  • Page 2: Copyright Notice

    In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 “Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/ perchlorate” ASRock Rack’s Website: www.ASRockRack.com Setting up the Server in a Restricted Access Location/Restricted Access Area • Access can only be gained by service persons or by users who have been instructed about the reasons for the restrictions applied to the location and about any precautions that shall be taken.

  • Page 4: Replaceable Batteries

    Replaceable Batteries CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS Warning When removal of the chassis lid required for servicing: - Turn off power and unplug any power cords/cables, and - Reinstall the chassis lid before restoring power.

  • Page 5: Table Of Contents

    Contents Chapter 1 Introduction Shipping Box Contents Specifications Chapter 2 Server System Overview System Components Internal Features System Front Panel System Rear Panel Front Control Panel Buttons and LEDs Drive Tray LEDs PSU LED Chapter 3 Hardware Installation and Maintenance Server Top Cover Hard Drive System Fan...

  • Page 7: Chapter 1 Introduction

    2U24E-EGS2 Chapter 1 Introduction Thank you for purchasing 2U24E-EGS2, a reliable barebone system produced under ASRock Rack’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock Rack’s commitment to quality and endurance. This guide provides the instructions of insertion and extraction of chassis components, such as chassis covers, system fans, power supplies, hard disk drive trays, and other main components this system supports.

  • Page 8: Shipping Box Contents

    1.1 Shipping Box Contents Item Quantity 2U24E-EGS2 (2U Barebone) System Board (MB)* Power Supply Unit* System Fan* HDD Backplane (BPB)* Front Panel Board (FPB)* Riser cable* Accessory Box 1U Cooler/Heatsink Slide Rail * The components are pre-installed. If any items are missing or appear damaged, contact the authorized dealer.

  • Page 9: Specifications

    2U24E-EGS2 1.2 Specifications 2U24E-EGS2 System Physical Status Form Factor 2U Rackmount Dimension 800 x 438 x 87.3 mm (31.50'' x 17.24'' x 3.44'') (D x W x H) Support MB SP2C741D32TM3 Front Panel • Power w/ LED Buttons • ID w/ LED •...

  • Page 10: Chapter 2 Server System Overview

    Chapter 2 Server System Overview This chapter provides diagrams showing the location of important components of the server system. 2.1 System Components Add-in card x16 (for PCIE slot on the server board) Add-in card x16 (for PCIE slot on the server board) 2 x Power Supply Units 2 x Hot-swap 2.5"...

  • Page 11: Internal Features

    2U24E-EGS2 2.2 Internal Features From Serverboard Power Supply Units (PSU1) Power Supply Units (PSU2) 2 x 2.5" Hot-swap 2.5" SATA drive bays...
  • Page 12 From System Fan 6 System Fan 5 System Fan 4 System Fan 3 System Fan 2 System Fan 1 2.5" Drive Backplane Board 24 x Hot-swap 2.5" NVMe Drive Bays Add-in card 1 x16 (for PCIE slot on the server board) Add-in card 2 x16 (for PCIE slot on the server board)

  • Page 13: System Front Panel

    2U24E-EGS2 2.3 System Front Panel Description 2 x USB3.2 Gen1 Control Panel (depends on the specification of the server board) 24 x Hot-swap 2.5" NVMe Drive Bays 2.4 System Rear Panel Description 2 x Power Supply Units (PSU) Rear Vent I/O Shield (depends on the specification of the server board) 2 x Hot-swap 2.5"...

  • Page 14: Front Control Panel Buttons And Leds

    2.5 Front Control Panel Buttons and LEDs Description Power Button and LED System Status LED ID Button and LED System Reset Button *Please be noted that the functions are supported depending on the type of the server board.
  • Page 15 2U24E-EGS2 System Reset Button When the system is completely unresponsive, press the system reset button to reboot the server without shutting it off and initialize the system. ID Button Press the ID button to toggle the front panel ID LED and the baseboard ID LED on and off.

  • Page 16: Drive Tray Leds

    2.6 Drive Tray LEDs 3.5" Drive Tray Description HDD Power LED HDD Activity LED Status LED Definitions HDD Power LED Status Description Solid Blue HDD powered-on No power to HDD HDD Activity LED Status Description Solid Green HDD active Blinking Green HDD accessing or reading Solid Red HDD failed...
  • Page 17 2U24E-EGS2 2.5" Drive Tray Description HDD LED Status LED Definitions HDD LED Status Description Solid Green HDD active Blinking Green HDD accessing or reading Solid Red HDD failed Blinking Red (4Hz) HDD positioning Blinking Red (1Hz) HDD reconnection HDD powered-off...

