DEMO MANUAL DC1707
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 0 C9 (OPT)
3 4 C2, C3, C12, C13 CAP ., X5R, 47μF , 10V, 20% 1206
4 1 C4
5 1 C5
6 2 C7, C8
7 1 C10
8 0 C6, C11(OPT)
9 10 E1-E10
10 3 JP1-JP3
11 3 JP1-JP3 SHUNT
12 1 L1
13 1 R1
14 1 R2
15 1 R3
16 1 R4
17 1 R5
18 0 R6 (OPT)
19 1 R7
20 1 U1
21 4 MH1-MH4
22 1
23 1
4
PART DESCRIPTION
CAP ., TANT, 47μF , 10V,20%, 7343
CAP ., TANT, 100μF , 10V, 20%, 7343
CAP ., X5R, 1μF , 10V, 10% 0402
CAP ., X7R, 0.1μF , 16V, 10% 0402
CAP ., X5R, 100μF , 10V, 20% 1210
CAP ., X5R, 470pF , 16V, 10% 0402
CAP ., 0402
TESTPOINT, TURRET, .094"
HEADER 3 PIN 0.079 SINGLE ROW
SHUNT
INDUCTOR, 220nH IHP-2020
Res., CHIP , 24, 1% 0402
Res., CHIP , 100K, 1% 0402
Res., CHIP , 365K, 1% 0402
Res., CHIP , 0, 1% 0402
Res., CHIP , 20K, 1% 0402
Res., 0402
Res., CHIP , 4.7M, 5% 0402
IC., LTC3617EUDD QFN-24 3X5MM
STAND-OFF , NYLON 0.25"
FAB, PRINTED CIRCUIT BOARD
STENCIL
MANUFACTURER/PART NUMBER
AVX, TPSC476M010R0350
AVX, TPSC107M010R0150
TAIYO YUDEN, LMK316BJ476ML-T
MURATA, GRM155R61A105KE15D
MURATA, GRM155R71C104KA88D
TAIYO YUDEN, LMK325BJ107MM-T
AVX, 0402YC471KAT2A
MILL-MAX, 2501-2-00-80-00-00-07
SAMTEC, TMM-103-02-L-S
SAMTEC, 2SN-BK-G
VISHAY, IHLP2020BZERR22M01
VISHAY, CRCW040224R0FKED
VISHAY, CRCW0402100KFKED
VISHAY, CRCW0402365KFKED
VISHAY, CRCW04020000Z0ED
NIC, NRC04F2002TRF
VISHAY, CRCW04024M70JNED
LINEAR TECH., LTC3617EUDD
KEYSTONE, 8831 (SNAP ON)
DEMO CIRCUIT 1707A
STENCIL
