ELECTRICAL WIRING
52
Communication and Power Cables
Communication cable
- Types : shielding cable
- Cross section : 1.0~1.5 mm
- Maximum allowable temperature: 60 °C
- Maximum allowable cable length: under 1000 m
Remote control cable
- Types : 3-core cable
Central control cable
Product type
ACP
AC Smart
AC Ez
Separation of communication and power cables
- If communication and power cables are run alongside each other then there is a strong likeli-
hood of operational faults developing due to interference in the signal wiring caused by electro-
static and electromagnetic coupling.
The tables below indicates our recommendation as to appropriate spacing of communication
and power cables where these are to be run side by side
Current capacity of power cable
100V or more
NOTE
!
• The figures are based on assumed length of parallel cabling up to 100 m. For length in ex-
cess of 100 m the figures will have to be recalculated in direct proportion to the additional
length of cable involved.
• If the power supply waveform continues to exhibit some distortion the recommended
spacing in the table should be increased.
- If the cable are laid inside conduits then the following point must also be taken into ac-
count when grouping various cable together for introduction into the conduits
- Power cable(including power supply to air conditioner) and communication cables
must not be laid inside the same
- In the same way, when grouping the power wires and communication cables should not
be bunched together.
CAUTION
!
If apparatus is not properly earthed then there is always a risk of electric shocks, the earthing of
the apparatus must be carried out by a qualified person.
2
Cable type
2-core cable (Shielding cable)
2-core cable (Shielding cable)
4-core cable (Shielding cable)
10 A
50 A
100 A
Exceed 100 A
Diameter
2
1.0~1.5 mm
2
1.0~1.5 mm
2
1.0~1.5 mm
Spacing
300 mm
500 mm
1000 mm
1500 mm
