Service Manual_
Service Manual
维修手册
Upright Frz. SERIES
市场型号
工厂型号
基准编码
Applicable Models
Model Code
Applicable Models
HS-267FN
UR-BD205-DQ
22031010006082
本手册中图片均为参考示意图，具体外观和配置以实物为准。
The picture in this service manual is only for reference, and specific appearance
and configuration are subject to the real product.
本手册主要讲授方法，具体的作业技能需要工程师通过日常工作积累。
This manual mainly teaches the method, the specific work skill needs engineer to
accumulate through the daily work.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Midea HS-267FN
Summary of Contents for Midea HS-267FN
- Page 1 Upright Frz. SERIES 市场型号 工厂型号 基准编码 Applicable Models Model Code Applicable Models HS-267FN UR-BD205-DQ 22031010006082 本手册中图片均为参考示意图，具体外观和配置以实物为准。 The picture in this service manual is only for reference, and specific appearance and configuration are subject to the real product. 本手册主要讲授方法，具体的作业技能需要工程师通过日常工作积累。 This manual mainly teaches the method, the specific work skill needs engineer to...
- Page 2 Service Manual_ WARNING Important Safety Notice There are special components used in this equipment which are important for safety. These parts are marked in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards.
-
Page 3: Table Of Contents
Service Manual_ Contents 重要更新说明 SIGNIFICANT UPDATE NOTES(NONE) ..................5 2. 安全警示规范 SAFETY WARNING CODE ......................6 2.1 作业安全警告 W ....................6 ARNING FOR OPERATION SAFETY 2.2 冷媒安全须知 S AFETY INSTRUCTION FOR REFRIGERANT ..................8 3. 运输 TRANSPORT ..............................9 3.1 搬运 H ANDLING ................................. - Page 4 Service Manual_ 9.5 除霜功能 D ..........................26 EFROST FUNCTION 10. 压缩机 COMPRESSOR ............................. 27 10.1 压缩机的开停控制规则 C OMPRESSOR ON AND OFF ONTROL SPECIFICATIONS ..........27 11. 故障排除方法 TROUBLESHOOTING METHOD ..................... 28 11.1 不制冷 N OT COOLING ............................28 11.2 压缩机故障 N .....................
-
Page 5: 重要更新说明 Significant Update Notes(None)
Service Manual_ 重要更新说明 Significant update notes(None) -
Page 6: 安全警示规范 Safety Warning Code
Service Manual_ 安全警示规范 Safety Warning Code Warning for operation safety 作业安全警告 Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your freezer. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your freezer. -
Page 7: Connecting Electricity
Service Manual_ CONNECTING ELECTRICITY Electrical Shock Hazard. Failure to follow these instructions can Plug into a grounded 3-prong outlet. result in death, fire, or electrical shock. Do not remove the ground prong. Do not use an adapter. WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death. -
Page 8: Grounding Requirement
Service Manual_ 13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this freezer. 14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If the power cord is too short, have a qualified electrician install an outlet near the freezer. Use of an extension cord can negatively affect the freezer’s performance. -
Page 9: 运输 Transport
Service Manual_ 运输 Transport Handling 搬运 Handling 搬运 1) 在移动中保护冰箱，如图所示，使用加垫的手推车。 2) 拆除冰箱所有包装材料和底垫再搬运到室内安放。 3) 放置 2 小时再通电运行。 1)Protect the refrigerator in moving it,Same as shown as lef t photo, please move it by handcart with cushion 2)Remove all packing materials and bottom cushion, the m ove into house for placement 3)After moving it to appropriate location, wait for 2 hours bef ore power on. -
Page 10: 安装和调试 Installation And Commissioning
Service Manual_ 安装和调试 Installation and commissioning Door Disassembly and Assembly 门体拆装 当整机无法进入室内时，需要对门体拆除。The refrigerator door needs to be dismantled if it cannot enter the room in the whole. Installation location 安装位置 安装位置 Installation location 需要选择通风的位置，有利于散热提升性能、降低能耗。 Location that is easy for ventilation shall be chosen to facilitate heat dissipation, enhance its performance and reduce the energy consumption. -
