CD Duplex Printer

The figure below shows the main parts of the CD single hopper duplex card printers. The main
features and options available for the printer are:
100‐card input tray

Double side color and monochrome printing

Magnetic stripe options (ISO and JIS)

Smart Card reader/writer

Ribbon Cartridge
with Lid
Main Enclosure
100 Card
Hopper
Print Engine Board
(Main Control Board)
1-14




Enclosure Flap
Swingarm Lid
Output tray with 25‐card capacity and reject
tray
100‐card output tray option (N/A on CE units)
200‐card input tray option
Kensington lock
Smart Card in
Duplex Assembly
Simplex Printer
Base Assembly
Hood Enclosure
Smart Card
Enclosure
Introduction
