- Page 1 Home Appliances KF-66DVDD04BM1K-EN KF-66DVDD04IM1K-EN Cooking User Manual...
- Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...
-
Page 3: Table Of Contents
CONTENTS 1.SAFETY INSTRUCTIONS ....................4 1.1 General Safety Warnings ....................4 1.2 Installation Warnings ...................... 7 1.3 During Use........................7 1.4 During Cleaning and Maintenance ................. 9 2.INSTALLATION AND PREPARATION FOR USE .............11 2.1 Instructions for the Installer ...................11 2.2 Electrical Connection and Safety.................. 12 2.3 Anti-tilting kit ......................... -
Page 4: Safety Instructions
1. SAFETY INSTRUCTIONS • Carefully read all instructions before using your appliance and keep them in a convenient place for reference when necessary. • This manual has been prepared for more than one model therefore your appliance may not have some of the features described within. - Page 5 WARNING: Danger of fire: Do not store items on the cooking surfaces. WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock. • For models which incorporate a hob lid, clean any spillages off the lid before use and allow the cooker to cool before closing the lid.
- Page 6 applicable local and international standards and regulations. • Maintenance and repair work should only be carried out by authorised service technicians. Installation and repair work that is carried out by unauthorised technicians may be dangerous. Do not alter or modify the specifications of the appliance in any way.
-
Page 7: Installation Warnings
• Please keep children and animals away from this appliance. 1.2 inStallation WarninGS • Do not operate the appliance before it is fully installed. • The appliance must be installed by an authorised technician. The manufacturer is not responsible for any damage that might be caused by incorrect placement and installation by unauthorised people. - Page 8 • Take care when opening the oven door during or after cooking. The hot steam from the oven may cause burns. • Do not put flammable or combustible materials in or near the appliance when it is operating. • Always use oven gloves to remove and replace food in the oven.
-
Page 9: During Cleaning And Maintenance
• Do not place heavy or flammable items (e.g. nylon, plastic bags, paper, cloth, etc.) into the drawer. This includes cookware with plastic accessories (e.g. handles). CAUTION: The inside surface of the storage compartment may get hot when the appliance is in use. -
Page 10: Disposal Of Your Old Machine
Disposal of your old machine This symbol on the product or on its packaging indicates that this product should not be treated as household waste. Instead it should be handed over to the applicable collection point for the recycling of electrical and electronic equipment. -
Page 11: Installation And Preparation For Use
2. INSTALLATION AND dryer. PREPARATION FOR USE • The appliance can be placed close to other furniture on condition that, in the WARNING : This appliance must be area where the appliance is set up, the installed by an authorised service furniture’s height does not exceed the person or qualified technician, height of the cooktop. -
Page 12: Electrical Connection And Safety
2.2 eleCtriCal ConneCtion anD Safety • If the appliance is not connected to the mains with a plug, a all-pole WARNING: The electrical connection disconnector (with at least 3 mm contact of this appliance should be carried out spacing) must be used in order to meet by an authorised service person or the safety regulations. -
Page 13: Anti-Tilting Kit
• For this connection, a ‘Twin and Earth Product Dimensions 6242Y’ type cable should be used. A (mm) B (mm) (Width X Depth X Height) (Cm) 60x60x90 (Double Oven) 297.5 50x60x90 (Double Oven) 247.5 90x60x85 60x60x90 309.5 60x60x85 309.5 50x60x90 247.5 50x60x85 247.5... -
Page 14: Product Features
3. PRODUCT FEATURES Important: Specifications for the product vary and the appearance of your appliance may differ from that shown in the figures below. List of Components 1. Cooktop 2. Control Panel 3. Top Oven Door Handle 4. Top Oven Door 5. -
Page 15: Use Of Product
4. USE OF PRODUCT decreased or until one of the cooking zones is activated. 4.1 hob ControlS Hints and Tips Ceramic Heater Important: When ceramic heaters are The ceramic heater is controlled by a 6 operated in higher heat settings, the position knob. - Page 16 well away from the hob during operation to cook on only one shelf at a time in this and until it has fully cooled after function. operation. Fan Function: Switch on the FAN function • If you notice a crack on the cooktop, using the main oven it must be switched off immediately control knob.