Page 11: 左右换门 Door Reversal
Service Manual_ Door reversal 左右换门 Door reversal 左右换门 1)用胶带防护带拆卸门体； 1) Fix the door by tapes. 1) 2)拆下铰链孔盖，拆下右上铰链罩，用螺丝刀松右上铰链 固定螺丝，拆下右上铰链，注意防止门体落下； 2) Dismantle hinge hole cap, the upper right hinge cover, fitting screws of upper right hinge, and remove the upper right hinge, please keep the door vertical in whole process for avoiding falling. -
Page 12: 门锁安装 Installation Of Door Lock（None
Service Manual_ 8) 7)将冷冻门体套在下铰链轴上，贴在箱体上，注意门体落 下，固定左上铰链螺钉，盖上左上铰链罩，将铰链孔盖装 在箱体顶部右侧。 7)Put the door on lower hinge vertically, and validate the gas tightness of door gasket, take out the spare upper left hinge and hinge cover from accessory bag, then install the upper left hinge by fitting screws, finally to install the hinge cover, and cover the hinge hole cap on upper right side. -
Page 13: 产品配置和尺寸 Product Configuration And Dimension
Service Manual_ 产品配置和尺寸 Product configuration and dimension Main parts and their names 主要部件及名称 （本图片为参考示意图，具体外观和配置以实物为准）(The picture is only for reference, and specific appearance and configuration are subject to the real product) Freezer chamber Refrigerator chamber 冷冻室 冷藏室 Thermostat box and assembly Thermostat box and assembly ❶温控盒组件... -
Page 14: 外观尺寸 External Dimension
Service Manual_ External dimension 外观尺寸 代码 Size (mm) 描述Description 尺寸 Code 高度Height to Top of Case 1270 宽度Width 深度/把手Depth w/Handles 1065 深度Depth (Total with Door Open) （本图片为参考示意图）(The picture is only for reference) -
Page 15: Ocation Of S/N
Service Manual_ Location of S/N 序列号的位置 有些产品在箱体的右侧的下部也有 S/N. Some products also have S/N on the lower part of the right side of the Cabinet. -
Page 16: 产品规格 Product Specification
Service Manual_ 产品规格 Product specification Electrical parameters 电气参数 Applicable Models 市场型号 HS-267FN Product Name 产品名称 UR-BD205-DQ Item Specification 项目 规格 Refrigerant R600a 制冷剂 Compressor EZ65E1Z-U 压缩机 启动器 Starter(PTC) QPE2-A4R7MD3 Overload protector(OLP) DRB29T61A1 过载保护器 Integrate PTC+OLP 整体式启动器+保护器 Variable frequency driver board 变频驱动板... -
Page 17: 电路图 Circuit Diagram
Service Manual_ Circuit diagram 电路图... -
Page 18: 制冷管路系统和冷气循环路线 Refrigerating Piping System And Circulating Route Of Cooling Air
Service Manual_ 制冷管路系统和冷气循环路线 Refrigerating piping system and circulating route of cooling air Refrigerating piping system 制冷管路系统 ○ 1 压缩机→○ 2 排气连接管→○ 3 后冷凝器→○ 4 整体冷凝器→○ 5 防凝露管→○ 6 干燥过滤器→○ 7 毛细管→○ 8 蒸发器→○ 9 回气换热段 ○ 1 Compressor→ ○ 2 Exhaust evaporation→... -
Page 19: 部件拆装 Dismantling Of Parts
Service Manual_ 部件拆装 Dismantling of parts Parts on the door 门上部件 Door seal 门封条 冰箱门封条被装到门胆槽内 1)打开冰箱门； 2)抓住门封条并将其从门胆槽中取出； Door seal is installed into door liner groove. 1)Open the refrigerator door; 2)Take the door seal out of door liner; Guardrail 门栏条 None Door stopper 止档... -
Page 20: 灯系统 Light System (None)
Service Manual_ Light system (None) 灯系统 Air duct components refrigerating chamber (None) 冷藏风道 Air duct components in freezing chamber and fan motor (None) 冷冻风道及风扇电机 Evaporator and temperature sensing system 蒸发器及感温系统 Evaporator in freezing chamber 冷冻室蒸发器 Evaporator in freezing chamber silk tube evaporator 冷冻室蒸发器... -
Page 21: 压缩机仓 Compressor Case
Service Manual_ 4 ） 更换温控器。 replace the thermostat. Compressor case 压缩机仓 Rear cover and compressor case 后盖板和压缩机仓 None Compressor and the cooling system pipe 压缩机和制冷系统管路 1）切断电源,取出冰箱内的物品，用胶带把全部门体固定 牢靠，防止冰箱倾倒时门体掉落。Cut off the power, remove the goods in the refrigerator, with the tape to make the door fixed firmly and prevent the door dropping when the refrigerator dumping. - Page 22 Service Manual_ 4-2）拆卸卡簧 Remove the metal clamp(for some models) Disassembly the metal clamp that is fix -拆卸压缩机卡簧 the electric appliance shield 5）拆卸压线卡 Remove the clipping strip Slowly pull it out 向外慢慢拔出 6）拆卸保护罩 Remove the protective cover Pry the protective -从上部慢慢撬开保护罩，使得卡扣脱落 cover slowly from the upper part, Pull it out and remove it.
