adjust picture settings, add filters and stickers, queue music and more! ADD MEDIA TO USB 1.
- Page 12 PLAYLIST SETTINGS Edit the overall playlist settings in the Settings tab. Once settings are adjusted, click PLAY or adjust further in the Edit or Music tab. Enable or disable automatic settings. A. AUTOMATIC SETTINGS Auto-Boot: Automatically launch DiViEX when unit is powered on Auto-Play: Automatically play slideshow when DiViEX opens B.
- Page 13 EDIT Tweak each photo individually in the Edit tab. A. PHOTOS Images/Video thumbnails in sequential order. Drag to rearrange. B. EDIT TOOLS Crop, Add Text, Add Filter, Add Sticker, Add Frame This white bar shows tool options for each of the Edit tools. Choose aspect ratios C.
- Page 14 R E F E R E N C E Technical Specifications LCD Size 65” Light Source LED backlight Resolution 3840*2160 (pixels) Brightness 500cd/m Contrast 1200: 1 Response 10ms PANEL Pixel Pitch 0.63 (H) * 0.63 (V) mm Refresh Rate 60Hz Viewing Angle 178°...
- Page 15 Ethernet (RJ45) HDMI IN Headset INTERFACES Wi-Fi Net Weight 191.8 lbs (87kg) Gross Weight 231.5 lbs (105kg) Unit Dimensions 37.4”x 4.3”x 66.5” (950*1 10*1690mm) STRUCTURE Package Dimensions ≈ 70” x 10.6” x 41.3” (≈1790*270*1050mm) Shell Material Aluminum profile/sheet metal Shell Color Black/White LANGUAGE English/Simplified Chinese...
- Page 16 Troubleshooting Guide ISSUE PROBABLE CAUSE SOLUTION Press Power button on the remote to see whether the device has Device is not on been turned on. Check power connection. SCREEN IS BLACK, Open the rear door to check whether the indicator light on Power source or Android 12/24V power supply is on.
- Page 17 Ethernet not enabled in Open Settings, then open Network and Internet. Enable ethernet. system settings. NO INTERNET – Ethernet cable is dead. Replace Ethernet cable. WIRE CONNECTION Ethernet port of Android Replace Android board. board is not working Check whether the Router is connected and has 2.4G. Router is not working or 02.
- Page 18 Do not attempt to replace or repair circuitry yourself. Contact customer service to schedule a professional maintenance appointment. If all the potential solutions have been tested for a particular issue and problems have not been resolved, contact a customer service representative for guidance. 844-221-3388 info@displays2go.com...
- Page 19 Cleaning and Maintenance • Avoid strong vibration or impact on the product. • Keep the product dry to avoid possible damage by moisture. • Don't place the product under direct sunlight which may shorten the service life of the screen. •...
- Page 20 FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
