Instruction
Installation of Site wireless board
Washers and Dryers with Compass Pro &
Washers with Clarus Vibe
Kit No. 988807301, 432731901
Read the instruction in full
before starting work.
If anything is unclear or
incorrect, please contact
your local sales office or
service representative.
438907726/EN
2025.02.11
Advertisement
Table of Contents
Related Manuals for Electrolux Professional 988807301
Summary of Contents for Electrolux Professional 988807301
- Page 1 Instruction Installation of Site wireless board Washers and Dryers with Compass Pro & Washers with Clarus Vibe Kit No. 988807301, 432731901 Read the instruction in full before starting work. If anything is unclear or incorrect, please contact your local sales office or service representative.
- Page 3 Instruction 1 Safety Precautions for Site wireless board Note! This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter- ference when the equipment is operated in a commercial environment.
-
Page 4: Dimension Drawing
Instruction 2 Dimension drawing 35 mm / 1.38 inch 96.7 mm / 3.81 inch 3.5 mm / 0.14 inch 12 mm / 0.47 inch fig.X03632 3 Contents of the kit fig.X02835A 432689301 Site Wireless Board x 1... - Page 5 Instruction 4 Recycling instruction for packaging fig.X03240A Fig. Description Code Type Bubble foil PE-LD Low density polyethylene Cardboard packaging PAP 20 Corrugated card board...
-
Page 6: Network Overview
8A (option). 5.1 Network overview To be able to use Electrolux Professional provided Connectivity and Management Software Tools, ELS network should be established. The Machine wireless board is a part of ELS Network, it should be installed on each machine with Compass Pro/Cla- rus Vibe control system or Vibe interface and it shall be connected to the CPU RS232 port via a quick connection port behind or on top of the machine. -
Page 7: System Requirements
Instruction WIFI-MESH • Fixed root (C) • Max. 16 layers (Y0–Y16) • Max. 6 children per node (B) • Max. 20 nodes (B) per root (C) L < 10m L < 10m fig.X03193 5.2 System requirements • Min. requirements for commercial router: –... - Page 8 Instruction 5.3 Installing the Site wireless board Decide a proper location where the Site wireless board shall be installed. • The equipment must not be installed at a height over 2 meters without being well secured to its place. • The length of the network cable must not exceed 30 meters. •...
- Page 9 Instruction Connect one end of the network cable to the PoE port on the router (A) and the other end to the Site Wireless Board (B). fig.X02837...
- Page 10 Instruction If the router (C) has no PoE, the local power supply connected via USB-C with output 5V DC/2A Min. – 8A Max. (D) is required to be connected to the Site wireless board. fig.X02838 Take a photo or take a note of the P/N & S/N of the Site wireless board (root node), they are needed in the provision- ing step.
- Page 11 Instruction 6 Adding an extra site wireless board as a repeater If the WiFi signal between the Site wireless board (C) and the Machine wireless board (B) is weak. (Or between the machine (B) and the another machine (B)). There is a possibility to increase the WiFi strength by adding an extra Wireless site board which is switched to be a repeater (RE) in between as illustrated in the below figure.
- Page 12 Instruction Connect the local power supply connected via USB-C with output 5V DC/8A Max. (D) to the Site wireless board. When the board is powered on, change the Site wireless board to be repeater (RE) mode: • Press and hold the button (E) for 5 seconds, then release the button. fig.X02838A •...
- Page 13 Instruction 7 Button & LEDs for Site wireless board Press and hold the button for 5 seconds, then release when it is toggling between Repeater mode and router (nor- mal) mode. A short press (< 1.5s) on the button is toggling the BLE on/off. fig.X02838B D12: Green color / Power Button...
- Page 16 Electrolux Professional AB 341 80 Ljungby, Sweden www.electroluxprofessional.com...
