REQUIRED TOOLS
18mm Wrench/Socket
16mm Wrench/Socket
Phillips Screwdriver
Manowar JK Front Winch Bumper
KIT CONTAINS
M12 Hex Bolt
M12 Flat Washer
M12 Lock Washer
M12 Nut
M10 Flat Washer
M10 Lock Washer
M10 Nut
M4 Card Holder Nut
M4 Screw
M4 Lock Washer
M4 Flat Washer
D-Rings
FB22045
Jeep® JK Wrangler
QTY
4
8
4
4
8
8
8
8
8
8
8
2
2204500
Advertisement
Related Manuals for Fishbone Offroad FB22045
Summary of Contents for Fishbone Offroad FB22045
- Page 1 FB22045 Jeep® JK Wrangler Manowar JK Front Winch Bumper REQUIRED TOOLS KIT CONTAINS 18mm Wrench/Socket M12 Hex Bolt 16mm Wrench/Socket M12 Flat Washer Phillips Screwdriver M12 Lock Washer M12 Nut M10 Flat Washer M10 Lock Washer M10 Nut M4 Card Holder Nut...
- Page 2 FB22045 Jeep® JK Wrangler Manowar JK Front Winch Bumper REMOVE YOUR FACTORY BUMPER Begin by removing your factory bumper. Ensure you disconnect your factory fog lights before you pull your bumper away. Remove your factory fog lights carefully to be reused in the new bumper.
- Page 3 Using one (1) M10 nut, lock washer, and flat washer per stud, secure the bumper to the Jeep. MOUNT THE SUPPLIED D-RINGS ELECTRICAL Reconnect your factory fog lights and wire your winch following the manufacturer’s instructions. ENJOY YOUR NEW FISHBONE OFFROAD BUMPER! 2204500...
