ASSEMBLY INSTRUCTIONS
Quadro A
Counter Table Frame
STEP 08
A
Need help!
Call us on
1300 527 665
K
BOTTOM VIEW
nut insert
Place desktops (A) ontop of frames. Nut inserts in top will align
with plastic joiner brackets using M6x30MM (K) sockets attached
tops to frames.
TABLE TOP
nut insert
www.jasonl.com.au
8 of 9
