EGLO Lighting has a policy of continual product improvement and development, dimensions, hardware and designs may change to reflect this policy. EGLO reserves the right to discontinue or change product specifications & designs at any time without notice and without incurring obligations. The images including all features and specifications in this manual are for illustrative purposes only.
Page 3
Congratulations Congratulations on the purchase of your new EGLO ceiling fan, your EGLO ceiling fan will improve your comfort every day, for many years to come. This manual is designed to make installation as simple as possible and will help guide you through the assembly and installation of your new ceiling fan, as well as provide valuable safety information about your fan‘s installation, and operation.
Table of Contents FOR YOUR SAFETY: ............................5 BEFORE INSTALLATION: WHAT COMES IN YOUR BOX ........................6 TOOLS NEEDED TO COMPLETE YOUR INSTALLATION ................6 CHOOSING THE RIGHT LOCATION ......................7 MOUNTING OPTIONS ..........................7 ASSEMBLY & INSTALLATION: HANGING THE FAN ..........................8 MAKING THE ELECTRICAL CONNECTIONS ...................9 FINISHING THE CANOPY INSTALLATION ....................10 BLADES ASSEMBLY ..........................11 INSTALLING THE FAN CAP ........................11...
19. Do NOT allow children to play with this appliance and always supervise children around electrical devices. 20. EGLO USA will not be liable for any advice given to the consumer from any 3rd parties including suppliers, retailers & electricians.
• Check that all parts are present before commencing assembly. Refer to Parts List. • If any parts are missing, carefully check the eco friendly packaging for the missing parts, and if they cannot be located, contact EGLO for assistance before commencing assembly or installation. O FF Tools needed to complete your installation •...
Option 3: Recessed outlet box mounted to Joist on angled ceiling. (Fig. 3) NOTE: Angled ceiling maximum 12° angle. For mounting on Recessed ceilings above 12° angle, you will need an EGLO Sloped Ceiling outlet box Canopy (sold separately). You may also need a longer downrod...
Installation Warning! WARNING: To avoid possible electric shock, before installing your fan, disconnect the power by turning off the circuit breakers to the outlet box associated with the wall switch location. Hanging the fan Fig. 5 Step 1. Pass the 120-volt supply wires through the center hole in the ceiling mounting bracket as shown in (Fig.
Making the electrical connections Your EGLO fan is supplied with 40” lead wires to enable use with up to 36” downrods (sold separately). Should you not require the full length of lead wire, carefully cut all wires ensuring there is sufficient to properly complete the installation.
Installation Making the electrical connections Fig. 9 Black Black Black Black CE-2 Blue Black White Blue White Black Green/Yellow CE-2 Light Switch Earth Blue Finishing the canopy installation Step 12: Tuck all connections neatly into the ceiling outlet box. Fig. 10 Step 13: Partially remove the two screws on the underside of the ceiling mounting bracket.
Installation Blade assembly Step 16: Working one blade at a time, place the blade into the slot in Fig. 11 the motor housing center band, and insert and tighten each blade screw loosely. When all blades are installed, tighten all screws firmly and evenly.
Installation Light assembly For models with LED light: Fig. 13 Step 18: Attach the light plate (shade ring) by aligning with the slotted holes in the bottom of the fan and push in until all clips click. (Fig. 13) Step 19: Align the light shade with the light plate, push the shade on, and twist the lamp shade until secure.
Operation Operating your new fan Turn the power back on by turning on the circuit breakers to the outlet box associated with the wall switch location and check the operation of your new fan. The wall control included with your new fan operates the fan speeds, and the light on models with light: Fan controls: - Fan off...
There is no need to oil your fan. The motor has permanently lubricated bearings. Cleaning All EGLO ventilation products should be cleaned regularly to insure against corrosion from salt, dust and moisture, both externally and internal (where allowed and possible). Cleaning your fan periodically will help maintain its appearance over the years.
Technical information To maximize energy savings, select a fan with a high airflow efficiency, and always turn fans off when you leave the room. • Ceiling fan airflow is measured in cubic feet per minute (CFM). • Power use is measured in watts (W). •...
