- Page 1 Double Oven Instruction Manual Model number(s): RH72DEO1001B/01 RH72DEO1002SS/01 IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Safety Instructions ………………………………………. Product Overview ………………………………………. Positioning ………………………………………. Installation ………………………………………. Electrical connection ………………………………………. Usage ………………………………………. 11-22 Cleaning & Maintenance ………………………………………. 23-28 Trouble shooting ………………………………………. Guarantee ………………………………………. Technical specification ………………………………………. -
Page 3: Safety Instructions
Safety Instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand... - Page 4 Safety Instructions • This appliance can only be installed in a well-ventilated place in accordance with existing regulations and ventilation specifications. • This appliance is intended for domestic use and the household environment only. The appliance is not intended for use outside. •...
- Page 5 Safety Instructions • Alcoholic vapours may catch fire in the hot cooking compartment. Never prepare food containing large quantities of drinks with a high alcohol content. Only use small quantities of drinks with a high alcohol content. Open the appliance door with care. •...
-
Page 6: Product Overview
Product overview 1. Top oven function dial 7. Bottom oven temperature dial 2. Top oven temperature dial 8. Oven door handles 3. Top cavity glass window 9. 2 x Wire shelf 4. Bottom cavity glass window 10. 1 x Universal tray & handle 5. -
Page 7: Positioning
Positioning • This appliance is to be installed under a counter top. • Avoid damaging the product during installation. • The appliance can only be used safely if it is correctly installed according to the safety instructions. The installer is responsible for ensuring that the appliance works correct when installed. - Page 8 Installation with brackets • This type of installation may be required if the aperture dimensions are insufficient with the wooden cabinet base fitted or there is no cabinet base. • Remove the wooden cabinet base. • Set the front edge of the brackets 50mm from the front edge of the aperture opening/cabinet.
-
Page 9: Installation
Installation Ensure that there are no electric wires, gas or water pipes in the area where holes are to be made. Components of the appliance may have sharp edges. Wear protective gloves. 1. Ensure that there is an electrical power point within adequate distance of the oven after it has been installed. -
Page 10: Electrical Connection
Electrical connection • WARNING- THIS APPLIANCE MUST BE EARTHED • This appliance is designed to be connected to a 220-240V~50Hz-60Hz AC electricity supply. • Before proceeding with the electrical connection, verify that the current carrying capacity of the system and the isolator / main switch is adequate for the maximum power rating of the oven. -
Page 11: Usage
Usage Control panel The appliance has an oven function dial, temperature dial, a display and mode buttons, these are explained below: Oven function dials The oven function dials allow you to set the oven function mode for the top and/or bottom oven. The dial can be rotated clockwise or anti-clockwise to set the required oven function. - Page 12 Symbol Function Single grill: Part of the area below the grill heating element becomes hot. The inner grill element is on. Can be used to grill a small number of burgers, sausages fish or bread. Double grill: The whole area below the grill heating element becomes hot. The inner and outer grill elements are on.
-
Page 13: Temperature Dial
Usage Temperature dial Use the temperature dials to set the required temperature for the ovens. The dials can then be rotated clockwise to set the required temperature. The temperature can set between 50ºC and 250ºC. The small light next to the temperature dial for the top oven will be lit when the top oven is heating and the small light next to the function dial for the bottom oven will be lit when the bottom oven is heating. -
Page 14: Function Buttons
Usage Function buttons The buttons can be used to set additional functions. Use this button to set the different modes Use this button to adjust the setting values upwards. Press and hold the button to rapidly adjusted the time (hold for a minimum of 5 seconds). -
Page 15: Setting The Clock
Usage Warnings: • When it is first used, it is normal for the oven to give off odours; this does not pose any risk and does not indicate a malfunction; they will disappear in time. Note • The bottom oven cannot be operated unless the clock is set Setting the clock When the oven is first connected to the electrical supply and powered on, the clock will need to be set. - Page 16 Usage Modes It is recommended that you run the oven for 15 minutes at 200 degrees to burn off any residue from their surfaces on first use. Note: • The cooking duration mode can only be used for the bottom cavity.
