QUICK START PROCEDURE
+
Vref
1.800V
-
+
V
-
+
V
Figure 1. Proper Measurement Equipment Setup
V
OUT
Figure 2. Measuring Input or Output Ripple
DEMO MANUAL DC1707
+
-
A
V
-
V
VTT
+
A
0.2/0.5Ω
-
10W
VTTR
GND
+
+
5V @ 5A
Input Power Supply
-
-
(set to 3.3V)
Connect 0.2Ω to GND (E7)
for Sourcing Current
Connect 0.5Ω to VIN (E1)
for Sinking Current
dc1707f
