  • Page 1: Xv-303/Xv-313 Multi-Touch Display Manual

    03/25 MN048031EN   Manual   XV-303/XV-313 multi-touch display Manual  ...

  • Page 2: Company Information

    No part of this manual may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, micro-filming, record- ing, or otherwise, without the prior written permission of EATON. Subject to alteration.

  • Page 3: Before Starting With The Installation

    DANGER! Hazardous electrical voltage! Before starting with the installation   Installation requires qualified electrician desktop devices and portable devices only when   the housing is closed. Disconnect the power supply of the device.     Measures should be taken to ensure the proper Secure against retriggering  ...

  • Page 5: Table Of Contents

    Table of Contents XV-303/XV-313 multi-touch display Manual Company information Before starting with the installation Table of Contents About this documentation 0.1.1 List of revisions 0.1.2 Target group 0.1.3 Legal disclaimer 0.1.4 Device designations and abbreviations 0.1.5 Writing conventions 0.1.5.1 Warning labels 0.1.5.2...
  • Page 6 Fixing and sealing 3.3.2 Front mounting XV-303 3.3.3 Rear (wall) mounting XV-313 Preparing the device for operation 3.4.1 Functional earthing XV-303/XV-313 multi-touch display 3.4.2 Power supply - electrical connection Commissioning Initial commissioning Running the XV300 External connections Layout of interfaces SD card XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 7 Technical data A.1.1 Data sheets A.1.2 Dimension and weight specifications A.1.2.1 XV-303 Front mounting A.1.2.2 XV-313 Rear (panel) mounting A.1.2.3 Mounting surrounds for rear (panel) mounting A.1.3 General data A.1.4 Port and interface specifications A.1.5 Information on the power supply A.1.6...

  • Page 8: About This Documentation

    This Manual contains all the information you will need in order to use the XV-303/XV- 313 multi-touch display safely and effectively. The Manual XV-303/XV-313 multi-touch display manual is considered an integral part of the devices and must always be readily available in the device's close proximity so that users have access to it.

  • Page 9: Target Group

    This Manual is intended for electricians and electrical engineers, as well as for the people who will be in charge of performing the electrical installation and people who will be using the XV-303/XV-313 multi-touch display as an operating and monitoring device or as an integrated operating and control device in their own applications.

  • Page 10: Legal Disclaimer

    In particular, this information does not guarantee any particular properties. Do not use the XV-303/XV-313 multi-touch display before reading and understanding this manual. It is assumed that the user of this manual is thoroughly familiar with the information found in the manuals for incorporating the XV-303/XV-313 multi-touch display into automation processes.

  • Page 11: Writing Conventions

    Warns of the possibility of hazardous situations that could result in serious injury or even death. DANGER! Dangerous Electrical Voltage! CAUTION Warns of the possibility of hazardous situations that can cause injury. Property damage warning NOTICE Warns about the possibility of material damage. XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 12: Additional Information For Use

    Documents (such as manuals) are listed after the icon together with the cor- responding name and Eaton number. Publication title For identifying the Eaton publication code External Internet addresses. They will be shown after the icon. Destination address XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 13: Description

      Requires very little space; can also be used in portrait mode   XV-303 model for front mounting and XV-313 model for rear (panel) mounting   Display sizes 7.0“ and 10.1“ with a 1024 x 600 Pixel resolution, Display size 15.6" with a 1366 x 768 Pixel resolution  ...

  • Page 14: Notes

    XV series with application-oriented functions that are ideal for optimized system solutions. 1.2 Use as intended XV-303/XV-313 multi-touch display are primarily intended for use in machine and sys- tem building applications. They are intended exclusively for monitoring, operating, and controlling machines and systems.

  • Page 15: Device Models - Versions And Part Nos

    Three widescreen display sizes: 7.0", 10.1" or 15.6" widescreen   Device bundles with visualization software and/or control software licenses. Additional integrated interface   Second Ethernet port (10/100 Mbit/s) for use as a communication interface Device models with PLC functionality XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 16 Tab. 2: Enclosure versions for front mounting Front with plastic bezel Service side with optional interfaces Fig. 1: XV-303-70-.. Fig. 2: XV303-70-C00-A00-2B Fig. 3: XV-303-10-.. Fig. 4: XV-303-10-B00-A00-2B     Fig. 5: XV-303-15-.. Fig. 6: XV-303-15-C00-A00-2B XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 17 Sheet thickness of the installation panel d = 2 mm (0.08") ± 0.1mm (0.004") Tab. 3: Enclosure versions for rear (panel) mounting Front side with aluminum mounting frame Service side with optional interfaces Fig. 7: XV-313-70-.. Fig. 8: XV-313-70-B00-A00-2C Fig. 9: XV-313-10-.. Fig. 10: XV-313-10-C00-A00-2C XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 18: Operating And Indication Elements

    1.4 Operating and indication elements     Front XV-303 Front XV-313 Service side with optional interfaces XV-303 Service side with optional interfaces XV-313 ① Display of HMI device Display, touch sensor Detects when the controls shown on the display are being actuated.

