- Page 1 PARTS LIST & INSTRUCTION Industrial Sewing Machines PX302-4W PX302-5W PX301F-2S 2021 年 4 月 第 12 版 発行 12th edition: April 2021 No. 210041...
- Page 22 INDEX 1 REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. REF. PART NO. 品 番 品 番 品 番 品...
- Page 23 Series Instruction Manual...
-
Page 24: Table Of Contents
INTRODUCTION CONTENTS Thank you for your purchasing Kansai Special's PX Series. 1. NEEDLES & THREADING THE MACHINE Read and study this instruction manual carefully before beginning any of the 1-1 Needles ··················································································· 1 1-2 Replacing the needle ································································· 1 procedures and save it for later use. -
Page 25: Needles & Threading The Machine
【1】NEEDLES & THREADING THE MACHINE 【2】MACHINE SPEED 1-1 Needles 2-1 Machine speed & direction in which the machine pulley runs UO163 of Schmetz or Organ Maximum speed : 3,500 rpm Select the proper needle for the fabric and thread. Standard speed : 3,000 rpm <... -
Page 26: Oil
【3】LUBRICATION 【4】SEWING MACHINE INSTALLATION 3-1 Oil 4-1 Cutting the machine table Use Kansai Special’s genuine oil (Part No. 28-611) 3-2 To fill the machine with oil Remove oil plug A. Fill the machine with oil until the oil level is at the top line (see H in the illustration) on oil gauge C. -
Page 27: To Install The Machine
4-2 To install the machine 5-2 Needle drop and needle side stroke Install the brackets on the underside of the table board (see the illustration below). The needle side stroke on this machine is 5.55mm (302-4W) and 7.4mm (302-5W) and Fit the rubber cushions onto the brackets. -
Page 28: To Install The Looper
5-5 Position of the looper rocker The setting distances of the looper with the needle at position 4 and position 1 should be 5-3 To install the looper equal (302-4W,-5W：5～5.5mm 301F-2S：4.8mm) To set the angle and height of the looper, insert the looper fully into looper holder A and (For PX302-5W, the needle at position 1 and position 5) tighten screw B. -
Page 29: Looper Left-To-Right Movement
5-6 Looper left-to-right movement 5-9 Adjusting the looper back spring This adjustment should be made when the needle is It is the best that the surface of the spring touches the at position 1 (see 5-2). When the point of the looper, looper closely within the range of B. -
Page 30: Adjusting The Feed Dog & Stitch Length
【7】ADJUSTING THE FEED DOG & STITCH LENGTH 【8】ADJUSTING THE PRESSER FOOT 7-1 Feed dog height 8-1 Presser foot pressure When the feed dog is at the top of its stroke, the feed dog The presser foot pressure should be as light as teeth should be 0.8~1.2mm above the top surface of the possible, yet be sufficient to feed the fabric and needle plate. -
Page 31: Adjusting The Stitch Formation
【9】ADJUSTING THE STITCH FORMATION 9-3 Adjusting the needle thread guard With the needle bar at the bottom of its stroke, the 9-1 Adjusting the looper thread eyelets centers of eyes on needle bar thread eyelet A should be Align the eyes on the looper thread eyelets A with the level with the top surface of needle thread guard B. - Page 32 MORIMOTO MFG. CO., LTD. 1-4-17, SUNA, SHIJONAWATE-CITY,OSAKA 575-0001, JAPAN TEL: +81-72-877-1221 FAX: +81-72-878-9649 E-MAIL: hqeigyo@kansai-special.com URL:www.kansai-special.com FOREIGN AFFILIATED COMPANIES KANSAI SPECIAL AMERICAN MACHINE CORP. 476 HAMPSHIRE DR., GAFFNEY, SC 29340. USA E-MAIL: ksam@kansaispecial.net KANSAI SPECIAL EUROPE GMBH QUIRINSTR. 19, 40545 DUSSELDORF, GERMANY TEL: +49-211-577-9090 FAX: +49-211-558-1477 E-MAIL: contact@kansai-special.de...