Troubleshooting PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Fuse or circuit breaker blown. Turn power OFF. Check main and branch circuit fuses and circuit breakers. Loose connections. Turn power OFF. Check line wire connections to the fan and switch wire connections to fan are properly connected.
Light Kits / Included Lights – Warranty May Vary Except as otherwise stated within this warranty, if any part of your EGLO light kit, or included light fails due to a defect in material or workmanship, it is covered under EGLO’s one (1) year warranty. If your LED light module (not including glass components) or LED bulb fails at any time within five (5) years of the date of purchase due to a defect in material or workmanship, as determined solely by EGLO, EGLO will repair the part or provide you with a replacement part free of charge.
• Commercial use - EGLO products which are specifically designed for commercial use are designated as Commercial Use Products on the product packaging. All other EGLO products are designed for domestic use only. This fan is not designed or warranted for commercial applications unless authorized in writing by an EGLO FAN MANAGER.
DATE OF PURCHASE: PURCHASE PRICE: SERIES NAME: MODEL NUMBER: RECEIPT / PURCHASE NUMBER: RETAILER NAME: RETAILER ADDRESS: RETAIL ASSISTANT: SIGNATURE: DATE: EGLO USA INC.: 3640 Royal South Parkway, ATLANTA, GEORGIA 30349 Phone: +1 404 477 5601, Email: info-usa@eglo.com SWIFTSURE Ceiling Fan...
Page 20
RECIBO / PURCHASE NUMBER: NOMBRE DE TIENDA: DIRECCION DE LA TIENDA: ASSISTENTE EN LA TIENDA: FIRMA: FECHA: EGLO USA INC.: 3640 Royal South Parkway, ATLANTA, GEORGIA 30349 Teléfono: +1 404 477 5601, Correo electrónico: info-usa@eglo.com Ventiladores de techo SWIFTSURE ES 19...
Page 21
Uso comercial: los productos EGLO que están diseñados específicamente para uso comercial están designados como Productos de uso comercial en el empaque del producto. Todos los demás productos EGLO están diseñados únicamente para uso doméstico. Este ventilador no está diseñado ni garantizado para aplicaciones comerciales a menos que lo autorice por escrito el ADMINISTRADOR DEL VENTILADOR DE EGLO.
Page 22
Salvo que se indique lo contrario dentro de esta garantía, si alguna parte de su equipo de iluminación EGLO, o luz incluida falla debido a un defecto en el material o la mano de obra, está cubierto por la garantía de un (1) año de EGLO.Si su módulo de luz LED (sin incluir componentes de vidrio) o bombilla LED falla en cualquier momento dentro de los cinco (5) años posteriores a la...
Solución de problemas PROBLEMA CAUSA POSIBLE POSIBLE REMEDIO Fusible o circuito fundido. Apague la alimentación. Compruebe los fusibles del circuito principal y de derivación y los disyuntores. Conexiones sueltas. Apague la alimentación. Compruebe que las conexiones de cable de línea al ventilador y las conexiones de cable del interruptor al ventilador estén conectadas correctamente.
Información técnica Para maximizar el ahorro de energía, seleccione un ventilador con una alta eficiencia de flujo de aire y siempre apague los ventiladores cuando salga de la habitación. El flujo de aire del ventilador de techo se mide en pies cúbicos por minuto (CFM). •...
Limpieza Todos los productos de ventilación EGLO deben limpiarse regularmente para asegurar contra la corrosión de la sal, el polvo y la humedad, tanto externa como interna (cuando esté permitido y sea posible). Limpiar su ventilador periódicamente ayudará a mantener su apariencia a lo largo de los años.
Page 26
Operacion Operacion Tu nuevo Ventilador Vuelva a encender los disyuntores en la caja de tomacorrientes asociada con la ubicación del interruptor de pared y verifique el funcionamiento de su nuevo ventilador. El control de pared incluido con su nuevo ventilador opera las velocidades del ventilador y la luz en los modelos con luz: Controles del ventilador: - Ventilador apagado.