  • Page 18: Psu Led

    2.7 PSU LED PSU LED PSU Status LED Status Description Green Normal work; output ON and OK Amber Module fault/protection in operating mode (failure, OCP, OVP, Fan Fail, OTP, UVP) AC cord unplugged Amber blinking at 0.5Hz Warning (high temp, high power, high current, slow fan) Green blinking at 0.5Hz AC Present Only 12VSB on (PS off) or PS in Smart Redundant state...

  • Page 19: Chapter 3 Hardware Installation And Maintenance

    2U24E-EGS2 Chapter 3 Hardware Installation and Maintenance This chapter helps user to assemble the chassis and install components. Before You Begin Before working with the server, pay close attention to the “Important Safety Instructions” at the beginning of this manual.

  • Page 20: Server Top Cover

    3.1 Server Top Covers Removing the Server Top Covers 1. Before removing the top covers, power off the server and unplug the power cord. 2. The system must be operated with all the chassis top covers installed to ensure proper cooling. 1.
  • Page 21 2U24E-EGS2 1. Lower the top rear cover on the chassis, making sure the side latches align with the cutouts. Slide the top rear cover toward the FRONT of the chassis. 2. Secure the top rear cover until it is locked in place.

  • Page 22: Hard Drive

    3.2 Hard Drive Removing 2.5” and 3.5” Hard Drive 1. Press the locking lever latch on the drive tray to unlock the retention lever. 2. Rotate the lever out and away from the module bay and pull the hard drive out of the drive tray.
  • Page 23 2U24E-EGS2 Installing a 2.5” Hard Drive to the Hard Drive Tray 1. Engage the one side of hard drive into the tray by aligning the side bracket. 2. Carefully push down the other side of the hard drive until it is locked into place.
  • Page 24 Rear Panel-Installing the HDD assembly 1. Slide the drive tray into the HDD bay until the drive is fully seated. 2. Push in the locking lever to lock the drive tray into place.

  • Page 25: System Fan

    2U24E-EGS2 3.3 System Fan Replacing the System Fan 1. Align the mounting holes on the fan bar with the fan mount on the replacement fan. 2. Please be aware of the mount location of each fan. 3. Gently place the fan on the fan bar. Make sure the fan is well seated.

  • Page 26: Power Supply

    3.4 Power Supply Installing the Power Supply Unit Carefully slide the PSU all the way into the power supply bay until it clicks into place.

  • Page 27: Add-In Card

    2U24E-EGS2 3.5 Add-in Card 1. You can install an add-on card to the chassis only when you have a riser card installed on the server board. 2. Before installing the add-on card, power off the server and unplug the power cord.
  • Page 28 Installing the Add-in Card 1. Remove the screws and plate. 2. Install the add-in card to the riser-card bracket blanking. 3. Secure the add-in card to the assembly with screws.
  • Page 29 2U24E-EGS2 4. Secure the assembly to the chassis. 5. Lock the screws. 6. Install the duct bracket over the duct assembly and lock it in place with the chassis. 7. Lock the screws by hand.
  • Page 30 Installing the CPU (LGA 4677 Socket) Unplug all power cables before installing the CPU. Socket Dust Cover CPU Carrier...
  • Page 31 2U24E-EGS2...
  • Page 33 2U24E-EGS2 CPU Carrier...
  • Page 34 Heatsink CPU Carrier Socket...
  • Page 35 2U24E-EGS2...

  • Page 36: Installation Of Memory Modules (Dimm)

    Appendix Installation of Memory Modules (DIMM) The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation. For more information about DIMM installation, please refer to the User Manual that comes with the server board used.
  • Page 37 2U24E-EGS2 Type B (Two Clips)
  • Page 38 Appendix C Block Diagram (SP2C741D32TM3)

  • Page 39: Contact Information

    2U24E-EGS2 Contact Information Contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at http://www.asrockrack.com; or contact the dealer for further information. For technical questions, please submit a support request form at https://event.