  • Page 19: Interfaces To Peripheral Devices

    1.5 Interfaces to peripheral devices 1.5 Interfaces to peripheral devices The interfaces featured by your XV-303/XV-313 multi-touch display will depend on theXV version selected and cannot be modified. The nameplate will indicate which specific interfaces are included with the unit.

  • Page 20: What The Different Parts Of The Part Number Mean

    Tab. 8: Version   Standard version, Type XV-313 sheet thickness of the installation panel d = 1.5 mm (0.059") ± 0.1mm (0.004") Type XV-313 sheet thickness of the installation panel d = 2 mm (0.08") ± 0.1mm (0.004") XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 21: Accessory Devices

    A variety of accessories are available for XV300 multi-touch displays.   SD card   Accessories NOTICE Only use original accessories. Order accessories through your supplier or through the EATON online catalog Eaton.eu/ecat Example: article no. Catalog Number 181638 MEMORY-SD-A2-S SD memory card with min. 1 GB 139807 MEMORY-SD-A1-S SD memory card with min.

  • Page 22: Nameplate

    Layout of ports/interfaces and controls Fig. 12: Example for a nameplate 1.9 Support To get fast and effective support, make sure to always provide Customer Service with the following information from the nameplate:   Part-No.   Serial-No XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 23: Conditions For Underwriters Laboratories Inc. (Ul) Listing

    The torque used to tighten the screw terminals on the plug-in connection for the sup- ply voltage must not exceed 0.6 ... 0.8 Nm (5 ... 7 lb-in). Required only for XV-303/XV-313 multi-touch display SmartWire-DT units with a con- nection.

  • Page 24: Marine Approvals

    EATON ZB4-102-KS1) Location class interface Installation EMC B Power supply Place noise filter EMC A No additional installations   Please refer to the following as well → Section "Conditions for marine approval", page 38 XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 25: Safety Regulations

    Follow the safety instructions for the XV300! The section on safety instructions must be read and understood by everyone who will be working with the XV-303/XV-313 multi-touch display before the actual work is performed HMI-PLC. NOTICE Pay attention to the hazard severity levels used throughout this doc- umentation whenever a hazard is indicated.

  • Page 26: Installation, Maintenance, And Disposal

    XV300. Additional parts of the documentation and information for the XV300, including the installation instructions, can be found at the Eaton Download Center - Documentation and at the product pages on the Internet Eaton.com/documentation Eaton.com/XV300...

  • Page 27: Device-Specific Hazards

    Make sure that the device is not exposed to dangerous impacts and other types of dangerous mechanical shock. Do not operate the device in hazardous (classified) locations unless it is mounted correctly. De-energize the device before disconnecting plug connections. XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 28 Dispose of the XV300 unit professionally. CAUTION DESTRUCTION The XV-303/XV-313 multi-touch display should only be opened by the manufacturer or by an authorized center. Operate the XV300 until only with the enclosure fully closed and sealed. CAUTION ELECTROSTATIC DISCHARGE Do not touch components (e.g., connector pins) that are elec-...
  • Page 29 Ground connection characteristics: Wire cross-sectional area ≧ 1.5 mm², length ≦ 350 mm The XV-303/XV-313 multi-touch display needs to be connected to the conductive structure in, e.g., the control panel using the central earth point (earthing screw). This method of earthing is mandatory required for proper function.
  • Page 30 CAUTION DATA LOSS Insert or remove the SD card only when the XV-303/XV-313 multi-touch display is de-energized. Before switching off the device, make sure that there are no pro- grams writing to the SD card.
  • Page 31 Do not use any pointy or sharp objects (e.g., knives).   Do not use aggressive or abrasive cleaning products or solvents. Make sure that no liquids get into the XV-303/XV-313 multi-touch display unit (short-circuit hazard) and that the XV-303/XV-313 multi- touch display unit is not damaged in any way.
  • Page 32 Protect the RJ45 plug-in connection from tensile forces at the socket. WARNING XV-303/XV-313 multi-touch display units are products designed for use in industrial environments as defined in ICE/EN 6100−6-4. These products can cause radio interference in domestic environments. In this case, the party operating the products must implement appro- priate radio interference suppression measures.

