Installation and User's Guide

IMPORTANT SAFETY INFORMATION:

Read this manual first before attempting to install or use this electric fire. Always comply with the warnings

and safety instructions contained in this manual and presented on the appliance to prevent personal injury

or property damage.

The product complies with the required Product Safety, Electromagnetic Compatibility and Environmental

Standards.This product is fully compliant with LVD,EMC. RoHs and EcoDesign Directives.

EN: This product is only suitable for well insulated rooms or occasional use. DE: Dieses Produkt ist nur für gut isolierte Bereiche oder

gelegentliche Verwendung geeignet. FR: Ce produit convient uniquement à des endroits bien isolés ou pour un usage occasionnel.

IT: Questo prodotto è adatto solo per spazi ben isolati o per uso occasionale. ES: Este producto sólo es adecuado para espacios

bien aislados o un uso ocasional. NL: Dit product is uitsluitend geschikt voor goed geïsoleerde ruimten of voor sporadisch gebruik.

PL: Produkt ten jest odpowiedni wyłcznie do dobrze odizolowanych miejsc lub do okazjonalnego uytku. NO: Dette produktet

egner seg kun for godt isolerte rom eller sporadisk bruk. RO: Acest produs este adecvat exclusiv spaiilor bine ventilate sau utilizrii

ocazionale. CZ: Tento výrobek je vhodný pouze do dobe izolovaných prostor nebo k píležitostnému použití. DK: Dette produkt

er kun egnet til velisolerede rum eller lejlighedsvis brug. PT: Este produto somente é adequado para espaços bem isolados ou

uso ocasional. SE: Denna produkt är endast avsedd för välisolerade utrymmen eller tillfällig användning. FI: Tämä tuote soveltuu

ainoastaan hyvin eristettyihin tiloihin tai satunnaiseen käyttöön. SK: Tento výrobok je vhodný len pre dobre izolované priestory alebo

na obasné použitie. SI: Ta izdelek je primeren le za dobro izolirane prostore ali za obasno uporabo. HR: Ovaj proizvod je pogodan

samo za dobro izolirane prostore ili povremenu upotrebu. HU: Ez a termék csak jól szigetelt terekhez vagy eseti használatra alkalmas

INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.

CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE

Models

EVO1200

EVO1500

EVO1800

EVO2500

7216860100 ISSUE 1

Need help?

Do you have a question about the IGNITE EVOLVE EVO1200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dimplex IGNITE EVOLVE EVO1200

