- Page 1 MY23 VelectriX Instruction Manual (rear hub series) • Stray...
-
Page 2: Table Of Contents
Contents Safe Riding Recommendations Page 2 Pre-Ride Checklist Page 3 Display and Controls Pages 4-6 Battery Instructions Page 7-11 Maintenance Pages 12 Warranty Page 13-15 Model Specification Pages 16 Page 1... -
Page 3: Safe Riding Recommendations
Safe Riding Recommendations Please ensure you are familiar with and follow all traffic laws and regulations for your state. Please remember you may need to review these when travelling interstate. Always wear a helmet when riding your bike. Don’t lend your bike to anyone who is unfamiliar with it. As with all bikes it is important that you stay within safe limits and speeds. -
Page 4: Pre-Ride Checklist
Pre-Ride Checklist Check over the bike for any loose nuts, bolts, or fixings. Check the tyre pressure. Please always refer to the tyre manufactures suggested levels on the side of the tyre. Check the tyres for any visible damage, wear and tear or bald spots. -
Page 5: Display And Controls Pages
Display and Controls The bike is operated by an integrated control button, fitted into the top tube, with 5 main functions: • Switching the bike ON/OFF • Selecting the level of support (power) • Switching the lights ON/OFF (if bike is equipped with lights) •... - Page 6 Select The Level Of Support (Power) When the display is turned on, press button for 1 second to switch the level of support to increase/decrease the output of the motor. The lowest level is 1 (Cyan colour), medium is 2 (blue colour) and the highest level is 3 (purple colour) Battery Capacity Indication The current battery capacity is displayed when the bike is first switched ON and will also be displayed during riding as below.
- Page 7 Error Code Detection In the event that the bike develops an error/fault, the display will flash with a series of blue and cyan colours. Please contact the VelectriX dealer where you purchased the bike, so they can resolve the issue.
-
Page 8: Battery Instructions
Battery Instructions To check how much charge the battery has, press the button on the battery top. The battery charge light will illuminate. The colour of the LED indicates the level of battery charge: Blue More than 90% charge Green 40 –... - Page 9 Battery Care Rechargeable Lithium-Ion batteries have a limited life and will gradually lose their capacity to hold a charge. This loss of capacity (ageing) is irreversible. As the battery loses capacity, the length of time it will power the bike (ride time) decreases. The typical estimated “healthy life” of a Lithium-Ion battery is about three years or 500 charge cycles, whichever occurs first.
- Page 10 If you are charging your battery on the bike, with the bike turned off, insert the charging plug into the charging port on the bike. Connect the battery charger power plug to the mains power outlet and switch the mains power on.
- Page 11 If a battery is stored or otherwise unused for an extended period, • be sure to follow the storage instructions in this document. If you do not follow the instructions, and the battery has no charge remaining when you check it, consider it to be damaged. Do not attempt to recharge it or to use it.
- Page 12 Keep the battery away from children. • Avoid exposing the battery to excessive shock or vibration • Do not use a damaged battery. • Cleaning & Care We recommend using a damp cloth to clean the outside of the battery shell only.
-
Page 13: Maintenance Pages
Maintenance Your VelectriX bike should be returned to your servicing dealer for servicing and a thorough inspection once every 9 months or 1500kms, whichever comes first. Excluding the electronics, motor, battery and wiring, your VelectriX e-bike is a normal bike, with normal components. -
Page 14: Warranty
Warranty This warranty is provided by VelectriX Pty Ltd. VelectriX warrants its products, including all individual components against defects in material or workmanship as follows: Warranty Conditions The warranty period is not renewed or extended as a result of a warranty repair or replacement. - Page 15 Controller *The battery warranty will exclude damage from: Over charging or power surges The use of an improper, non-approved VelectriX charger Any other misuse, abnormal wear and tear, physical damage or water damage Age related reduction in the capacity of the battery is normal and unavoidable and as such does not constitute a fault.
- Page 16 Damage caused from competitive use, stunt riding or exceeding the bikes carrying capacity. How To Make a Warranty Claim If you believe your VelectriX product is faulty or defective, please contact the authorised VelectriX reseller/dealer from where the bike was purchased and explain the issue.
- Page 17 Model Specification Stray FRAME Aluminium Urban frame COLOUR Basalt SIZES 49cm, 51.5cm, 54cm, 57cm FORK Fixed fork RIMS Double wall, 700c, 13 gauge, 36 hole TYRES Kenda Drumlin 700c x 45c" with K-Shield protection HANDLEBARS Zoom straight handlebar STEM Promax 31.8mm bar, 108mm extension SEAT POST Promax 27.2mm x 300mm BRAKES...
