PIPE CONNECTIONS BETWEEN INDOOR AND OUTDOOR UNIT
27
Method of drawing out pipes on the bottom side
- Drawing out common pipe through side panel
Liquid pipe
Gas pipe
Remove only liquid/gas pipe Knock out