  • Page 33: Installation

    The SD card slot is located on the side of the XV300. Make sure to take the space required to remove the SD card into account. Fig. 13: Space required to remove the SD card XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 34: Temperatures

    CAUTION UV LIGHT Plastics will become brittle when exposed to UV light. This artificial aging will reduce the XV-303/XV-313 multi-touch display unit's life- span. Protect the XV300 unit from direct sunlight and other sources of UV radiation. The environmental ambient conditions for operation must not exceed the specified...

  • Page 35: Aeration And De-Aeration

      Make sure that there will be enough volume for air changes inside the control panel, etc. The specified clearance around the XV-303/XV-313 multi-touch display is: a, b, c ≧ 30 mm (1.18")   If you will be installing the XV-303/XV-313 multi-touch display in complex systems together with other assemblies, you must ensure that there will be enough air cir- culation in order to prevent overheating.

  • Page 36: Criteria For The Installation Position

    XV-303-10-..:e = 183 mm ±1 (7.20" ±0.04), f = 122 mm ±1 (4.80"±0.04") XV-303-70-..: e = 255.5 mm ±1 (10.06"±0.04), f = 160.5 mm ± 1 (6.32" ±0.04), XV-313-10-..:e = 387 mm ±1 (15.24"± 0.04), f = 238.5 mm ±1 mm (9.39" ± 0.04) for rear (panel) mounting XV-313-70-..: e = 182.7 mm ±0.1 (7.193"...

  • Page 37: Technical Conditions For Acceptance By Underwriters Laboratories Inc. (Ul)

    The devices must be installed in a suitable fire protection enclosure that provides protection against the spread of fire. The torque used to tighten the screw terminals on the plug-in connection for the sup- ply voltage must not exceed 0.6 ... 0.8 Nm (5 ... 7 lb-in). XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 38: Conditions For Marine Approval

    Integrate a radio interference suppression filter into the wiring. Depending on the output, the following filters can be used:   XT-FIL-1 radio interference suppression filter for 24 V DC supply up to 2.2 A (Eaton article no. 285316)   XT-FIL-2 radio interference suppression filter for 24 V DC supply up to 12 A (Eaton article no.
  • Page 39 3. Installation 3.1 Prerequisites for the location of use   a separate line to the filer's PE connection. Depending on the current consumption or configuration, several filters may be used as well. XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 40: Unpacking And Checking The Equipment Supplied

    6 x for XV-303-10-.., 10 x for XV-303-70-.., 12 x for XV-303-15-.. The XV-303/XV-313 multi-touch display is sturdily built, but the components inside it are sensitive to excessively strong vibrations and/or mechanical shock. Accordingly, make sure to protect the XV-303/XV-313 multi-touch display from mechanical loads that exceed the scope of the unit's intended use.

  • Page 41: Mounting

    Check the gasket for damage and make sure it is resting correctly inside the enclosure groove. Missing parts or damage If you notice anything wrong, please contact your distributor or Eaton Service +49 (0) 180 5 223822 (de,en) XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 42: Front Mounting Xv-303

    Pre-install the holding brackets using the set screws. Check that the gasket is in its correct position and pre-install the holding brackets Peripheral gasket in the rim Sponge rubber round cord, Material NBR/PVC Black, closed outer skin, diameter 3 mm (0.12") XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 43 6. Check that the device is in its correct, centered position and that the gasket is in contact all around; adjust if necessary. 7. Tighten the set screws in a criss-cross sequence: with a torque of ≦ 0.1Nm (0.86 lb-in) XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 44: Rear (Wall) Mounting Xv-313

    R 3.5 ±0.1 mm (R 0.14 ±0.004") M4 x 12 156 ±0.5 mm (6.14 ±0.02") 182.7 ±0.1 mm (7.19 ±0.004") 199 ±0.5 mm (7.83 ±0.02") Fig. 19: Dimensional drawing for mounting XV-313-70-.. XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 45 1. Carefully insert the XV-313 into the mounting cutout from behind. 2. Center the XV-313 in the mounting cutout. 3. Use washers and M4 nuts to fasten the XV-313 to all the weld studs on the sheet in such a way that there is zero clearance Fig.

