EN User Manual | Cooker
LKR62001CW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LKR62001CW and is the answer not in the manual?

Questions and answers

Summary of Contents for Electrolux LKR62001CW

  • Page 1 EN User Manual | Cooker LKR62001CW...
  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................9 5.
  • Page 3: General Safety

    • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down.
  • Page 4 • CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously. • WARNING: Danger of fire: Do not store items on the cooking surfaces. • Do not use a steam cleaner to clean the appliance. •...
  • Page 5: Safety Instructions

    • The means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance.
  • Page 6: Care And Cleaning

    The isolation device must have a contact • Do not let sparks or open flames to come opening width of minimum 3 mm. in contact with the appliance when you • Fully close the appliance door before you open the door. connect the mains plug to the mains •...
  • Page 7: Internal Lighting

    • Make sure the appliance is cold. There is These lamps are intended to withstand the risk that the glass panels can break. extreme physical conditions in household • Replace immediately the door glass appliances, such as temperature, panels when they are damaged. Contact vibration, humidity, or are intended to the Authorised Service Centre.
  • Page 8: Levelling Of The Appliance

    Minimum distances Dimension 3.3 Levelling of the appliance CAUTION! Make sure you install the anti-tilt protection at the correct height. Make sure that the surface behind the appliance is smooth. 1. Set the correct height and area for the Use small feet on the bottom of appliance to appliance before you attach the anti-tilt set the appliance top surface level with other protection.
  • Page 9: Electrical Installation

    Applicable types of cables for different 24 mm phases: Phase Min. size cable 3x6.0 mm² 3 with neutral 5x1.5 mm² WARNING! The power cable must not touch the part of the appliance shaded in the illustration. 3.5 Electrical installation WARNING! The manufacturer is not responsible if you do not follow the safety precautions from Safety chapters.
  • Page 10: Before First Use

    4.2 Hob overview Cooking zone Residual Heat Indicator 4.3 Accessories 145 mm 180 mm • Wire shelf For cookware, cake tins, roasts. • Baking tray 210 mm 145 mm For cakes and biscuits. • Storage drawer The storage drawer is below the oven cavity.
  • Page 11: Residual Heat Indicator

    The indicator appears when a cooking zone is hot, but it does not function if mains power is disconnected. Use the residual heat to decrease energy consumption. Deactivate the cooking The indicator may also appear: zone approximately 5 - 10 minutes before •...
  • Page 12: Hob - Care And Cleaning

    Heat setting Use to: Time Hints (min) Keep cooked food warm. as neces‐ Put a lid on the cookware. sary 1 - 2 Hollandaise sauce; melt: butter, choco‐ 5 - 25 Mix from time to time. late, gelatine. Solidify: fluffy omelettes, baked eggs. 10 - 40 Cook with a lid on.
  • Page 13: Oven - Daily Use

    • Remove shiny metallic discoloration: use a solution of water with vinegar and clean the glass surface with a cloth. 9. OVEN - DAILY USE WARNING! Moist Fan Baking Refer to Safety chapters. This function was used to comply with the Energy Efficiency Class and Ecodesign Regulations (according to EU 65/2014 and 9.1 Heating functions...
  • Page 14: Cooling Fan

    3. To deactivate the oven turn the knobs for Wire shelf: the oven functions and temperature to the Push the shelf between the guide bars of the off position. shelf support. 9.3 Cooling fan When the oven operates, the cooling fan turns on automatically to keep the surfaces of the oven cool.
  • Page 15 Cakes in tin Food Temperature (°C) Time (min) Shelf position Soufflè 30 - 40 Sponge flan base 20 - 30 Victoria sandwich 25 - 35 Fish Food Temperature (°C) Time (min) Shelf position Fish in pouches 300 g 25 - 35 Whole fish 200 g 25 - 35 Fish fillet 300 g...
  • Page 16: Information For Test Institutes

    10.2 Information for test institutes Food Function Time (min) Accesso‐ Shelf po‐ ries sition (°C) Small cakes (20 small Conventional Cooking 20 - 30 Tray cakes per tray) Small cakes (20 small True Fan Cooking 20 - 30 Tray cakes per tray) Small cakes (20 small True Fan Cooking 25 - 35...
  • Page 17: Removing The Shelf Supports

    mild detergent. Clean and check the door gasket around the frame of the cavity. • Use a cleaning solution to clean metal surfaces. • Clean stains with a mild detergent. Everyday Use • Clean the cavity after each use. Fat accumulation or other residue may cause fire.
  • Page 18: Replacing The Lamp

    11.7 Replacing the lamp 2. Move the slider until you hear a click. 3. Close the door until the slider locks. 4. Remove the door. WARNING! To remove the door, pull the door Risk of electric shock. outwards first from one side, and then the The lamp can be hot.
  • Page 19: Troubleshooting

    Do not remove the rating plate from the appliance cavity. 13. ENERGY EFFICIENCY 13.1 Product Information according to EU Ecodesign Regulations for Hob Model identification LKR62001CW Type of hob Hob inside Freestanding Cooker Number of cooking zones ENGLISH...
  • Page 20: Hob - Energy Saving

    13.3 Product Information Sheet and Product Information according to EU Energy Labelling and Ecodesign Regulations for Oven Supplier's name Electrolux Model identification LKR62001CW 940003106 Energy Efficiency Index 95.3 Energy efficiency class Energy consumption with a standard load, conventional mode 0.95 kWh/cycle Energy consumption with a standard load, fan-forced mode 0.82 kWh/cycle...
  • Page 21: Environmental Concerns

    Keep the door gasket clean and make sure it minimum 3 - 10 min before the end of is well fixed in its position. cooking. The residual heat inside the appliance will continue to cook. Use metal cookware and dark, non-reflective tins and containers to improve energy saving.
  • Page 24 867364002-B-052024...
