LG MULTI V IV PRO ARUN080LLH4 Installation Manual page 76

ELECTRICAL WIRING
76
Comfort Cooling Function
In the cooling mode, this optional function enables the IDU to operate continuously with out
thermo off to reduce ODU power consumption.
Continuous cooling function setting method
Mode Setting
Option
Off
op1
op2
op3
CAUTION
!
• Ask an authorized technician to setting a function.
• If use a function, first install a Central controller.
Master unit PCB DIP switch on : No.5
Select the mode using '▶', '◀' Button :
"Idu" Push the '●' button
Select the Function using '▶', '◀' Button :
"Id6" Push the '●' button
Select the Option using '▶', '◀' Button :
"IDU No. & Mode(OFF, OP1~OP3)" Push the '●' button
Start the IDU function
Little low cooling, but least power consumption
Medium Cooling with medium power consumption
High cooling, but more power consumption
Setting
Usual Operation
