- Page 1 Programming Guide EvoFlat 4.0 Pro - M © Danfoss | 2024.10 AU505131037251en-010101 | 1...
-
Page 2: Introduction
Programming Guide EvoFlat 4.0 Pro - M 1.0 Introduction This document describes the settings and control options with the ECL220 control for EvoFlat 4.0 Pro M for oor heating. Authorized personnel only Changing the settings in the software requires thorugh knowledge The initial sections descripe the ECL220 control box and connec- of heat regulation. -
Page 3: Table Of Contents
Programming Guide EvoFlat 4.0 Pro - M Table of content Introduction .........................................: ECL220 ..........................................: LED symbols ......................................: 2.1.1 Manual operating ....................................: 2.1.2 Alarm or error ......................................: Electrical wiring .......................................: Application ........................................: ECL Go app........................................: Bluetooth........................................: Commissioning ......................................: Manually ........................................: 5.1.1 Components ......................................:... - Page 4 Programming Guide EvoFlat 4.0 Pro - M Primary supply and external heating control ..........................: 6.4.1 Comissioning ......................................: 6.4.2 Front page ........................................: 6.4.3 Software update ......................................: 6.4.4 Heating circuit ......................................: 6.4.4.1 Primary settings ....................................: 6.4.4.2 Flow temperature ....................................: 6.4.4.3 Optimization ......................................: 6.4.4.4...
-
Page 5: Ecl220
Programming Guide EvoFlat 4.0 Pro - M 2.0 ECL220 The ECL220 is mounted visibly at the top of the station. There are ve LEDs that show the station operating state and indicate if there are errors on the station. 2.1 LED symbols... -
Page 6: Manual Operating
Programming Guide EvoFlat 4.0 Pro - M 2.1.1 Manuel operating It is possible to operate the ECL220 control with- out connecting to it via the ECL Go app. This is done by pressing the button on the left side. Stations with external heating control... -
Page 7: Electrical Wiring
Programming Guide EvoFlat 4.0 Pro - M 2.2 Electrical wiring 3.0 Application 1 ECL220 controller 27C DHW supply temperature sensor (S3) 2 Plate heat exchanger DHW 27D Heating supply temperature sensor (S6) 4 Di erential pressure controller 30 M2 stepper motor Heating... -
Page 8: Ecl Go App
Programming Guide EvoFlat 4.0 Pro - M 4.0 ECL Go app The installer uses the ECL Go app to set up and commissioning the EvoFlat 4.0 Pro station. The app can also be used to optimize the opera- tion and troubleshoot the station. -
Page 9: Commissioning
Programming Guide EvoFlat 4.0 Pro - M 5.0 Commissioning When a station is to be started up for the rst time, it must be commissioned. You can either commission the station manually, byt selecting the operation mode and making all necessary settings for the speci c installation. -
Page 10: Using Template
Programming Guide EvoFlat 4.0 Pro - M 5.2 Using template When commissioning by using a template, you Using templates will save you as an installer a lot will get an overview of the templates that are of time if you have several uniform installations available on your phone. -
Page 11: Setup Guides Oor Heating
Programming Guide EvoFlat 4.0 Pro - M 6.0 Setup guides oor heat- To help the installer, we have subsequently indicated which settings must be decided upon when a station is installed for the rst time. It is important to understand that our setup... -
Page 12: Flow Temperature
Programming Guide EvoFlat 4.0 Pro - M 6.1.4.2 Flow temperature Max ow temperature The max temperature at which the under oor heating must be operated. Depending on the Settings: 5 - 150 °C (default 45 °C) standard outdoor temperature, the heat require- ment of the apartment and the spacing of the under oor heating pipes. -
Page 13: Optimization
Programming Guide EvoFlat 4.0 Pro - M 6.1.4.3 Optimization Total stop This setting must be set to “On”. Settings: On/O (default O ) This means that when the external signal says that there is no need for heating, the station shuts o . -
Page 14: Control Parameters
Normally, you set the time it takes for the actua- tors to close the individual heating circuits. Note: If a Danfoss ICON2 under oor heating control is connected, pump post-run is controlled by it and the setting in the ECL220 should be 0 min. -
Page 15: System
Programming Guide EvoFlat 4.0 Pro - M Valve exercise M2 stepper motor will exercise every day at noon, and by every power cycle as well. Settings: On/O (default O ) External override mode Here you set “Saving when open”, which... -
Page 16: Room Temperature And External Heating Control
Programming Guide EvoFlat 4.0 Pro - M 6.2 Room temperature and external heating control 6.2.1 Comissioning Under commissioning you have choosen room sensor and external heating control. You have had the opportunity to test connected components and now need to set up the station. -
Page 17: Flow Temperature
Programming Guide EvoFlat 4.0 Pro - M 6.2.4.3 Flow temperature Desired ow temperature Here you set the desired supply ow tempera- ture for the oor heating. Settings: 5 - 150 °C (default 34 °C) This setting form the bases for the calculation of the required supply ow temperature. -