- Page 23 Service Manual_ 9）使用扳手依次拆卸❹❺❻❼螺栓，更换压缩机后逆向 操作安装。Use the wrench to remove the bolts by steps❹❺❻❼, replace the compressor and reverse process can complete installation. 10）用割管器割断冷凝器❽，用毛细管钳剪断毛细管 ❾Use Pipe cutter cut off the condenser tube❽, then Shear off capillary ❾ by the capillary tube scissors. 11）更换压缩机进行管路焊接...
- Page 24 Service Manual_ 13）抽真空，真空度达到 6Pa 以下 Vacuum system,The degree of vacuum below 6Pa. 14）系统充注制冷剂。Perfusion refrigerant. 15）使用大力钳夹紧工艺管中间部位，然后对工艺管⓯⓰ 封焊。Use the vise grip pliers clamp the middle of the process pipe, then seal welding process tube⓯⓰. Condenser fan motor 冷凝风扇电机 None Standby condenser 副冷凝器 None Piping system in the compressor case 压缩机仓管路系统...
-
Page 25: 功能和操作 Function And Operation
Service Manual_ 功能和操作 Function and operation Operation panel 操作面板 Icons Button 图标 按键 Cooling gear 冷藏档 关闭“OFF” Freezer gear 冷冻档 Temperature control 温度控制 直冷机械冰箱，通过温控器旋钮来调节档位 Direct cooling mechanical refrigerator, through the thermostat knob to adjust the stalls. 温控器旋钮调至最大档（COLDEST)，冰箱内部温度越低; 温控器旋钮调至最小档(COLD)，冰箱内部温度越高。 注意：请在 COLDEST 档位与 COLD 档位之间使用调节。 Turn the temperature control knob to COLDEST, the internal temperature of the refrigerator becomes lower. -
Page 26: 报警 Give An Alarm (None)
Service Manual_ Give an alarm (None) 报警 Failure code and solutions (None) 故障代码及解决方法 Defrost function 除霜功能 Manual defrost 手动除霜... -
Page 27: 压缩机 Compressor
Service Manual_ 压缩机 Compressor 10.1 Compressor on and off Control specifications 压缩机的开停控制规则 1.1 满足下列条件之一，压缩机停机： Tr ≤ Trt； 压缩机连续运行时间超过（含）3 小时（停机 5 分钟）； 1.2 下列条件全部满足时，压缩机开机： Tr ≥Trk 压缩机停机时间 ≥ 7min ★在 1.1 项、1.2 项均不满足的情况下，压缩机维持原状态不变。 1.1 When one of the following conditions is met, the compressor stops: 1) Tr ≤... -
Page 28: 故障排除方法 Troubleshooting Method
Service Manual_ 故障排除方法 Troubleshooting Method 11.1 Not cooling 不制冷... -
Page 29: Ot Working Of Compressor
Service Manual_ 11.2 Not working of compressor 压缩机故障 11.3 Thermostat malfunction-Undercooling 温控器故障-过冷... -
Page 30: 灯不亮 Light Is Not On(None)
Service Manual_ 11.4 Light is not on(None) 灯不亮 11.5 Noise 噪音... -
Page 31: 产品爆炸图和备件明细 Product Exploded View And Spare Parts List
Service Manual_ Product exploded view and spare parts list 产品爆炸图和备件明细 此部分内容请到 I-Service 系统中查看 Please log in to I-Service system to view and download these contents. URL: https://ics.midea.com https://ics.midea.com APAC: https://ics-eu.midea.com EMEA: https://ics-amer.midea.com Americas：...
