Summary of Contents for HALNy HL-4G2
- Page 1 Quick Installation Guide Quick Installation Guide GPON ONT HALNY HL-4G2...
-
Page 2: Safety Guidance
Quick Installation Guide Safety Guidance 1.1 Safety Check Before installing the device, you must check the following items. 1.1.1 Electric Safety Ensure that there are no inflammable, conductive or moist objects around. Check whether the cables are aged and whether other electrical appliances are placed stably. -
Page 3: Features And Function
Users should assume responsibilities for any accidents due to incompliance with the above instructions. 2 Overview This chapter mainly describes functions and the structure of the HALNy HL-4G2. 2.1 Features and Function Fast rate. Support up to 1.25Gbps uplink and 2.5Gbps downlink data transmission rates. -
Page 4: Front Panel
Quick Installation Guide 2.2.1 Front Panel Fig. 1 - Front Panel Color Status Description The power works normally. POWER Green Powered off or the power supply is abnormal. Refer to Table 2: “PON LED Status Instruction” Green Refer to Table 2: “PON LED Status Instruction” The WAN IP address has been successfully acquired or device has been connected to the Internet access Green... -
Page 5: Rear Panel
Quick Installation Guide 2.2.2 Rear Panel Fig 2. Rear Panel ONU Rear Panel Description Interface / Function Button Ethernet interface, for connecting to a computer or an Ethernet LAN1-4 interface of a switch. Connect power cable Turn on/off the power supply. ON/OFF Table 3.Rear Panel port description 2.2.3... -
Page 6: Installation Preparations
Quick Installation Guide 3 ONU Installation The chapter describes the required installation operations before you use the device for the first time. 3.1 Product Networking Application - FTTH Fiber to the Home (FTTH) means to install the ONU to residences or enterprise buildings. -
Page 7: Connecting The Network Cable
Step 1 Use the one end of the network cable to connect the Ethernet interface of the computer. Step 2 Use other end of a network cable to connect the Ethernet interface on the rear panel of the HALNy HL-4G2. 3.3.2 Connecting the Fiber Caution ... -
Page 8: Troubleshooting
Quick Installation Guide 3.3.3 Connecting the Power Adapter and Power Cord Connect the output end of the power adapter included in the device package to the input end of the power supply of the ONU , Insert one end of the power cord attached with the device into the input end of the power adapter. -
Page 9: Technical Specification
Quick Installation Guide 5 Technical Specification Main Technical Specifications Standard GPON Standard ITU-T G.984.x and G.988 Uplink 1.25Gbps Rate Downlink 2.5Gbps Optical interface Single Mode Interface RJ-45 10/100/1000Mbps MDI/MDIX Self LAN port adaption Physical Characteristics and Environment Requirements Power adapter input 100V～240V AC，50Hz～60Hz Whole-device power supply 12V DC / 1A... -
Page 10: Additional Information
36-062 Zaczernie 190F (POLAND) info@fibrain.pl BDO: 000007477 Information furnished by HALNy Networks is believed to be accurate and reliable. However, no responsibility is assumed by importer for its use, nor for any infringements of patents or other rights of third parties which may result from its use. - Page 11 Quick Installation Guide Recycling This product bears selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled according to European directive 2012/19/EU order recycled dismantled. This will minimize the negative effects on the environment and human health resulting from the possibility of the presence in equipment substances,...
- Page 12 Quick Installation Guide Rev1.4-20241206...
