- Page 1 User Manual...
-
Page 2: Edition Notes
Blazor as of the release date of this edition. Trademarks Chauvet, Chauvet DJ, the Chauvet logo, and Blazor are registered trademarks or trademarks of Chauvet & Sons, LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other company and product names and logos referred to herein may be trademarks of their respective companies. -
Page 3: Table Of Contents
Motor Control Mode ..................Mirror rotation: ......................13 Gobo rotation: ......................13 IRC-6 Infrared Remote Control ..............Master/Slave Mode ..................5. Maintenance..................Product Maintenance ..................Gobo Maintenance..................6. Technical Specifications..............Contact Us....................Warranty & Returns..................Blazor User Manual Rev. 1... -
Page 4: Before You Begin
Important installation or configuration information. The product may not function correctly if this information is not used. Useful information. Blazor User Manual Rev. 1... -
Page 5: Safety Notes
Before You Begin Safety Notes These Safety Notes include important information about installation, use, and maintenance of the Blazor. ■ ALWAYS: ♦ Connect to a grounded circuit. ♦ Connect to operating voltages as specified on the product's spec sticker. ♦... -
Page 6: Introduction
Introduction 2. Introduction Product Overview EU power connectors Name Name Power in/out Menu buttons IR sensor 3-pin DMX in/out Fuse holder Lens Display Barrel LED indicators Easy access door Safety loop Blazor User Manual Rev. 1... -
Page 7: Product Dimensions
Introduction Product Dimensions 11.8 in 300 mm 13.4 in 340 mm 4.3 in 110 mm Blazor User Manual Rev. 1... -
Page 8: Setup
It is possible to link up to 3 Blazor products on 120 VAC or up to 5 products on 230 VAC. The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, consult with the local Chauvet distributor as power linking connectors and requirements may differ by country or region. -
Page 9: Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The Blazor may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming. -
Page 10: Gobo Wheels
Gobo Wheels Replacing Gobos Gobos in the Blazor can be changed using the easy-access gobo door on side of the fixture. To remove and replace gobos in the Blazor: 1. Loosen the two screws holding the easy-access gobo door. Remove the door to gain access to the gobo wheel. -
Page 11: Operation
Press to scroll down the list of options or to find a lower value <ENTER> Press to activate a menu option or a selected value Menu Map Refer to the Blazor product page on www.chauvetdj.com for the latest menu map and software. Mode... -
Page 12: Dmx Configuration
DMX Configuration The Blazor works with a DMX controller. Information about DMX is in the Chauvet DMX Primer, which is available from the Chauvet website chauvetlighting.com/downloads/DMX_Primer_rev05_WO.pdf. Personality and Starting Address The Blazor uses up to 11 DMX channels in the 11 DMX mode, which defines the highest configurable address to 502. -
Page 13: Dmx Channel Assignments And Values
Alternating clockwise-counterclockwise, slow to 223 255 fast 001 086 Mirror rotation, clockwise, slow to fast 087 129 Stop – Mirror rotation 130 222 Mirror rotation, counter-clockwise, slow to fast 223 255 Mirror bounce, slow to fast Blazor User Manual Rev. 1... - Page 14 129 255 Pan bounce, slow to fast 000 095 No function 096 103 Pan reset 104 111 Tilt reset Control 112 119 Color wheel reset 120 127 Gobo wheel reset 128 151 All reset 152 255 No function Blazor User Manual Rev. 1...
-
Page 15: Standalone Configuration
DMX controller. Products in standalone mode may transmit DMX signals that could interfere with the DMX signals from the controller. Auto Programs To run the Blazor with an Auto program, follow the instructions below. 1. Press <MENU> repeatedly until P-- shows on the display. 2. Press <ENTER>. -
Page 16: Gobo Rotation
To set the gobo rotation speed, do the following: 1. Press <MENU> repeatedly until rGob shows on the display. 2. Press <ENTER>. 3. Press <ENTER> to select from N000 (no function) to N100 (highest speed). 4. Press <ENTER>. Blazor User Manual Rev. 1... -
Page 17: Irc-6 Infrared Remote Control
Operation IRC-6 Infrared Remote Control The Blazor is compatible with the IRC-6 infrared remote control from Chauvet. To enable or disable IRC-6 functionality, do the following: 1. Press <MENU> repeatedly until SEt shows on the display. 2. Press <ENTER>. 3. Press <ENTER> to select from on (enable), or oFF (disable). -
Page 18: Master/Slave Mode
Operation Master/Slave Mode The Master/Slave mode allows a single Blazor product (the “master”) to control the actions of one or more Blazor products (the “slaves”) without the need of a DMX controller. The master product will be set to operate in either standalone mode or with the IRC-6, while the slave products will be set to operate in slave mode. -
Page 19: Maintenance
(needle tip applier recommended). Make sure the gobo holder is rotating freely and is not making any abnormal noise. 8. Reinstall the gobos in the gobo holder. Make sure the gobos are in the correct positions. 9. Reinstall the gobo holder in the unit. Blazor User Manual Rev. 1... -
Page 20: Technical Specifications
115 W 50,000 hours Thermal Maximum External Temperature Cooling System 104 °F (40 °C) Fan-assisted convection I/O Connector Channel Range 3-pin XLR 4 or 11 Ordering Product Name Item Code UPC Number Blazor 07052549 781462228972 Blazor User Manual Rev. 1... -
Page 21: Contact Us
For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. Blazor User Manual Rev. 1...