  • Page 46: Preparing The Device For Operation

    Ground connection characteristics: Wire cross-sectional area ≧ 1.5 mm², length ≦ 350 mm The XV-303/XV-313 multi-touch display needs to be connected to the conductive structure in, e.g., the control panel using the central earth point (earthing screw). This method of earthing is mandatory required for proper function.
  • Page 47 14.4W Current consumption at 24 V DC: 11.9 W for basic device + 2.5 W for USB module XV-303-70-.., XV-313-70-.. max. 18 W Current consumption at 24 V DC: 15.5 W for basic device + 2.5 W for USB module XV-303-15-..

  • Page 48: Functional Earthing Xv-303/Xv-313 Multi-Touch Display

    Ground connection characteristics: Wire cross-sectional area ≧ 1.5 mm², length ≦ 350 mm The XV-303/XV-313 multi-touch display needs to be connected to the conductive structure in, e.g., the control panel using the central earth point (earthing screw). This method of earthing is mandatory required for proper function.

  • Page 49: Power Supply - Electrical Connection

    = 24 V DC (19.2 - 30 V DC SELV) = ... 0.6 - 0.8 Nm (5 - 7 lb-in) 0 V +24 V DC Fig. 23: Connecting the screw terminals on the Plug connector MSTB 2.5/3-ST-5.08 XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 50 (SELV) set forth in IEC 60950 and – in connection with the UL listing – the requirements for a low-voltage source set forth in UL 61010-2-201. The XV-303/XV-313 multi-touch display is now ready to run on 24 V XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 51: Commissioning

    The XV300 unit will boot up. The XV300 multi-touch display does not come with any runtime soft- ware for visualization or PLCs installed. The corresponding software packages can be used to install the required runtime software on the XV300 unit. XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 52: Initial Commissioning

    Install the required software packages. 4.2 Running the XV300 Once the XV-303/XV-313 multi-touch display has been initially commissioned, it will run whenever it is connected to the supply voltage. In other words, it does not have to be separately switched on and off.

  • Page 53: External Connections

    5. External connections 5. External connections With their ports, Eaton's XV300 multi-touch display make it possible to connect a vari- ety of peripheral devices and components. DANGER STRAY CURRENTS Large equalizing currents between the functional earthing system and the ground system of different devices may result in fire or in mal- functions due to signal interference.

  • Page 54: Layout Of Interfaces

    RS-232 SUB-D plug 9-pole, not galvanically isolated, UNC nuts for interlocking ⑦ SUB-D plug 9-pole, not galvanically isolated, UNC nuts for interlocking Optional ⑧ Ethernet 2 RJ-45 socket, 8-pole, 2 LEDs (CAT5e/6), LAN1, 10/100 Mbps   XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 55: Sd Card

    CAUTION DATA LOSS Insert or remove the SD card only when the XV-303/XV-313 multi-touch display is de-energized. Before switching off the device, make sure that there are no pro- grams writing to the SD card.

  • Page 56: Usb Interfaces

    5. External connections 5.3 USB interfaces 5.3 USB interfaces Eaton's XV300 multi-touch display units feature ports that can be used to connect USB peripheral devices supported by the XV300 unit's hardware and operating sys- tem. CAUTION When using commercially available peripheral devices (e.g., with the...

  • Page 57: Ethernet 1, Ethernet

    Protect the RJ45 plug-in connection from strong vibrations.   Protect the RJ45 plug-in connection from tensile forces at the socket. To commission the communication between the XV300 and the device, follow the description for the connected device. XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 58: Serial Interfaces For Communication With Plcs Or Devices

      2.5 m 115200 Bit/s 57600 Bit/s 10 m 38400 Bit/s 15 m 19200 Bit/s 30 m 9600 Bit/s When preparing connections, ensure that the cable shield has a low impedance connection with the connector housing. XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 59: Rs-485 Com2

    1200 m Possible baud rates 9600 Bit/s   19200 Bit/s   38400 Bit/s   57600 Bit/s   115200 Bit/s When preparing connections, ensure that the cable shield has a low impedance connection with the connector housing. XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 60 The bus segment must be terminated at both ends. There must not be more than two terminations per bus segment. Running the bus segment without the right termination may result in transmission errors.   Fig. 29: Bus segment with four nodes XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 61: Can1 Interface For The Canopen Protocol, J1939 Protocol, Etc

        108 … 132 Ohm Capacitance per unit length     < 60 pF/m Core cross-section 100 m 0.25 mm With a max. cable length of 250 m 0.34 mm 500 m 0.75 mm   XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 62 The bus segment must be terminated at both ends. There must not be more than two terminations per bus segment. Running the bus segment without the right termination may result in transmission errors. Fig. 30: CAN bus segment with four nodes XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 63: Faults

    6. Faults 6. Faults This section provides troubleshooting information for your XV-303/XV-313 multi-touch display in case it does not behave as expected. Fault Cause Remedy XV300 will not boot up Check the input wiring. No 24 VDC supply voltage Switch on XV300.

