- Page 1 Home Appliances KF-66DVDD05WL1-EN KF-66DVDD05BL1-EN KF-66DVDD05SL1-EN Cooking User Manual...
- Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...
-
Page 3: Table Of Contents
CONTENTS 1.SAFETY INSTRUCTIONS ....................4 1.1 General Safety Warnings ....................4 1.2 Installation Warnings ......................7 1.3 During Use ........................7 1.4 During Cleaning and Maintenance .................9 2.INSTALLATION AND PREPARATION FOR USE ............11 2.1 Instructions for the Installer ..................11 2.2 Electrical Connection and Safety..................12 2.3 Anti-tilting kit .........................13 2.4 Adjusting the feet ......................13 3.PRODUCT FEATURES ....................14... -
Page 4: Safety Instructions
1. SAFETY INSTRUCTIONS • Carefully read all instructions before using your appliance and keep them in a convenient place for reference when necessary. • This manual has been prepared for more than one model therefore your appliance may not have some of the features described within. - Page 5 WARNING: Danger of fire: Do not store items on the cooking surfaces. WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock. • For models which incorporate a hob lid, clean any spillages off the lid before use and allow the cooker to cool before closing the lid.
- Page 6 applicable local and international standards and regulations. • Maintenance and repair work should only be carried out by authorised service technicians. Installation and repair work that is carried out by unauthorised technicians may be dangerous. Do not alter or modify the specifications of the appliance in any way.
-
Page 7: Installation Warnings
1.2 inStallation WarninGS • Do not operate the appliance before it is fully installed. • The appliance must be installed by an authorised technician. The manufacturer is not responsible for any damage that might be caused by incorrect placement and installation by unauthorised people. •... - Page 8 • Take care when opening the oven door during or after cooking. The hot steam from the oven may cause burns. • Do not put flammable or combustible materials in or near the appliance when it is operating. • Always use oven gloves to remove and replace food in the oven.
-
Page 9: During Cleaning And Maintenance
• Do not place heavy or flammable items (e.g. nylon, plastic bags, paper, cloth, etc.) into the drawer. This includes cookware with plastic accessories (e.g. handles). CAUTION: The inside surface of the storage compartment may get hot when the appliance is in use. -
Page 10: Installation And Preparation For Use
Disposal of your old 2. INSTALLATION AND PREPARATION FOR USE machine WARNING : This appliance must be This symbol on the installed by an authorised service person or qualified technician, product or on its according to the instructions in this guide and in compliance with the current local packaging regulations. -
Page 11: Electrical Connection And Safety
Installation of the Cooker • If the kitchen furniture is higher than the cooktop, the kitchen furniture must be at least 10 cm away from the sides of appliance for air circulation. A (mm) Cupboard • If a cooker hood or cupboard is to be B (mm) Cooker Hood 650/700 installed above the appliance, the safety... -
Page 12: Anti-Tilting Kit
• Ensure all connections are adequately tightened. • Fix the supply cable in the cable clamp and then close the cover. Wall Anti- • The terminal box connection is placed tilting bracket on the terminal box. • Green/Yellow (Earth) wire to the terminal marked "PE". -
Page 13: Product Features
3. PRODUCT FEATURES Important: Specifications for the product vary and the appearance of your appliance may differ from that shown in the figures below. List of Components 1. Cooktop 2. Control Panel 3. Top Oven Door Handle 4. Top Oven Door 5. -
Page 14: Use Of Product
4. USE OF PRODUCT decreased or until one of the cooking zones is activated. 4.1 hob ControlS Hints and Tips Ceramic Heater Important: When ceramic heaters are The ceramic heater is controlled by a 6 operated in higher heat settings, the position knob. -
Page 15: Main Oven Functions
well away from the hob during operation upper heating elements within the oven and until it has fully cooled after while the fan provides air circulation, operation. dispersing the heat and giving the food a slightly grilled effect. It is recommended you •... - Page 16 seconds. The desired operation can then be carried out. Function Description Audible warning time adjustment The audible warning time can be set to any Auto cooking time between “00:00” and “23:59” hours. The audible warning time is for warning Manual cooking purposes only.
- Page 17 4. The current time will 3. Select the desired reappear on the cooking time period screen, the symbols using the “+” and “-” “A” and “ ” will remain keys. illuminated. 4. The current time will When the timer reaches zero, the oven reappear on the will switch off and an audible warning will screen, and the...
-
Page 18: Accessories
5. Select the desired 4.3 aCCeSSorieS finishing time using the “+” and “-” keys. “ ” The Wire Grid for Deep Trays symbol will disappear. Make sure the wire grid is correctly placed Add the cooking period within a deep tray. It is recommended to the current time of to use this accessory for grilling steaks, day. -
Page 19: Cleaning And Maintenance
Cleaning the Ceramic Glass Ceramic glass can hold heavy utensils but may be broken if it is hit with a sharp object. 5. CLEANING AND WARNING : Ceramic Cooktops - if the MAINTENANCE... - Page 20 to a change in the material. of alcohol, stain removers, degreasers, surface abrasive chemicals. Otherwise, Colour changes to the ceramic glass may corrosion may occur on the powder be for a number of reasons: painted surfaces, and stains may occur. 1.
-
Page 21: Maintenance
below. 5.2 MaintenanCe 1. Open the oven door. WARNING: The maintenance of this appliance should be carried out by an authorised service person or qualified technician only. Changing the Oven Lamp WARNING: Switch off the appliance and allow it to cool before cleaning your appliance. -
Page 22: Troubleshooting&Transport
6. TROUBLESHOOTING&TRANSPORT 6.1 troubleShootinG If you still have a problem with your appliance after checking these basic troubleshooting steps, please contact an authorised service person or qualified technician. Problem Possible Cause Solution Check the household fuse for the appliance. The hob or cooking zones There is no power supply. -
Page 23: Technical Specifications
7. TECHNICAL SPECIFICATIONS 7.1 enerGy fiChe Brand Model KF-66DVDD05WL1-EN KF-66DVDD05BL1-EN KF-66DVDD05SL1-EN Type of Hob Electric Number of Cooking Zones Heating Technology-1 Radiant Size-1 Ø14,5 Energy Consumption-1 192,0 Heating Technology-2 Radiant Size-2 Ø14,5 Energy Consumption-2 192,0 Heating Technology-3 Radiant Size-3 Ø18,0... - Page 24 Brand Model KF-66DVDD05WL1-EN KF-66DVDD05BL1-EN KF-66DVDD05SL1-EN Type of Oven ELECTRIC Mass Energy Efficiency Index - conventional Energy Efficiency Index - fan forced Energy Class Energy consumption (electricity) - conventional kWh/ cycle Energy consumption (electricity) - fan forced kWh/ cycle Heat Source...
- Page 25 Service & Support Visit Our Website sharphomeappliances.com 52370715...
