- Page 1 User Manual...
-
Page 2: Edition Notes
Edition Notes The EZPar 64 RGBA ILS User Manual includes a description, safety precautions, installation, programming, operation, and maintenance instructions for the EZPar 64 RGBA ILS as of the release date of this edition. Trademarks Chauvet, Chauvet DJ, the Chauvet logo, and EZPar are registered trademarks or trademarks of Chauvet &... -
Page 3: Table Of Contents
D-Fi USB DIP Switch Channels................12 IRC-6 Infrared Remote Control ..............Wired Master/Slave Mode................D-Fi USB Master/Slave Mode ............... ILS Mode....................... 5. Maintenance..................Product Maintenance ..................6. Technical Specifications..............Contact Us....................Warranty & Returns..................EZPar 64 RGBA ILS User Manual Rev. 1... -
Page 4: Before You Begin
Important installation or configuration information. The product may not function correctly if this information is not used. Useful information. EZPar 64 RGBA ILS User Manual Rev. 1... -
Page 5: Safety Notes
♦ Set this product on a flammable surface. Keep this User Manual for future use. If the product is sold to someone else, be sure that they also receive this document. EZPar 64 RGBA ILS User Manual Rev. 1... -
Page 6: Battery Charge Notes
Continue charging if the battery becomes hot, smokes, swells, or gives off an odor during charging. ♦ Leave the product unattended while charging. ♦ Deplete the battery below 10%. ♦ Charge the battery in a closed container. ♦ Charge for more than 24 hours. EZPar 64 RGBA ILS User Manual Rev. 1... -
Page 7: Introduction
WARNING! DO NOT plug anything other than a D-Fi USB into the USB type B port. Doing so may cause damage to the product. Product Dimensions 11.1 in 282 mm 9.7 in 2.5 in 246 mm 64 mm EZPar 64 RGBA ILS User Manual Rev. 1... -
Page 8: Setup
3. Setup AC Power The EZPar 64 RGBA ILS has an auto-ranging power supply and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 9: Power Linking
Additional product products It is possible to link up to 21 EZPar 64 RGBA ILS products on 120 VAC or up to 40 products on 230 VAC. The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, consult with the local Chauvet distributor as power linking connectors and requirements may differ by country or region. -
Page 10: Battery Power
Charging the Battery The battery charges whenever the EZPar 64 RGBA ILS is plugged into a power source using the included power cable. If the product is plugged in and not in operation, make sure the product is turned off. -
Page 11: Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The EZPar 64 RGBA ILS may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming. -
Page 12: Operation
Press to scroll down the list of options or to find a lower value <ENTER> Press to activate a menu option or a selected value Menu Map Refer to the EZPar 64 RGBA ILS product page on www.chauvetdj.com for the latest software and menu map. Mode... -
Page 13: Dmx Configuration
If the starting address is set too high, access to some of the product’s channels could be restricted. The EZPar 64 RGBA ILS uses up to 8 DMX channels in an 8-Ch DMX mode, which defines the highest configurable address to 505. For information about the DMX protocol, download the DMX Primer from www.chauvetdj.com. -
Page 14: Standalone Configuration
DMX signals from the controller. Static Colors To run the EZPar 64 RGBA ILS in Preset Color mode, follow the instructions below: 1. Press <MENU> repeatedly until C-- shows on the display. 2. Press <ENTER>. -
Page 15: D-Fi Usb Connectivity
D-Fi USB Connectivity The EZPar 64 RGBA ILS is able to become a D-Fi wireless receiver/transmitter with the use of the D-Fi USB from Chauvet DJ. Simply set the product's DMX Personality and DMX Address, set the DIP switch D- Fi receiving/transmitting channel, then plug it into the D-Fi USB port. -
Page 16: Irc-6 Infrared Remote Control
Operation IRC-6 Infrared Remote Control The EZPar 64 RGBA ILS is compatible with the IRC-6 infrared remote control from Chauvet. To enable or disable IRC-6 functionality, do the following: 1. Press <MENU> repeatedly until SET shows on the display. 2. Press <ENTER>. -
Page 17: Wired Master/Slave Mode
D-Fi USB Master/Slave Mode The D-Fi USB allows a single EZPar 64 RGBA ILS product (the “master”) to control the actions of one or more EZPar 64 RGBA ILS products (the “slaves”) without the need of a DMX controller or DMX cables. -
Page 18: Ils Mode
ILS mode. This product will synchronize with the par effect on the selected side of the GigBAR MOVE+ILS. To set the EZPar 64 RGBA ILS to respond to an ILS signal: 1. Press <MENU> repeatedly until iLS_ shows on the display. -
Page 19: Maintenance
6. Softly drag any dirt or grime to the outside of the transparent surface. 7. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. EZPar 64 RGBA ILS User Manual Rev. 1... -
Page 20: Technical Specifications
Maximum External Temperature Cooling System 104 °F (40 °C) Convection I/O Connector Channel Range 3-pin XLR 4 or 8 Ordering Product Name Item Code UPC Number EZPar 64 RGBA ILS 10032294 781462226428 EZPar 64 RGBA ILS User Manual Rev. 1... -
Page 21: Contact Us
For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. EZPar 64 RGBA ILS User Manual Rev. 1...
