- Page 1 ASSEMBLY INSTRUCTION HARRISON SINGLE BED ITEM CODE : 81945 1000mm 395mm 2300mm Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please refer to your receipt 81945...
- Page 2 PRE�ASSEMBLY PREPARATION Before you start: 1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product 2. Take care when li�ing. Product should be assembled as near as possible to the point of use 3. Ensure that you have all required contents for complete assembly 4.
-
Page 3: Parts List
PARTS LIST Code Descrip�ons Code Descrip�ons Side Panel L Front Bumper Support L Side Panel R Front Bumper Support R Side Panel L Back Side Bumper L Side Panel R Back Side Bumper R Bumper Top Footboard Bumper Bo�om Headboard 81945... -
Page 4: Hardware List
HARDWARE LIST M8 X 20MM EU 24 Minifix Cam (15/12) M8 X 30MM Unita M6.3 x 40MM M3.5 x 15MM a x 4 b x 4 c x 25 d x 2 e x 12 f x 4 5/8” Z - M4 Barrel Nut M6 x 25MM PVC L Bracket... - Page 5 STEP 1 c x 25 STEP 2 a x 4 81945...
- Page 6 STEP 3 STEP 4 b x 4 81945...
- Page 7 STEP 5 h x 4 e x 4 STEP 6 e x 8 81945...
- Page 8 STEP 7 h x 8 STEP 8 j x 8 81945...
- Page 9 STEP 9 l x 4 g x 2 f x 2 STEP 10 d x 2 k x 4 81945...
- Page 10 STEP 11 j x 4 STEP 12 m x 2 n x 8 f x 2 81945...
- Page 11 STEP 13 o x 1 ASSEMBLY IS COMPLETE 81945...
-
Page 12: Care And Maintenance
CARE AND MAINTENANCE To protect your furniture, we suggest the following: • Avoid placing your furniture in direct sunlight. • Do not place furniture directly under windows. • Do not place sharp materials (knife, fork, etc.) directly onto your furniture as sharp material may scrape and damage the finish. •...
