Maxim Lighting Falcon Manual

52” 3-blade fan

Advertisement

Quick Links

Item / Model Number:
88708
Falcon 52" 3-Blade Fan
Lamping | Ampoule: 1 x 18W LED (included)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Falcon and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxim Lighting Falcon

  • Page 1 Item / Model Number: 88708 Falcon 52” 3-Blade Fan Lamping | Ampoule: 1 x 18W LED (included)
  • Page 2: Safety Instructions

    Safety Instructions: READ ALL SAFETY INFORMATION AND INSTALLATION INSTRUCTIONS BEFORE YOU BEGIN INSTALLING THE FAN. IF YOU ARE NOT FAMILIAR WITH NATIONAL AND LOCAL ELECTRI- CAL CODES AND BASIC ELECTRICAL WIRING PROCEDURES WE RECOMMEND THAT YOU HAVE A QUALIFIED ELECTRICIAN INSTALL YOUR NEW CEILING FAN. SAVE INSTRUCTIONS. •...
  • Page 3: Tools Required

    Tools Required: Screw Package Included: Screw Package Quantity S1. Blade Screws 2 Each Per Fan Blade S2. Machine Screws S3. Wood Screws S4. Washers S5. Lock Washers S6. Star Washers S7. Wire Nuts S8. Balance Kit Fan Parts Included: Hanging Bracket Down Rod Canopy Canopy Ring...
  • Page 4: Fan Diagram

    Fan Diagram Hanging Bracket Down Rod Ball Assembly Down Rod Hairpin Clip Safety Pin Ceiling Canopy Canopy Ring Down Rod Coupler Cover Fan Blades Motor Assembly Blade Disk Junction Box Blade Screws LED Module Lamp Panel Lamp Shade page 3 of 10...
  • Page 5: Installation Instructions

    Warning: • To reduce the risk of fire, electrical shock, or personal injury, mount this fan to an outlet box marked “Acceptable for Fan Support of 22.7 kg (50 lbs) ” or less and use Mounting Screws provided with the outlet box. CAUTION: Install the primary mounting means and use only the hardware provided with the fan.
  • Page 6: Step 2 Suspension Installation

    Step 2 Suspension Installation 1. Loosen the set screws (2) in the down rod coupler until the inside tunnel is clear. 2. Remove the hairpin clip and safety pin at the end of the down rod, Slide the ceiling canopy and canopy ring onto the down rod, followed by the down rod coupler cover.
  • Page 7: Step 4 Making Electrical Connections

    Step 3 Hanging Fan Body Using a step ladder carefully lift the fan and seat the down rod ball assembly on the hanging bracket. Rotate fan so that down rod ball assembly notch engages with the Hanging Bracket hanging bracket groove.(See Step 3.1) Hanging Bracket Down Rod Groove...
  • Page 8: Step 6 Canopy Installation

    Step 6 Canopy Installation 1. Align the screw holes on the bottom of Hanging Bracket and the Ceiling Canopy, put in the screws and tighten them.(See Step 6.1) 2. Cover the screw head with the slot in the Canopy ring, and rotate the Canopy ring to tighten it.(see Step 6.2) Hanging Bracket Canopy Ring Ceiling Canopy...
  • Page 9 Step 8 Light Assembly Installation 1. Connect the Light wires plug and socket (2 pins) . 2. Align the screw holes of Junction Box and Lamp Panel, insert 3 screws with fingers,and tighten them securely with a Phillips screwdriver. Junction Box Lamp Panel Step 9 Lamp Shade Installation The LED module is pre-installed on the Lamp Panel .
  • Page 10 10.4 & 10.5 Secure the wall-mounted control to the outlet box with two screws provided. Secure the face plate over the wall control with two screws provided. Wall-Mounted Control Function: • Push the light switch upward to brighten the lightness. •...
  • Page 11: Troubleshooting Guide

    Trouble shooting Guide: If you have di culty oprtating your new ceiling fan it may be the result of incorrect assembly,installation,or wiring.In some cases these installation errors may be mistaken for defects. If you experience any faults please check this troubleshooting guide. Problem Suggested Remedy: Check main and branch circuit fuses or circuit breakers.

This manual is also suitable for:

8870888708bk88708mw88708sn88708bkwn
