Summary of Contents for Stabila LAX 500 G
- Page 1 Operating instructions...
-
Page 2: Table Of Contents
Contents Section Page • 1. Intended use • 2.1 Safety instructions for laser units • 2.2 Safety instructions for the Li-ion battery pack • 3. Components of the unit • 4. Commissioning • 4.0 Inserting, removing and charging the battery •... -
Page 3: Intended Use
Congratulations on the purchase of your STABILA measuring tool. LASER The STABILA LAX 500 G is an easy-to-use cross line and plumb-line laser for horizontal LASER RADIATION and vertical levelling. Plumb-line dots enable you to align and create plumb lines on DO NOT STARE INTO BEAM 510 - 635 nm / <1mW... -
Page 4: Components Of The Unit
3. Components of the unit 1. Protective frame: with magnet and tripod socket 2. Exit window: Horizontal and vertical laser line, plumb-line dot upwards 3. Exit window: Plumb-line dot downwards 4. Protective slider: Mechanical lock 5. Magnet surface 6. Contact edge: Makes aligning with plumb-line dot easier 7. -
Page 5: Commissioning
4. Commissioning 4.0 Inserting, removing and charging the battery Only 12 V Li-ion CAS System (Cordless Alliance System) battery packs can be used. Push in the battery pack in the direction of the arrow up to the stop. The battery pack must have an adequate charge capacity. -
Page 6: Unlocking And Setting Up
4.1 Unlocking and setting up When the protective slider is slid on, the laser exit windows are enabled. At the same time, the laser unit is unlocked and can be turned in the desired direction. -
Page 7: Switching The Unit On
"Manual mode" button. For this purpose, press and hold it for more than 2 seconds. The laser beam flashes 2 x every 5 seconds. The LAX 500 G is not in self-levelling function mode and can only be used in this mode for marking and alignment! -
Page 8: Functions
5. Functions 5.1 Selecting laser functions Once the unit has been switched on, the "Laser lines" button can be used to set the various laser functions. Plumb-line function Transfers a determined point from the floor to the ceiling. 5.2 Working with the receiver Pulse mode must be activated for work completed over larger distances or using a suitable receiver. -
Page 9: Led Indicators
Operation without levelling function Operation activated Battery check failed Replace the battery pack Operation activated Operation with levelling function Get in touch with STABILA Battery capacity low CAS battery Operation with levelling function charge capacity too low Laser in pulse mode -->... -
Page 10: Using The Laser With The Slb 500 Laser Base
7.2 Using the SWB10 bracket The LAX 500 G can be attached to and aligned with walls or profiles using the SWB 10 bracket. The clamp can be used to attach the bracket to interior construction profiles. -
Page 11: Checking Accuracy
Checking vertical laser lines 1. Create a reference line, e.g. with a plumb line. 2. Set up and align the LAX 500 G at a distance of Y in front of this reference line. 3. Compare the laser line with the reference line. -
Page 12: Horizontal Check
4. Once automatic levelling has ended, mark the cross projected onto wall A. Point 1. 5. Turn the LAX 500 G by 180° and align with wall B using the same vertical laser line exit window. Do not adjust the height. -
Page 13: Technical Data
9. Technical data Laser type: Green diode laser, 510–530 nm wavelength Power output: < 1 mW, laser class 2, in accordance with IEC 60825-1:2014 EN60825-1:2014 /A11:2021 Self-levelling range: approx. ± 5° Levelling accuracy*: Laser line: ±0.3 mm/m ± 3/16“ over 50ft centre of laser line Batteries: 12 V 2 Ah Li-ion CAS battery pack 12 V 4 Ah Li-ion CAS battery pack...
