Operating instructions
Betriebsanleitung
Mode d'emploi
Manual de instrucciones
PSD-30
Pressure switch /
Druckschalter /
Pressostat /
Interruptor automático por
aumento de presión
PSD-30
Advertisement
Table of Contents
Related Manuals for WIKA PSD-30
Summary of Contents for WIKA PSD-30
- Page 1 Se aplican nuestras condiciones actuales aumento de presión de venta y de suministro, que se pueden consultar en ... www.wika.de PSD-30 WIKA Alexander Wiegand SE & Co. KG Alexander-Wiegand-Straße 30 63911 Klingenberg Germany Phone +49 (0) 93 72/132-295 +49 (0) 93 72/132-706 E-Mail support-tronic@wika.de...
- Page 2 5. Para su seguridad 6. Embalaje 6. Verpackung 7. Puesta en servicio, funcionamiento 7. Inbetriebnahme, Betrieb 8. Wartung, Zubehör 8. Mantenimiento, accesorios 9. Störbeseitigung 9. Eliminación de perturbaciones 10. Almacenaje, eliminación de desechos 10. Lagerung, Entsorgung WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30...
-
Page 3: Important Details For Your Information
Our environmental manage- ment system is certified to DIN EN ISO 14001. Use of the product in accordance with the intended use PSD-30: Use the pressure switch (indoor and outdoor) transform the pressure into an electrical signal. -
Page 4: Signs, Symbols And Abbreviations
This electric signal changes in proportion to the pressure and can be evaluated correspondingly. WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30... -
Page 5: For Your Safety
Take precautions with regard to remaining media in removed pressure transmitter. Remaining media in the pressure port may be hazardous or toxic! Have repairs performed by the manufacturer only. Open circuit before removing connector. WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30... -
Page 6: Starting Operation
Inspect the pressure switch for possible damage during transportation. Should there be any obvious damage, inform the transport company and WIKA without delay. Keep the packaging, as it offers optimal protection during transportation (e.g. chan- ging installation location, shipment for repair). - Page 7 Product-No. Serial-No. PIN assignment Coded manufacture date Please refer to our data sheet “Pressure gauge sealing washers AC 09.08” in WIKA’s product catalog Pressure and Temperature Measurement or our website www.wika.de for details about sealing washers. When mounting the instrument, ensure that the sealing faces of the instrument and ...
- Page 8 IP 65 and IP 67 IP 65 and IP 67 IEC 60 529 The ingress protection classes specified only apply while the pressure transmitter is connected with female connectors that provide the corresponding ingress protection. WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30...
- Page 9 Pressure sensor 316 L (up to 0 ... 10 bar rel 13-8 PH) Case » Lower body 316 L » Plastic head Highly resistive, fibreglass-enforced plastic (PBT) » Keyboard TPE-E » Display disc WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30...
- Page 10 Including non-linearity, hysteresis, zero point and full scale error (corresponds to error of measurement per IEC 61298-2) ≤ ± 0.5 Non-linearity % of span (BFSL) according to IEC 61298-2 ≤ 0.2 Long-term drift % of span according to IEC 61298-2 WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30...
- Page 11 { } Items in curved brackets are optional extras for additional price. When designing your plant, take into account that the stated values (e.g.burst pressure, over pressure safety) apply depending on the material, thread and sealing element used. WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30...
- Page 12 Mode, otherwise it reverts to Display Mode. short press: short press: display units - Select Menu Item - Confirmation of the entry (Parameter value) short press (both keys at the same time): INFO Return to Display Mode MENU WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30...
- Page 13 FNC = Window Function, normally closed UNIT Changing Units (If the pressure range is higher than the display range, no change of the unit is posssible and the parameter UNIT is not shown) WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30...
- Page 14 Instrument Nominal Pressure - 10% RP1 / FL1 value (Min: LLR + 0.5% Max: ULR) Instrument Nominal Pressure SP2 / FH2 value (Min: LLR Max: SP2 - 0.5%) Instrument Nominal Pressure- 10% RP2 / FL2 value WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30...
- Page 15 DISU value YES/NO DISR (Display rotate 180°) YES/NO (Reset HIGH, LOW) value (Password) without (Measuring Point number) without value Display-Mode Legend: LLR = lower limit of range ULR = upper limit of range WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30...
-
Page 16: Switch Function
If the switching event no longer pertains when the delay time has elapsed, the switching output does not change. WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30... -
Page 17: Maintenance, Accessories
Have repairs performed by the manufacturer only. Accessories: Mounting clamp (Order No. 11467887) For details about the accessories (e. g. connectors), please refer to WIKA‘s price list or contact our sales department. . Trouble shooting Open pressure connections only after the system is without pressure! - Page 18 This Return Form contains information on all materials with which the instrument has come into contact, either through installation, test purposes, or cleaning. You can find the Product Return Form on our internet site (www.wika.de / www.wika.com). WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30...
-
Page 19: Storage, Disposal
Dispose of instrument components and packaging materials in accordance with the respective waste treatment and disposal regulations of the region or country to which the instrument is supplied. WIKA reserves the right to alter these technical specifications. WIKA Operating instructions/Betriebsanleitung/Mode d'emploi/Instrucciones de servicio PSD-30...
