Installing the Marantz Model M1
The NP17AV-MRZ1 enclosure features a mounting
system designed specifically for the Marantz M1.
Step 1:
Attach the included locking cam to the bottom side
of the Marantz M1
Mounting Bracket
Step 2:
Slide the Marantz M1 into the
mounting bracket until it locks into
place
IS0237 Rev A 03/18/25
NP17AV-MRZ1 Enclosure Installation Guide
Locking Cam
Release Tab
To remove, press tab to release the
Marantz M1 and slide out.
Advertisement
Related Manuals for Altelix NP17AV-MRZ1
Summary of Contents for Altelix NP17AV-MRZ1
- Page 1 NP17AV-MRZ1 Enclosure Installation Guide Installing the Marantz Model M1 The NP17AV-MRZ1 enclosure features a mounting system designed specifically for the Marantz M1. Step 1: Attach the included locking cam to the bottom side of the Marantz M1 Locking Cam Mounting Bracket...
- Page 2 NP17AV Series Enclosure Installation Guide NP17AV Series Wall Mounting Guide External Mounting Feet The NP17AV series enclosures feature four external mounting feet for mounting the enclosure. For more secure installations, internal mounting Rear of Enclosure points are provided. These mounting points will need to be drilled out in order to wall mount the enclosure.
- Page 3 Altelix LLC USA: 866-660-WIFI (9434) International: +1 561-660-9434 sales@altelix.com www.altelix.com Copyright (C) 2025 Altelix LLC. All rights reserved. Altelix and the Altelix logo are Trademarks and/or Registered Trademarks of Altelix LLC. Specifications are subject to change without notice. See www.altelix.com for most current information...
