VelectriX SUV Instruction Manual

250 watt, 500 watt
Hide thumbs

Advertisement

Table of Contents

VelectriX Instruction Manual
• SUV 250 Watt
• SUV+ 500 Watt

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUV and is the answer not in the manual?

Questions and answers

Related Manuals for VelectriX SUV

Summary of Contents for VelectriX SUV

  • Page 1 VelectriX Instruction Manual • SUV 250 Watt • SUV+ 500 Watt...
  • Page 2 Contents Safe Riding Recommendations Page 2 Pre-Ride Checklist Page 3 Display and Controls Pages 4-12 Battery Instructions Pages 13-18 Maintenance Page 19 Warranty Pages 20-22 Model Specification Page 23 Page 1...

  • Page 3: Safe Riding Recommendations

    Safe Riding Recommendations Please ensure you are familiar with and follow all traffic laws and regulations for your state. Please remember you may need to review these when travelling interstate. Always wear a helmet when riding your bike. Don’t lend your bike to anyone who is unfamiliar with it. As with all bikes it is important that you stay within safe limits and speeds.

  • Page 4: Pre-Ride Checklist

    Pre-Ride Checklist Check over the bike for any loose nuts, bolts, or fixings. Check the tyre pressure. Please always refer to the tyre manufactures suggested levels on the side of the tyre. Check the tyres for any visible damage, wear and tear or bald spots.

  • Page 5: Lcd Display And Controls

    LCD Display and Controls The Bafang LCD display model DP C080.C is mounted on the left side of the handlebar. Interface Single mileage "TRIP" and residual mileage "RANGE" is shown. Gear represents the current power assist mode selected, shown as 0-E-T-S-S+-B.
  • Page 6 The headlight symbol appears when the headlight is turned on, and disappears when the headlight is turned off. The maintenance symbol appears when the riding mileage reaches 5000km. The battery charge amount will be shown as a graphic & as a percentage.
  • Page 7 Walk Assist To activate the walk assist mode (6kph), press the “–“button to level 0, and then press the “–“ button again, and “person on a bike” symbol will appear and the bike will move forward to maximum speed of 6kph. (this is not a riding mode).
  • Page 8 Riding Data To view riding data, press the power button and press to scroll between 3 screens, that will show data including Speed, Trip, Odometer (odo), Max Speed, Average Speed, Cadence, Calories, Time and Watts Information & Settings Press and hold the "+" and "-" buttons simultaneously to enter "Settings". Then press "+"...
  • Page 9 Page 8...
  • Page 10 HMI Setting Screen Select Metric/Imperial When in the HMI Setting Screen, press "+" or "-" to select "Unit", then the "Power button" to enter the setting and press "+" or "-" to select "Metric"/"Imperial", and press the power button to save and return to "Unit." To save and return to the main interface, press "BACK"...
  • Page 11 Auto Off The display will automatically shut off, when the bike is not in use after a period of time, you can turn this function off or adjust the period of time. When in the HMI Setting Screen, press "+" or "-" to select "Auto Off”, then the power button to enter the setting, press "+"...
  • Page 12 Display Brightness To adjust the brightness of the display, when in the HMI Setting Screen, press "+" or "-" to select "Brightness”, then the power button to enter the setting, press "+" or "-" to select “100%”/“75%”/“50%”/“25%”, and press the power button to save and return to "Brightness". To save and return to the main interface, press "BACK"...
  • Page 13 Information Screen In the event of a fault with the bike, your dealer will access the information contained in these screens and provide to VelectriX to assist in identifying and resolving the fault. Language Screen When in the HMI Setting Screen, press "+" or "-" to select "Language”, then the power button to enter the setting, press "+"...
  • Page 14 Battery Instructions & Care Overview Rechargeable Lithium-Ion batteries have a limited life and will gradually lose their capacity to hold a charge, over time. This loss of capacity (ageing) is irreversible and normal. As the battery loses capacity, the length of time it will power the bike (ride time) decreases.
  • Page 15 You should only use the battery charger that is supplied, as new, with the bike. If you are not sure if you have the correct charger, contact VelectriX before you use it. If you drop or damage the battery charger in any way, DO NOT use it, you should dispose of the charger and purchase a replacement.
  • Page 16 Storage Or Low Use (30 days+) If you don’t intend to use your bike for a prolonged period of time, 30 days+, then there are some important things to note, and procedures to follow. Failure to comply with these instructions will result in damage to your battery, sometimes beyond repair.
  • Page 17 Cleaning & Care We recommend using a damp cloth to clean the outside of the battery shell only. To protect the electronic components, batteries must not be cleaned with direct water contact, for example: do not submerge the battery in water or use a hose or power hose on any part of the battery.
  • Page 18 Check Charge To check the battery charge level, turn on the display. The battery charge level is shown in the top left corner and displays as a %. You can also check the battery charge level by pushing the button on the top of the battery case.

  • Page 19: Removing The Battery From The Bike

    Locking & Unlocking the Battery The bike is supplied with a set of keys. The lock is located at the bottom of the battery, in the frame of the bike. Removing the Battery from the Bike To remove the battery, insert the key and turn fully clockwise and slide the lever lock forward.

  • Page 20: Maintenance

    You can wipe dry the bike with a cloth. • VelectriX encourages all owners to return their new VelectriX bike to the place of purchase for a service/safety check, within the first month or so of ownership.

  • Page 21: Warranty

    Warranty This warranty is provided by VelectriX Pty Ltd. VelectriX warrants its products, including all individual components against defects in material or workmanship as follows: Warranty Conditions The warranty period is not renewed or extended as a result of a warranty repair or replacement.
  • Page 22 Controller *The battery warranty will exclude damage from: Over charging or power surges The use of an improper, non-approved VelectriX charger Any other misuse, abnormal wear and tear, physical damage or water damage Failure to follow Battery Instructions & Care Age related reduction in the capacity of the battery is normal and unavoidable and as such does not constitute a fault.
  • Page 23 Damage caused from competitive use, stunt riding or exceeding the bikes carrying capacity. How To Make a Warranty Claim If you believe your VelectriX product is faulty or defective, please contact the authorised VelectriX reseller/dealer from where the bike was purchased and explain the issue.

  • Page 24: Model Specification

    Shimano MT200 hydraulic disc brakes GEARS Shimano Cues 9 speed MOTOR Bafang 250 watt, 36 volt rear hub motor (SUV model) Bafang 500 watt, 36 volt rear hub motor (SUV+ model) DRIVE TYPE Speed sensor. 5 levels of pedal assist & walk assist mode...

This manual is also suitable for:

Suv+