- Page 17 Usage Manual mode This mode can be used for the top and bottom cavities. In manual mode, only the time will be shown on the display. The cooking duration has to be controlled by the user (the oven will run continuously until turned off). To start cooking you need to turn the oven function and temperature dials that controls the top or bottom oven cavity to the required function and temperature.
- Page 18 Usage Minute minder (audible warning) This mode can be used for the top and bottom cavities. This function can be used to set an audible warning at the completion of the adjusted time period. Like the manual mode the cooking duration has to be controlled by the user (the oven will run continuously until turned off).
- Page 19 Usage Cooking duration (cook for a desired time period) This mode can only be used for the bottom cavity. This function is used to cook for a desired time range (the maximum cooking period is 23 hours and 59 minutes). To start cooking you need to turn the oven function and temperature dials to the required function and temperature.
-
Page 20: Lock Function
Usage Lock Function Press the lock button for a minim of 3 seconds, the lock function will be activated and lock symbol will be lit on the display. When lock function is activated, no modes can be accessed or the clock adjusted. The oven function dials and temperature dials can still be adjusted. - Page 21 Usage Accessories Warning: • Correct placement of the shelves between the side racks is imperative. This will ensure that food does not fall off or slide out when in the oven or being carefully removed from the oven. • Ensure that you always insert the accessories into the cooking compartment the right way round.
- Page 22 Usage Universal tray - for cooking large quantities of food such as cakes, pastries, frozen food, etc. Can also be used under the wire rack to catch fat when grilling. Slide the baking tray into the oven with the sloping edge facing towards the oven door. Wire rack - for grilling and roasting.
-
Page 23: Cleaning & Maintenance
Cleaning and Maintenance: Important notes: • The appliance will become hot during operation, allow the appliance to cool down before cleaning. • Do not use any high-pressure cleaners or steam cleaners. • Wash new sponge cloths thoroughly before use. • Do not leave acidic substances (lemon juice, vinegar) on stainless steel parts. •... - Page 24 Cleaning and Maintenance: • After each use, clean all surfaces once they have cooled down. If any residue is left (baked-on food, drops of grease etc.), however little, will become stuck to the surface and more difficult to remove later. •...
- Page 25 Cleaning and Maintenance: • Close the door to an angle approximately 30°. Hold the door with one hand on each side. Lift up and slowly pull the door out from the oven. Removing the Glass window • This can be done with the door(s) still attached to the appliance •...
- Page 26 Cleaning and Maintenance: • To reinstall the glass reverse the above steps after cleaning the glass (you must ensure the glass is fully dry) always make sure that the glass is the right way up and is pushed fully into position. When reinstalling the inner glass panel care must be taken not to push out the 2 rubber pads that are near the bottom of the inner door.
- Page 27 Cleaning and Maintenance: Causes of damage: • Accessories, foil, greaseproof paper or ovenware on the cooking compartment floor: Do not place accessories on the cooking compartment floor. Do not cover the cooking compartment floor with any sort of foil or greaseproof paper.
-
Page 28: Changing The Bulb
Cleaning and Maintenance: • Very dirty door seal: If the door seal is very dirty, the appliance door will no longer close properly when the appliance is in use. The fronts of adjacent units could be damaged. Always keep the door seal clean. •... -
Page 29: Trouble Shooting
Trouble Shooting: Problem Solution The circuit break is defective or turned off check circuit breaker is in working order and that it is not switched off No power Power cut or faulty fuse Check whether other kitchen appliances are working or check in the fuse box to make sure that the fuse for the appliance is working The oven doesn’t heat up... -
Page 30: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship you must contact Product Care with the original proof of purchase so a replacement or refund can be arranged. -
Page 31: Technical Specification
Technical Specification Model number RH72DEO1001B/01 RH72DEO1002SS/01 Rated Voltage 220V – 240V ~ 50Hz-60Hz External Dimensions (HxWxD) including handle 720mm x 594mm x 575mm External Dimensions (HxWxD) excluding handle 720mm x 594mm x 563mm... - Page 32 Swan Lane, Hindley Green, Wigan, WN2 4AY, United Kingdom Product Care (Ireland) Ltd, Unit 3D North Point House, North Point Business Park, New Mallow Road, Cork, T23 AT2P, Ireland. Russell Hobbs is the registered trademark of Spectrum Brands (UK) Ltd.
