Summary of Contents for Chauvet DJ EZLink Wedge Q3BT ILS

  • Page 1 User Manual...
  • Page 2: Edition Notes

    Edition Notes The EZLink Wedge Q3BT ILS User Manual includes a description, safety precautions, installation, programming, operation, and maintenance instructions for the EZLink Wedge Q3BT ILS as of the release date of this edition. Trademarks Chauvet, Chauvet DJ, the Chauvet logo, and EZLink are registered trademarks or trademarks of Chauvet &...
  • Page 3: Table Of Contents

    Sound Sensitivity ..................... 13 IRC-6 Infrared Remote Control ..............Bluetooth Control ..................Master/Slave Mode ..................D-Fi USB Master/Slave Mode ............... ILS Mode....................... 5. Maintenance..................Product Maintenance ..................6. Technical Specifications..............Contact Us....................Warranty & Returns..................EZLink Wedge Q3BT ILS User Manual Rev. 1...
  • Page 4: Before You Begin

    Important installation or configuration information. The product may not function correctly if this information is not used. Useful information. EZLink Wedge Q3BT ILS User Manual Rev. 1...
  • Page 5: Safety Notes

    ♦ Set this product on a flammable surface. Keep this User Manual for future use. If the product is sold to someone else, be sure that they also receive this document. EZLink Wedge Q3BT ILS User Manual Rev. 1...
  • Page 6: Battery Charge Notes

    This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and the user. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. EZLink Wedge Q3BT ILS User Manual Rev. 1...
  • Page 7: Introduction

    Safety cable pass-through Power switch 3-pin DMX in/out Power in/out WARNING! DO NOT plug anything other than a D-Fi USB into the USB type B port. Doing so may cause damage to the product. EZLink Wedge Q3BT ILS User Manual Rev. 1...
  • Page 8: Product Dimensions

    Introduction Product Dimensions 4.3 in 108mm 6.3 in 161 mm 4.7 in 120 mm 4.3 in 109 mm 4.3 in 109 mm EZLink Wedge Q3BT ILS User Manual Rev. 1...
  • Page 9: Setup

    3. Setup AC Power The EZLink Wedge Q3BT ILS has an auto-ranging power supply and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart.
  • Page 10: Power Linking

    It is possible to link up to 16 EZLink Wedge Q3BT ILS products on 120 VAC or up to 23 products on 230 VAC. The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, consult with the local Chauvet distributor as power linking connectors and requirements may differ by country or region.
  • Page 11: Battery Power

    Charging the Battery The battery charges whenever the EZLink Wedge Q3BT ILS is plugged into a power source using the included power cable. If the product is plugged in and not in operation, make sure the product is turned off.
  • Page 12: Mounting

    Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The EZLink Wedge Q3BT ILS may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming.
  • Page 13: Operation

    DMX_Primer_rev05_WO.pdf. Personality and Starting Address The EZLink Wedge Q3BT ILS uses up to 8 DMX channels in the DMX mode, which defines the highest configurable/recommended address to 505. When selecting a starting DMX address, always consider the number of DMX channels the DMX mode uses.
  • Page 14: D-Fi Usb Connectivity

    D-Fi USB Connectivity The EZLink Wedge Q3BT ILS is able to become a D-Fi wireless receiver/transmitter with the use of the D- Fi USB from Chauvet DJ. Simply set the product's DMX Personality and DMX Address, set the DIP switch D-Fi receiving/transmitting channel, then plug it into the D-Fi USB port.
  • Page 15: Dmx Charts

    158  208 Auto program 4 209  255 Auto program 5 000  250 Program speed, slow to fast – Auto program speed 251  255 Sound-active Mode – Dimmer 000  255 0–100% EZLink Wedge Q3BT ILS User Manual Rev. 1...
  • Page 16: Standalone Configuration

    DMX signals from the controller. Preset Color Mode To run the EZLink Wedge Q3BT ILS on a static color, follow the instructions below: 1. Press <MENU> repeatedly until C-- shows on the display. 2. Press <ENTER>.
  • Page 17: Irc-6 Infrared Remote Control

    The buttons on the IRC-6 not listed above are reserved for future use. Bluetooth Control Bluetooth control mode allows users to control one or more EZLink Wedge Q3BT ILS products via Bluetooth connection on the BTAir app. To operate the product via Bluetooth control mode: 1.
  • Page 18: Master/Slave Mode

    D-Fi USB Master/Slave Mode The D-Fi USB allows a single EZLink Wedge Q3BT ILS product (the “master”) to control the actions of one or more EZLink Wedge Q3BT ILS products (the “slaves”) without the need of a DMX controller or DMX cables.
  • Page 19: Ils Mode

    This product will synchronize with the par effect on the selected side of the GigBAR MOVE+ILS, as well as the laser and strobes. To set the EZLink Wedge Q3BT ILS to respond to an ILS signal: 1. Press <MENU> repeatedly until iLS_ shows on the display.
  • Page 20: Maintenance

    6. Softly drag any dirt or grime to the outside of the transparent surface. 7. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. EZLink Wedge Q3BT ILS User Manual Rev. 1...
  • Page 21: Technical Specifications

    Maximum External Temperature Cooling System 104 °F (40 °C) Convection I/O Connector Channel Range 3-pin XLR 4Ch or 8Ch Ordering Product Name Item Code UPC Number EZLink Wedge Q3BT ILS 10031971 781462223199 EZLink Wedge Q3BT ILS User Manual Rev. 1...
  • Page 22: Contact Us

    For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. EZLink Wedge Q3BT ILS User Manual Rev. 1...