Instalación Configurar el color de la luz Fig. 15 Para los modelos con luz LED, puede seleccionar el color de luz que desee utilizando el conveniente interruptor DIP ubicado en la placa LED. (Figura 15) Asegurándose de que la alimentación no esté conectada, ubique el interruptor DIP CCT en la placa de LED y seleccione el color deseado: 2700K, 3000K o 4000K.
Page 28
Instalación Conjunto de cuchillas Nota: Retire topes de goma del motor ANTES de colocar las cuchillas y/o Fig. 11 los soportes de las mismas. Paso 16: Trabajando una hoja a la vez, coloque la hoja en la ranura de la banda central de la carcasa del motor e inserte y apriete cada tornillo de la hoja sin apretar.
Page 29
Instalación Haciendo de las conexiones eléctricas Fig. 9 Black Black Black Black CE-2 Blue Black White Blue White Black Green/Yellow CE-2 Light Switch Earth Blue Finalización de la instalación del dosel Paso 12: Introduzca cuidadosamente todas las conexiones en la Fig.
Page 30
Haciendo de las conexiones eléctricas Su ventilador EGLO se suministra con cables conductores de 40” para permitir el uso con varillas descendentes de hasta 36” (se venden por separado). Si no necesita toda la longitud del cable conductor, corte con cuidado todos los cables asegurándose de que haya suficiente para completar correctamente la instalación.
Instalación Advertencia! Para evitar una posible descarga eléctrica, antes de instalar ADVERTENCIA: ventilador, desconecte la alimentación apagando los disyuntores de la caja de salida asociada con la ubicación del interruptor de pared. Colgar el ventilador Fig. 5 Paso 1. Pase los cables de alimentación de 120 voltios a través del orificio central en el soporte de la suspensión del techo como se muestra en la Figura 5.
ángulo de más de 12°, necesitará un dosel de techo inclinado EGLO. También es posible que necesite una varilla descendente más larga para mantener la holgura adecuada de la hoja cuando se instala en un techo inclinado pronunciadamente.
• Compruebe que todas las piezas están presentes antes de comenzar el montaje. Consulte Lista de piezas.Si falta alguna pieza, revise cuidadosamente el embalaje ecológico y las bolsas para ver si faltan las piezas, y si no se pueden localizar, comuníquese con EGLO para obtener ayuda antes de comenzar el ensamblaje o la instalación...
11.ADVERTENCIA: Para reducir el riesgo de descargas eléctricas e incendios, no utilice este ventilador con ningún dispositivo de control de velocidad del ventilador de estado sólido. Instale y opere SOLO el controlador EGLO suministrado con su ventilador, o un controlador EGLO adecuado diseñado específicamente para su ventilador.
Page 35
Tabla de contenidos PARA SU SEGURIDAD: ................................ANTES DE LA INSTALACIÓN: LO QUE VIENE EN LA CAJA: ............................. HERRAMIENTAS NECESARIAS PARA COMPLETAR LA INSTALACIÓN: ..............ELEGIR LA UBICACIÓN CORRECTA: ......................... OPCIONES DE MONTAJE: ............................IINSTALACIÓN: COLGAR EL VENTILADOR: ............................HACIENDO LAS CONEXIONES ELÉCTRICAS: ......................
Page 36
Cuidar su entorno La caja de cartón y el embalaje interior de su nuevo ventilador de techo EGLO están fabricados con materiales reciclables respetuosos con el medio ambiente, que puede reciclar a través de su servicio de recogida en la acera o a través de programas comunitarios locales.
Page 37
EGLO Lighting tiene una política de mejora y desarrollo continuos de sus productos, las dimensiones, el hardware y los di- seños pueden cambiar para reflejar esta política. EGLO se reserva el derecho a interrumpir o cambiar las especificaciones y diseños de los productos en cualquier momento sin previo aviso y sin incurrir en obligaciones. Las imágenes que incluyen todas las características y especificaciones de este manual tienen únicamente fines ilustrativos.
Page 38
SWIFTSURE Guía del propietario - (ESPAÑOL) Seguridad Instalación Funcionamiento Técnica Garantia Modelos sin luz: 235040-52yyA Modelos LED: 235041-52yyA (yy = color code)
