Altelix NP17AV-SNS1 Installation Manual

Download this manual

Installing the Sonos AMP

The NP17AV-SNS1 enclosure features a mounting

system designed specifically for the Sonos AMP.

Step 1:

Attach the included locking cam to the bottom side

of the Sonos AMP

Mounting Bracket

Step 2:

Slide the Sonos AMP into the mounting

bracket until it locks into place

IS0236 Rev A 02/06/25

NP17AV-SNS1 Enclosure Installation Guide

Locking Cam

Release Tab

To remove, press tab to release the

Sonos AMP and slide out.