-
Page 17: Use Of The Digital Touch Timer
4.2 uSe of the DiGital touCh tiMer Upper Heating Function: Switch on the UPPER function using the top oven function control knob. The oven thermostat and warning lights will illuminate, and the upper heating element will switch on. The temperature setting will set to the highest level for this function. - Page 18 Semi-automatic time adjustment (cooking period) 3. After a few seconds, the dot will This function helps you to cook for a fixed stop flashing and will period of time. A time range between 0 and remain illuminated. 10 hours can be set. Prepare the food for cooking and put it in the oven.
- Page 19 cloth on first use. • The accessories may deform with heat. Once they have cooled down, they will recover their original appearance and performance. • Trays and wire grids can be positioned on any level from 1 to 5. • Telescopic rails can be positioned on levels T1, T2, 3, 4, 5.
-
Page 20: Cleaning And Maintenance
Cleaning the Ceramic Glass Ceramic glass can hold heavy utensils but may be broken if it is hit with a sharp object. 5. CLEANING AND WARNING : Ceramic Cooktops - if the MAINTENANCE... - Page 21 glass will not affect the structure or surface-damaging dish sponge) or durability of the ceramic and is not due cleaning agents containing high levels to a change in the material. of alcohol, stain removers, degreasers, surface abrasive chemicals. Otherwise, Colour changes to the ceramic glass may corrosion may occur on the powder be for a number of reasons: painted surfaces, and stains may occur.
-
Page 22: Maintenance
must remove the oven door, as shown Removal of the Wire Shelf below. To remove the wire rack, pull the wire rack as shown in the figure. After releasing it 1. Open the oven door. from the clips (a), lift it up. 2. -
Page 23: Troubleshooting&Transport
6. TROUBLESHOOTING&TRANSPORT 6.1 troubleShootinG If you still have a problem with your appliance after checking these basic troubleshooting steps, please contact an authorised service person or qualified technician. Problem Possible Cause Solution Check the household fuse for the appliance. The hob or cooking zones There is no power supply. -
Page 24: Technical Specifications
7. TECHNICAL SPECIFICATIONS 7.1 enerGy fiChe Brand Model KF-66DVDD04BM1K-EN KF-66DVDD04IM1K-EN Type of Oven ELECTRIC Mass 50,2 Energy Efficiency Index - conventional 105,1 Energy Efficiency Index - fan forced Energy Class Energy consumption (electricity) - conventional kWh/cycle 0,75 Energy consumption (electricity) - fan forced... - Page 25 Brand Model KF-66DVDD04BM1K-EN KF-66DVDD04IM1K-EN Type of Hob Electric Number of Cooking Zones Heating Technology-1 Radiant Size-1 Ø14,5 Energy Consumption-1 Wh/kg 192,0 Heating Technology-2 Radiant Size-2 Ø14,5 Energy Consumption-2 Wh/kg 192,0 Heating Technology-3 Radiant Size-3 Ø18,0 Energy Consumption-3 Wh/kg 192,0 Heating Technology-4...
- Page 26 Service & Support Visit Our Website www.sharphome.eu UK Technical Support - Large Appliances helpdesk.GB@sharphomeappliances.com 0333 5777230 Republic Of Ireland Technical Support– Large Appliances helpdesk.GB@sharphomeappliances.com 03335 777230 VESTEL Holland B.V. UK Branch, 1 Waterside Drive, Langley, Berkshire. SL3 6EZ VESTEL Holland B.V. Stationsplein 45, A2.191 3013 AK Rotterdam, The Netherlands.