  • Page 64: Maintenance

    Do not use any pointy or sharp objects (e.g., knives).   Do not use aggressive or abrasive cleaning products or solvents. Make sure that no liquids get into the XV-303/XV-313 multi-touch display unit (short-circuit hazard) and that the XV-303/XV-313 multi- touch display unit is not damaged in any way.

  • Page 65: Repairs

    For repairs, please contact your vendor or Eaton's Technical Support. CAUTION DESTRUCTION The XV-303/XV-313 multi-touch display should only be opened by the manufacturer or by an authorized center. Operate the XV300 until only with the enclosure fully closed and sealed.
  • Page 66 HMI-PLC until it is completely dry. Use the original packaging to ship the device. The XV-303/XV-313 multi-touch display is sturdily built, but the components inside it are sensitive to excessively strong vibrations and/or mechanical shock. Accordingly, make sure to protect the XV-303/XV-313 multi-touch display from mech- anical loads that exceed the scope of the unit's intended use.

  • Page 67: Disposal

    Important! Dispose of recyclables as required by your local recycling reg- ulations. XV-303/XV-313 multi-touch display no longer being used must be professionally dis- posed of as per local standards or returned to the manufacturer or relevant sales department. Tab. 20: Materials used XV-303/XV-313 multi-touch display Assembly part  ...

  • Page 68: Appendix

    Appendix Appendix A.1 Technical data A.1.1 Data sheets A.1.2 Dimension and weight specifications A.1.3 General data A.1.4 Port and interface specifications A.1.5 Information on the power supply A.1.6 Approvals and declarations A.2 Further usage information XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 69: Technical Data

    1 Slot for 1 SD-card 7.0" XV-303-70-C00-A00-2B EP-401362 Integrated interfaces: 2 x Ethernet 100/10, 1 x USB host, XV-303-10-C00-A00-2B 10.1" EP-401366 1 x USB device, 1 x RS-485, 1 x RS-232, 15.6" XV-303-15-C00-A00-2B EP-401369 1 x CAN XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 70 2 x Ethernet 100/10, XV-313-10-C00- d = 1.5 mm (0.059") ± 0.1mm (0.004") 10.1" 1 x USB host, 401374 A00-2C 1 x USB device, 1 x RS-485, 1 x RS-232, 1 x CAN PLC function   XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 71: Dimension And Weight Specifications

    Fig. 31: Dimensions for 7.0" front mounting devices in mm (inches) Width x Height x Depth 196 mm x 135 mm x 51 mm (7.72" x 5.31" x 2.01") (without plug) Weight 0.74 kg (1.63 lbs) XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 72 Fig. 32: Dimensions for 10.1" front mounting devices in mm (inches) Width x Height x Depth 269 mm x 174 mm x 58 mm (10.59" x 6.85" x 2.28") (without plug) Weight 1.13 kg (2.49 lbs) XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 73 Fig. 33: Dimensions for 15.6" front mounting devices in mm (inches) Width x Height x Depth 401.7 mm x 254.9 mm x 67.6 mm ±0.2 (15.9" x 10.04" x 2.661" ±0.008 ) (without plug) Weight 3.25 kg (7.17 lbs) XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 74: Xv-313 Rear (Panel) Mounting

    156 mm (6.14") 181.5 mm (7.15") 209 mm (8.23") Fig. 34: Dimensions for 7.0" rear (panel) mounting devices in mm (inches)XV-313-..-...-A00-.. Width x Height x Depth 209 mm x 151 mm x 51 mm (8.23" x 5.94" x 2.01") (without plug) Weight 0.8 kg (1.76 lbs)
  • Page 75 ⌀ 5.5 mm (⌀ 0.22") ⌀ 7.5 mm (⌀ 0.30") R 3.2 mm (R 0.13") x 1.5 mm (0.059") 170 mm (6.69") 254.4 mm (10.02") 282 mm (11.10") Fig. 35: Dimensions for 10.1" rear (panel) mounting devices in mm (inches)XV-313-..-...-A00-.. XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 76 170 mm (6.69") 254.4 mm (10.02") 282 mm (11.10") Fig. 36: Dimensions for 10.1" rear (panel) mounting devices in mm (inches)XV-313-..-...-A11-.. Width x Height x Depth 282 mm x 190 mm x 58 mm (11.10" x 7.48" x 2.28") (without plug) Weight 1.21 kg (2.67 lbs)

