LG MULTI V IV PRO ARUN080LLH4 Installation Manual page 70

ELECTRICAL WIRING
70
Setting the ODU address
Mode setting method
CAUTION
!
• Ask an authorized technician to setting a function.
• If use a function, first install a Central controller.
Master unit PCB DIP switch on : No.5
Select the mode using '▶', '◀' Button :
"Func" Push the '●' button
Select the Function using '▶', '◀' Button :
"Fn5" Push the '●' button
Select the Option using '▶', '◀' Button :
"0" ~ "254" Push the '●' button
ODU address is set
