- Page 1 INSTRUCTIONS FOR USE Induction hob GI6401BSCE / GI6401BCE...
-
Page 2: Table Of Contents
Content 1. Foreword ................... 4 1.1 Safety Warnings ................4 1.2 Installation ..................4 1.2.1 Electrical Shock Hazard............4 1.2.2 Cut Hazard ..............4 1.2.3 Important safety instructions ..........4 1.3 Operation and maintenance ............... 5 1.3.1 Electrical Shock Hazard............5 1.3.2 Health Hazard .............. - Page 3 9.5 Adjusting the bracket position ............23 9.6 Cautions ..................24 9.7 Connecting the hob to the mains power supply ........24...
-
Page 4: Foreword
1. Foreword 1.1 Safety Warnings Your safety is important to us. Please read this information before using your cooktop. 1.2 Installation 1.2.1 Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. •... -
Page 5: Operation And Maintenance
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 6: Hot Surface Hazard
(such as insulin pumps) must consult with their doctor or implant manufacturer before using this appliance to make sure that their implants will not be affected by the electromagnetic field. • Failure to follow this advice may result in death. 1.3.3 Hot Surface Hazard •... - Page 7 • Do not leave children alone or unattended in the area where the appliance is in use. • Children or persons with a disability which limits their ability to use the appliance should have a responsible and competent person to instruct them in its use.
-
Page 8: Product Induction
2. Product Induction 2.1 Top View 1. Max. 1200/1500 W zone 2. Max. 1500/2000 W zone 3. Max. 1500/2000 W zone 4. Max. 1200/1500 W zone 5. Glass plate 6. Control panel 7. ON/OFF control 2.2 Control Panel 1. Heating zone selection controls 2. -
Page 9: Technical Specification
2.5 Technical Specification Cooking Hob GI6401BSCE / GI6401BCE Cooking Zones 4 Zones Supply Voltage 220-240V~ 50Hz or 60Hz Installed Electric Power 7000W Product Size L×W×H(mm) 590X520X60 Building-in Dimensions A×B (mm) 560X490 Weight and Dimensions are approximate. Because we continually strive to improve our products we may change specifications and designs without prior notice 3. -
Page 10: How To Use
Use pans whose diameter is as large as the graphic of the zone selected. Using a pot a slightly wider energy will be used at its maximum efficiency. If you use smaller pot efficiency could be less than expected. Pot less than 140 mm could be undetected by the hob. -
Page 11: If The Display Flashes
Warning: The whole hob can take in charge a maximum power of 3000W. Consequently, the hob automatically reduces the maximum output power by allowing a maximum sum of the all power levels of 12 If the display flashes alternately with the heat setting This means that: •... -
Page 12: Locking The Controls
Touching the heating zone selection control Touching the boost control ,the zone indicator show “b” and the power reach Max Cancel the Boost function Touching the heating zone selection control that you wish to cancel the boost function Touching the "Boost" control or the “-” button to cancel the Boost function, then the cooking zone will revert to its original setting. -
Page 13: Timer Control
3.3.5 Timer control You can use the timer in two different ways: You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the set time is You can set it to turn one or more cooking zones off after the set time is up. The timer of maximum is 99 min. -
Page 14: Default Working Times
Touch timer control, the minder indicator will start flashing and “10” will show in the timer display. Set the time by touching the or control of the timer Hint: Touch the “-” or “+” control of the timer once will decrease or increase by 1 minute. Touch and hold the “-”... -
Page 15: Power Management Function
3.3.7 Power Management Function • it is possible to set a maximum power absorption level for the induction hob, choosing up to different power ranges. • induction hobs are able to limit themselves automatically in order to work at lower power, to avoid the risk of overloading. -
Page 16: Cooking Guidelines
4. Cooking Guidelines Take care when frying as the oil and fat heat up very quickly, particularly if you’re using PowerBoost. At extremely high temperatures oil and fat will ignite spontaneously and this presents a serious fire risk. 4.1 Cooking Tips •... -
Page 17: Heat Settings
5. Heat Settings The settings below are guidelines only. The exact setting will depend on several factors, including your cookware and the amount you are cooking. Experiment with the induction hob to find the settings that best suit you. Heat setting Suitability •... -
Page 18: Hints And Tips
Spillovers on the 1. Switch the power to the cooktop off. • The cooktop may beep and turn touch controls 2. Soak up the spill itself off, and the touch controls 3. Wipe the touch control area with a clean may not function while there is damp sponge or cloth. -
Page 19: Failure Display And Inspection
Pans do not become hot and The induction hob cannot Use cookware suitable for induction cooking. See appears in the display. detect the pan because it is not section ‘Choosing the right cookware’. suitable for induction cooking. Centre the pan and make sure that its base The induction hob cannot detect the pan matches the size of the cooking zone. - Page 20 Specific Failure & Solution Failure Problem Solution A Solution B The LED does not No power supplied. Check to see if plug is come on when unit is plugged secured tightly in outlet and that outlet is working. The accessorial power Check the connection.
-
Page 21: Installation
9. Installation 9.1 Selection of installation equipment Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant and insulated work surface material (Wood and similar fibrous or hygroscopic material shall not be used as work surface material unless impregnated) to avoid the electrical shock and larger deformation caused by the heat radiation from the hotplate. -
Page 22: Before Installing The Hob, Make Sure That
WARNING: Ensuring Adequate Ventilation Make sure the induction cooker hob is well ventilated and that air inlet and outlet are not blocked. In order to avoid accidental touch with the overheating bottom of the hob, or getting unexpectable electric shock during working, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 50mm from the bottom of the hob. -
Page 23: After Installing The Hob, Make Sure That
9.3 After installing the hob, make sure that • The power supply cable is not accessible through cupboard doors or drawers. • There is adequate flow of fresh air from outside the cabinetry to the base of the hob. • If the hob is installed above a drawer or cupboard space, a thermal protection barrier is installed below the base of the hob. -
Page 24: Connecting The Hob To The Mains Power Supply
9.6 Cautions 1. The induction hotplate must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. 2. The hob will not be installed directly above a dishwasher, fridge, freezer, washing machine or clothes dryer, as the humidity may damage the hob electronics 3. - Page 25 • If the cable is damaged or to be replaced, the operation must be carried out the by after-sale agent with dedicated tools to avoid any accidents. • If the appliance is being connected directly to the mains an omnipolar circuit-breaker must be installed with a minimum opening of 3mm between contacts.
- Page 26 www.gorenje.com...