  • Page 77: Mounting Surrounds For Rear (Panel) Mounting

    (R 0.14 ±0.004") M4 x 12 156 ±0.5 mm (6.14 ±0.02") 182.7 ±0.1 mm (7.19 ±0.004") 199 ±0.5 mm (7.83 ±0.02") Fig. 37: Installation panel for XV-313-10-..   R 3.9 ±0.1 mm (R 0.15 ±0.004") M4 x 12 170 ±0.5 mm (6.69 ±0.02") 255.7 ±0.1 mm (10.07 ±0.004")

  • Page 78: General Data

    Appendix A.1 Technical data A.1.3 General data The following specifications apply to all XV-303/XV-313 multi-touch display units or to the specified part nos. where applicable. General type     XV-303 Plastic enclosure and glass panel in plastic frame   XV-313...
  • Page 79 344.23 mm x 193.54 mm XV-303-15-.. Contrast ratio (Normally)     normally 850:1 XV-303-70-.., XV-313-70-..   XV-303-10-.., XV-313-10-.. normally 500:1 XV-303-15-.. Brightness Normally 400 cd/m2 Backlight dimmable via software Lifespan of backlight Normally 50000 h at 25 °C XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 80: Port And Interface Specifications

    USB 2.0, not galvanically isolated, plug type B   SUB-D plug 9-pole, not galvanically isolated, RS-485 UNC nuts for interlocking   SUB-D plug 9-pole, not galvanically isolated, RS-232 UNC nuts for interlocking   SUB-D plug 9-pole, not galvanically isolated, UNC nuts for interlocking XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 81: Information On The Power Supply

    Appendix A.1 Technical data A.1.5 Information on the power supply The following specifications apply to all XV-303/XV-313 multi-touch display units. Power Supply rated operating voltage + 24 VDC SELV (safety extra low voltage)/PELV (protective extra low voltage) permissible Voltage range Effective: 19.2-30.0 V DC (rated operating voltage -20%/+25%)

  • Page 82: Approvals And Declarations

    -XV-313-10-..: on each 8 x -XV-313-70-..: on each 10 x Marine approval Type approval for the XV-303/XV-313 multi-touch display 7.0"and 10.1" – provided that (shipping clas- a radio interference suppression filter for the device is installed in the wiring DNVGL-CG-0039, from 11/2015...
  • Page 83 Inclination from vertical: ⍺ ≦ ± 45° at operating temperature ≦ 45°C (113°F) possible (if using natural convection) Storage / Transport -20 – + 60 °C (-4 – +140 °F) Humidity Relative humidity 10 - 95 % Condensation non-condensing XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...

  • Page 84: Further Usage Information

    For more information on additional devices and modules, please refer to the following documentation: XV-303-70-..., XV-303-10-… installation instructions IL048022ZU XV-313-70-..., XV-313-10-… installation instructions IL048023ZU Software Information on this can be found in the visualization software as user help: GALILEO 11...

  • Page 85: Alphabetical Index

    Capacitive multitouch ecat Cleaning Enclosure material Commissioning Equipment supplied Company information Ethernet Connections Ethernet 1 19, 54 External Ethernet 2 19, 54 Cooling Copy-protected Copyright Faults CTRL button Features Current 47, 81 Front Front mounting Function Damage XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 86 19, 22 CAN1 Equipment Ethernet Online Catalog RS-232 Operating elements RS-485 Operating System SD card Operation Serial Proper Type 19, 54 Original Operating Instructions USB device USB host USB peripheral devices Package contents Part number J1939 XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
  • Page 87 19, 54, 58 RS-485 19, 54, 59 Weight Safety Screen area visible Screen diagonal SD card SD card slot 18-19, 54 Sealing Service Service side Shipping classification 24, 38 Standards Std. pack Storage Support System Technical data XV-303/XV-313 multi-touch display  03/25 MN048031EN  Eaton.com...
