OPTIONAL
REQUIRED TOOLS
16mm Wrench
16mm Socket
18mm Wrench
18mm Socket
Phillips Screwdriver
Drill (for Winch Plate)
7/16" Drill Bit
Front Stubby Winch Bumper w/ Tube
HARDWARE CONTENTS
M10 Hex Bolt
M10 Lock Washer
M10 Flat Washer
M10 Nut
M4 Card Holder Nut
M4 Screw
M4 Lock Washer
M4 Flat Washer
D-Rings
FB22001
Jeep® JK Wrangler
QTY
4
12
12
8
8
8
8
8
2
2200100
Advertisement
Related Manuals for Fishbone Offroad FB22001
Summary of Contents for Fishbone Offroad FB22001
- Page 1 FB22001 Jeep® JK Wrangler Front Stubby Winch Bumper w/ Tube OPTIONAL REQUIRED TOOLS HARDWARE CONTENTS 16mm Wrench M10 Hex Bolt 16mm Socket 18mm Wrench M10 Lock Washer 18mm Socket Phillips Screwdriver M10 Flat Washer Drill (for Winch Plate) 7/16” Drill Bit...
- Page 2 FB22001 Jeep® JK Wrangler Front Stubby Winch Bumper w/ Tube REMOVE YOUR FACTORY BUMPER Begin by removing your factory bumper. Ensure you disconnect your factory fog lights before you pull your bumper away. Remove your factory fog lights carefully to be reused in the new bumper.
- Page 3 RUN YOUR WIRING Reconnect your factory fog lights and wire your winch following the manufacturer’s instructions. ENJOY YOUR NEW FISHBONE OFFROAD BUMPER! WITH THE WEIGHT OF THE WINCH AND BUMPER, IT IS HIGHLY ADVISED TO HAVE HELP WHEN INSTALLING THE BUMPER!
