- Page 1 Oven Instruction Manual Model number(s): RHEO6501B SS For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcare.co.uk IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Safety Instructions ………………………………………. Product Overview ………………………………………. Positioning ………………………………………. Installation ………………………………………. Usage ………………………………………. 10-23 Cleaning & Maintenance ………………………………………. 24-26 Trouble shooting ………………………………………. Guarantee ………………………………………. Technical specification ………………………………………. Notes ………………………………………. 30-31 For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am –... -
Page 3: Safety Instructions
Safety Instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand... - Page 4 Safety Instructions • This appliance can only be installed in a well-ventilated place in accordance with existing regulations and ventilation specifications. • This appliance is intended for domestic use and the household environment only. The appliance is not intended for use outside. •...
- Page 5 Safety Instructions • When you open the appliance door, hot steam may escape. Open the appliance door with care. Keep children at a safe distance. • Water in a hot cooking compartment may create hot steam. Never pour water into the hot cooking compartment. •...
-
Page 6: Product Overview
Product overview 1. Oven function dial 6. Temperature dial 2. Function buttons 7. 2 x Wire shelf 3. Handle 8. 1 x Universal tray & handle 4. Glass window 9. 1 x Wire rack 5. Display 10.2 x Distance holding screws Unit &... -
Page 7: Positioning
Positioning • This appliance is to be installed under a counter top or in cabinets. • Avoid damaging the product during installation. • The appliance can only be used safely if it is correctly installed according to the safety instructions. The installer is responsible for ensuring that the appliance works correct when installed. -
Page 8: Installation
Installation Preparation & installation Ensure that there are no electric wires, gas or water pipes in the area where holes are to be made. Components of the appliance may have sharp edges. Wear protective gloves. 1. Ensure that that there is an electrical power point within adequate distance of the oven after it has been installed. - Page 9 Installation Electrical connection • WARNING- THIS APPLIANCE MUST BE EARTHED • This appliance is designed to be connected to a 220-240V~50Hz AC electricity supply. • Before proceeding with the electrical connection, verify that the current carrying capacity of the system and the isolator / main switch is adequate for the maximum power rating of the oven.
-
Page 10: Usage
Usage Control panel The appliance has an oven function dial, temperature dial, a display and function buttons, these are explained below: Oven function dial The oven function dial allows you to set the oven function mode for the oven. The dial has to be pressed in for it to pop out, before it can then be rotated clockwise or anti-clockwise to set the required oven function. - Page 11 Symbol Function Bottom heating: The temperature is emitted from below which provides heat to the base of food. Use bottom heating for baking and browning dishes from below, ideal for slow cooking dishes such as casseroles, stews, pastries and pizzas where a crispy base is desired.
-
Page 12: Temperature Dial
Usage Temperature dial Use the temperature dial to set the required temperature for the oven. The dial has to be pressed in for it to pop out, before it can then be rotated clockwise to set the required temperature. The temperature can set between 50ºC and 250ºC. The small light above the temperature dial will be lit when the oven is heating. -
Page 13: The Oven Cavity
Usage Function buttons The buttons can be used to set additional functions. Use this button to adjust the setting values downwards. Use this button to set the different modes (press and hold for 3 seconds to turn the oven on: the symbol will appear on the display). -
Page 14: Setting The Clock
Usage Warnings: • When it is first used, it is normal for the oven to give off odours; this does not pose any risk and does not indicate a malfunction; they will disappear in time. Setting the clock When the oven is first connected to the electrical supply and powered on, the clock will need to be set. - Page 15 Usage Modes Important: If the display does not show the symbol the oven will not work or heat up. Only when the symbol is visible will the oven function or heat up. It is recommended that you run the oven for 15 minutes at 200 degrees to burn off any residue from their surfaces on first use.
- Page 16 Usage Manual mode: In manual mode, only the time and the symbol will be shown on the display. The cooking duration has to be controlled by the user (the oven will run continuously until turned off). To start cooking you need to turn the oven function and temperature dials to the required function and temperature.
- Page 17 Usage Minute minder (audible warning) This function can be used to set an audible warning at the completion of the adjusted time period. Like the manual mode the cooking duration has to be controlled by the user (the oven will run continuously until turned off). To start cooking you need to turn the oven function and temperature dials to the required function and temperature.
- Page 18 Usage Dur (cook for a desired time period) This function is used to cook for a desired time range (the maximum cooking period is 10 hours). To start cooking you need to turn the oven function and temperature dials to the required function and temperature. The food that is to be cooked needs to be put into the oven.
- Page 19 Usage End (cook to a desired time) This function is used to cook according to a desired finishing time. To start cooking you need to turn the oven function and temperature dials to the required function and temperature. The food that is to be cooked needs to be put into the oven.
- Page 20 Usage Fully automatic programming (cook during a desired time range to a desired time) This function is used to cook after a certain period of time, with a certain duration. To start cooking you need to turn the oven function and temperature dials to the required function and temperature.
- Page 21 Usage 4. Once the required minute time has been reached press the mode button to confirm the cooking time and the “A“ symbol will stop flashing and stay lit. symbol will disappear from the display and the display will go to manual mode.
- Page 22 Usage Tips • Press the "+" or "-" buttons for more than 3 seconds to make the time rapidly increase or decrease at a rate of 5 seconds. • When setting the time for each function, if no button is pressed after 5 minutes then the oven will return to the manual mode •...
- Page 23 Usage Accessories Warning: • Correct placement of the shelves between the side supports is imperative. This will ensure that food does not fall off or slide out when in the oven or being carefully removed from the oven. • Ensure that you always insert the accessories into the cooking compartment the right way round.
-
Page 24: Cleaning & Maintenance
Cleaning and Maintenance: Important notes: • The appliance will become hot during operation, allow the appliance to cool down before cleaning. • Do not use any high-pressure cleaners or steam cleaners. • Wash new sponge cloths thoroughly before use. • Do not leave acidic substances (lemon juice, vinegar) on stainless steel parts. •... -
Page 25: Cleaning And Maintenance
Cleaning and Maintenance: How to clean: • After each use, clean all surfaces once they have cooled down. If any residue is left (baked-on food, drops of grease etc.), however little, will become stuck to the surface and more difficult to remove later. •... -
Page 26: Cleaning & Maintenance
Cleaning and Maintenance: • Very dirty door seal: If the door seal is very dirty, the appliance door will no longer close properly when the appliance is in use. The fronts of adjacent units could be damaged. Always keep the door seal clean. •... -
Page 27: Trouble Shooting
Trouble Shooting: Problem Solution The circuit break is defective or turned off check circuit breaker is in working order and that it is not switched off No power Power cut or faulty fuse Check whether other kitchen appliances are working or check in the fuse box to make sure that the fuse for the appliance is working The oven doesn’t heat up... -
Page 28: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship you must contact Product Care with the original proof of purchase so a replacement or refund can be arranged. Refund or replacement is at the discretion of Product Care. -
Page 29: Technical Specification
Technical Specification Model number RHEO6501B SS Rated Voltage 220V – 240V ~ 50Hz External Dimensions(HxWxD) 595mm x 595mm x 575mm For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm... -
Page 30: Notes
Notes For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcare.co.uk... - Page 31 Notes For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcare.co.uk...
- Page 32 For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday – Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcare.co.uk This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
