- Page 1 ASSEMBLY INSTRUCTION SHELTON QUEEN BED 82913 1690MM 2115MM 1100MM Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please refer to your receipt 82913...
-
Page 2: Pre-Assembly Preparation
PRE-ASSEMBLY PREPARATION Before you start: Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product Take care when lifting. Product should be assembled as near as possible to the point of use Ensure that you have all required contents for complete assembly Always read the assembly instructions carefully before beginning assembly. -
Page 3: Parts List
PARTS LIST HEADBOARD HEADBOARD LEG (L+R) FOOTBOARD LEG (L+R) FOOTBOARD SIDE RAIL CENTER RAIL CENTER SUPPORT LEG SLATS Allen Key M4 Allen Key M5 JCBB M8 x 35mm (Long Ball Head) JCBC M6 x 50mm JCBC M6 x 40mm JCBC M6 x 25mm M8 Flat Washer Spring Washer Spring Washer... - Page 4 STEP 1 : Attach (2) to (1) with (C),(G) and (H) Using a Allen Key M5 (B) as shown. STEP 2 : Attach (3) to (4) with (L),(E) and (I) Using a Allen Key M4 (A) as shown. Remarks: arrows sticker points upward 82913...
- Page 5 STEP 3 : Attach (5) to (2) and (3) Assembled Headboard and Footboard as shown. 2&3 2&3 STEP 4 : Attach (8) and (7) to (6) With (D) Using a Allen Key M4 (A) as shown. 82913...
- Page 6 STEP 5 : Attach Assembled Center Support to Assembled Bed with (J) using a Screwdriver as shown. STEP 6 : Attach Assembled Bed Slats to Assembled Bed Frame with (F) Using a Allen Key M4 (A) as shown. 82913...
- Page 7 STEP 7 : Attach Assembled Bed Slats to Assembled Bed Frame with (K) using a Screwdriver as shown. ASSEMBLY IS COMPLETE CAUTION: ALWAYS LIFT YOUR BED WHEN MOVING/RELOCATING - DO NOT DRAG. DRAGGING CAN CAUSE THE CENTRE SUPPORT LEGS TO BEND/BREAK 82913...
-
Page 8: Product Care
PRODUCT CARE: REGULAR CARE: Protect from direct sunlight • Vacuum regularly using low suction • • Do not place sharp materials (knife, fork, etc.) directly onto your furniture as sharp material may scrape and damage the finish. • Do not place material with high temperature directly onto the surface of your furniture. CLEANING: Protect from direct sunlight •...