Page 18: Control Parameters
Normally, you set the time it takes for the actua- tors to close the individual heating circuits. Note: If a Danfoss ICON2 under oor heating control is connected, pump post-run is controlled by it and the setting in the ECL220 should be 0 min. -
Page 19: Fixed Reference And External Heating Control
Programming Guide EvoFlat 4.0 Pro - M 6.3 Fixed reference and external heating control 6.3.1 Comissioning Under commissioning you have choosen xed reference and external heating control. You have had the opportunity to test connected components and now need to set up the station. -
Page 20: Optimization
These settings should not be changed, as they indicate how the control must regulate. Settings: 0 - 1000 K (default 125 K) Danfoss have come to these settings through thorough test and experience. Settings: 0secs - 16min 39secs (default 1min 30secs) -
Page 21: Application
Normally, you set the time it takes for the actua- tors to close the individual heating circuits. Note: If a Danfoss ICON2 under oor heating control is connected, pump post-run is controlled by it and the setting in the ECL220 should be 0 min. -
Page 22: Primary Supply And External Heating Control
Programming Guide EvoFlat 4.0 Pro - M 6.4 Primary supply and external heating control 6.4.1 Comissioning Under commissioning you have choosen Primary supply and external heating control. You have had the opportunity to test connected components and now need to set up the station. -
Page 23: Optimization
These settings should not be changed, as they indicate how the control must regulate. Settings: 0 - 1000 K (default 125 K) Danfoss have come to these settings through thorough test and experience. Settings: 0secs - 16min 39secs (default 1min 30secs) -
Page 24: Application
Normally, you set the time it takes for the actua- tors to close the individual heating circuits. Note: If a Danfoss ICON2 under oor heating control is connected, pump post-run is controlled by it and the setting in the ECL220 should be 0 min. -
Page 25: Room Sensor And No External Heatin Control
Programming Guide EvoFlat 4.0 Pro - M 6.5 Room sensor and no external heating control 6.5.1 Comissioning Under commissioning you have choosen room sensor and no external heating control. You have had the opportunity to test connected components and now need to set up the station. -
Page 26: Room Limit
Programming Guide EvoFlat 4.0 Pro - M 6.5.4.2 Room limit Enabled Here it is set how the supply ow temperature must be regulated in relation to how well the Settings: On/O (defalut On) heating circuit can heat the reference room. -
Page 27: Return Limit
These settings should not be changed, as they 6.5.4.6 Control parameters indicate how the control must regulate. Settings: 0 - 1000 K (default 125 K) Danfoss have come to these settings through thorough test and experience. Settings: 0secs - 16min 39secs (default 1min 30secs) -
Page 28: Application
Normally, you set the time it takes for the actua- tors to close the individual heating circuits. Note: If a Danfoss ICON2 under oor heating control is connected, pump post-run is controlled by it and the setting in the ECL220 should be 0 min. -
Page 29: Other Settings
Programming Guide EvoFlat 4.0 Pro - M 6.6 Other heating settings The Boost function is intended for the case if you Note: It is not recommended that the user access 6.6.1 Boost have had the heating turned down for a period, the control via ECL Go, because there are many e.g. -
Page 30: Domestic Hot Water
Programming Guide EvoFlat 4.0 Pro - M 7.0 Domestic hot water The settings for DHW are the same no matter which type of regulation is chosen for the under- oor heating. It is important to understand that our setup guides are only indicative and intended as help for the installer. -
Page 31: Dhw Circulation
Programming Guide EvoFlat 4.0 Pro - M 7.2.2 DHW circulation Enable circulation The purpose is to reduce the time from when the tap is opened to hot water is coming out of the Settings On/O (default O ) tap. In larger buildings, the distance from the station... -
Page 32: System Settings
LAN Settings: On/O (default O ) connection. Danfoss o ers a professional online tool for moni- When enabled: toring EvoFlat 4.0 Pro stations. A serial number and installation code is shown. -
Page 33: Modbus Con Guration
Programming Guide EvoFlat 4.0 Pro - M 8.3 Modbus con guration Baudrate The ECL220 has an open Modbus protocol. This makes it possible to integrate the station into an Settings: 9600 external BMS system. 19200 38400 (default) Find the Modbus registers and settings for Mod- 57600 bus in the Modbus protocol. -
Page 34: Save Settings
Programming Guide EvoFlat 4.0 Pro - M 9.0 Save settings It is possible to save the settings. If someone changes the settings afterwards and it does not work, you can reset the control to the last saved settings. When the settings are saved, it is possible to A commissioning report is good documentation 9.1 Commisioning report... -
Page 35: System Overview
Programming Guide EvoFlat 4.0 Pro - M 12.0 System overview Provides an good overvies of the staions current opration state. Thers is an overvies for room heating and one for DHW production. You get an overview of all saved commissioning 13.0 Commissioning reports... - Page 36 AU505131037251en-010101 © Danfoss | DCS-SFDPT/PL | 2024.10 | 36...
