Example) Connection of transmission wire
[BUS type]
- Connection of communication cable must be
installed like below figure between indoor
unit to outdoor unit.
ELECTRICAL WIRING
[STAR type]
- Abnormal operation can be caused by com-
munication defect, when connection of
communication cable is installed like below
figure(STAR type).
57