Page 1 Models EVO1200 EVO1500 EVO1800 EVO2500 Installation and User’s Guide IMPORTANT SAFETY INFORMATION: Read this manual first before attempting to install or use this electric fire. Always comply with the warnings and safety instructions contained in this manual and presented on the appliance to prevent personal injury or property damage.
Page 2 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Dimplex...
Page 3 Welcome MODEL NUMBER AND SERIAL NUMBER Please record your model and serial numbers for future reference. Model Serial Number QR Code label (behind front glass) for the Flame Connect App Model and serial number label SAVE THESE INSTRUCTIONS...
Page 4 Warning: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility. Dimplex...
Page 5 IMPORTANT INSTRUCTIONS WARNING: KEEP BATTERIES OUT OF REACH OF CHILDREN • Swallowing may lead to serious injury in as little as 2 hours or death, due to chemical burns and potential perforation of the oesophagus. • If you think batteries might have been swallowed or placed inside any part of the body seek immediate medical attention •...
Page 6 Product Dimensions Figure 1 EVO1200 model 1278 mm EVO1500 model 1532 mm EVO1800 model 1887 mm EVO2500 model 2548 mm 110 mm EVO1200 model 1306 mm EVO1500 model 1560 mm 147 mm EVO1800 model 1941 mm EVO2500 model 2576 mm Dimplex...
Page 7 Package Contents Quantity Image Description EVO1200 EVO1500 EVO1800 EVO2500 Remote Control Driftwood ~2.6 lb ~3.3 lb ~3.9 lb ~5.2 lb Tumbled Glass Embers ~1.2 kg ~1.5 kg ~1.8 kg ~2.4 kg Firebox Front Glass 7.4×10 Hex Key Black Screws (M4×10, hex button head) Screw Covers Mirrored Glass UK Power Cord...
Page 8 Wood Screws 38.1 mm Bubble Level *Package contents are subject to change Optional Accessories Model Number Description EVO1200 EVO1500 EVO1800 500003877 500003878 500003879 Ignite Evolve Oak Logset *Please contact your local Dimplex dealer for inquiries. Dimplex...
Page 9 Installation Placement NOTE: It is recommended that the bottom of the unit be mounted between 127 mm and 1016 mm from the ground to maintain an optimized viewing angle of the flame. WARNING: The top of the fireplace must be installed a minimum of 610 mm from the ceiling. The fireplace must be installed a minimum of 127 mm from the ground.
Page 10 4. Lift the firebox into the opening in the frame using the handles on the back of the fireplace. 5. Using a bubble level (supplied) ensure that the fireplace is level within the framing. Adjust as required. Dimplex...
Page 11 Installation Distance from the right side to the power cord: EVO1200, EVO1500, EVO1800 EVO2500 330 mm 508 mm 6. Drive four supplied mounting screws through the four mounting holes located on the inside surface of the fireplace chassis, into wall studs. (Figure 4) 7.
Page 12 NOTE: Two power cords are provided (the EU or UK option) with the fireplace. Install the suitable power cord if the incorrect set came installed on the unit. WARNING: This heater is not intended for use with an extension cord. Plug the power cord directly into an appropriate grounded receptacle. Figure 5 Figure 6 Dimplex...
Page 13 Installation Heater Hardware Disconnect The fireplace heater can be permanently disabled by removing the electronic jumper on the control board. NOTE: Heater hardware disconnect will permanently disable the heater and fan. Follow these instructions only when an installation without heat is required. Temporary disabling of the heater can be achieved through the hidden touch controls.
Page 14 NOTE: Do not dispose of the suction cup! Keep it in a secure location, as it may be needed for maintenance and service on this fireplace. Figure 9 Mirrored Glass Bracket Mirrored Glass Support Media Tray Mirrored Glass Mirrored Glass Support Dimplex...
Page 15 Installation Media Arrangement For the best results when using the supplied media, follow the instructions below. Figure 10 Tumbled Glass Media and Driftwood: NOTE: The driftwood is fragile. Ensure the driftwood is secure when placing it in the media bed, and keep a soft surface below the fireplace during installation.
Page 16 6. Install the provided screw covers by placing the tabs of the screw cover between sides of the front glass bracket. (Figure 15) NOTE: Do not dispose of the suction cup and hex key! Keep them in a secure location, as it may be needed for maintenance and service on this fireplace. Figure 14 Figure 15 Dimplex...
Page 17 NOTE: To operate correctly, the remote control must be pointed toward the front of the unit. The fireplace is capable of being controlled using the Flame Connect app for mobile devices. For up-to-date information about the app, please visit www.dimplex.com/fcapp Figure 17...
Page 18 Freeze the media and accent lights to a custom color. When in Prism or Kaleidoscope modes (see Moods), press while the desired color is Custom Color displayed to freeze the cycle on that color. Press again to resume the color cycle. Dimplex...
Page 19 Operation Press repeatedly to cycle through the brightness and flicker modes. Solid H - High Brightness Brightness Solid L - Low Brightness Cycle H - High Brightness with flickering media and accent lights Cycle L - Low Brightness with flickering media and accent lights Press repeatedly to cycle through the 7 different flame themes: 1 - Base with orange and blue accents...
Page 20 For this reason the heater must be inspected regularly, depending upon conditions and at a minimum yearly intervals. Servicing Except for installation and cleaning described in this manual, an authorized service representative should perform any other servicing. Dimplex...
Page 21 Check with your Local Authority or retailer for recycling advice in your area. © Glen Dimplex Flame Europe. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Glen Dimplex Flame Europe.
