Operating instructions
Safety-monitoring module
Operating instructions. . . . . . . . . . . .pages 1 to 10
EN
Original
Content
1
About this document
1.1 Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.2 Target group: authorised qualified personnel. . . . . . . . . . . . . . . . . .1
1.3 Explanation of the symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.4 Appropriate use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1.5 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1.6 Warning about misuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1.7 Exclusion of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2
2.1 Ordering code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2.2 Special versions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2.3 Destination and use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2.4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2.5 Derating / electrical lifespan of safety contacts . . . . . . . . . . . . . . . .3
2.6 Safety classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
3
3.1 General mounting instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3.2 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
4
4.1 General information for electrical connection. . . . . . . . . . . . . . . . . .4
4.2 Coding of connecting terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
5
5.1 Description of the terminals and LED indications . . . . . . . . . . . . . .4
rotary mode switch 1 and 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
5.3 Changing setting or application . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
6
6.1 LED indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
6.2 Malfunctions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
7
7.1 Possible applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
7.2 Application example. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
7.3 Start configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
7.4 Feedback circuit / Release signal . . . . . . . . . . . . . . . . . . . . . . . . . .7
7.5 Sensor configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
8
8.1 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
8.2 Functional testing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
8.3 Behaviour in the case of faults. . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
8.4 Setting report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
8.5 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
9
9.1 Disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
9.2 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
10.1 Wiring/circuit information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
1. About this document
1.1
Function
This operating instructions manual provides all the information you
need for the mounting, set-up and commissioning to ensure the safe
operation and disassembly of the safety-monitoring module. The
operating instructions must be available in a legible condition and
a complete version in the vicinity of the device.
1.2
Target group: authorised qualified personnel
All operations described in this operating instructions manual must
be carried out by trained specialist personnel, authorised by the plant
operator only.
Please make sure that you have read and understood these operating
instructions and that you know all applicable legislations regarding
occupational safety and accident prevention prior to installation and
putting the component into operation.
The machine builder must carefully select the harmonised standards
to be complied with as well as other technical specifications for the
selection, mounting and integration of the components.
1.3
Explanation of the symbols used
Information, hint, note:
This symbol is used for identifying useful additional information.
Caution: Failure to comply with this warning notice could
lead to failures or malfunctions.
Warning: Failure to comply with this warning notice could
lead to physical injury and/or damage to the machine.
EN
SRB-E-402ST
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for schmersal SRB-E-402ST-CC
Summary of Contents for schmersal SRB-E-402ST-CC
-
Page 1: Table Of Contents
Operating instructions Safety-monitoring module SRB-E-402ST Wiring examples 7.1 Possible applications ........6 7.2 Application example. -
Page 2: Appropriate Use
Safety-monitoring module SRB-E-402ST 2. Product description Appropriate use Products in Schmersal’s range are not intended to be used by private end consumers. Ordering code This operating instructions manual applies to the following types: The products described in these operating instructions are developed SRB-E-402ST- ➀... -
Page 3: Derating / Electrical Lifespan Of Safety Contacts
Operating instructions Safety-monitoring module SRB-E-402ST UL Rating of external fuse: max. 16 A, only use fuses in Derating / electrical lifespan of safety contacts accordance with UL 248 series No derating with individual installation of modules. Insulation values to EN 60664-1: Rated insulation voltageU Derating on request if several modules are installed one after the - safety contacts:... -
Page 4: Mounting
Operating instructions Safety-monitoring module SRB-E-402ST 3. Mounting 5. Operating principle and settings General mounting instructions Description of the terminals and LED indications Mounting: snaps onto standard rails to EN 60715. Function Function Hook bottom of enclosure in rail and push down until it engages in Operating voltage Operating voltage OK position. -
Page 5: Applications For Two Safety Functions Can Be Set Separately Using Rotary Mode Switch 1 And 2
Operating instructions Safety-monitoring module SRB-E-402ST Adjustment of application using rotary “mode” switch • Open front transparent cover (see fig.). • Opening is carried out by lifting side with lock. • Select desired application for safety function 2 using rotary mode switch 2 (1 …... -
Page 6: Diagnostic
RUN, In 1/2, In 3/4, operating voltage Out 1, Out 2 Application was LEDs flash quickly: changed during In 1/2, In 3/4, active operation Out 1, Out 2 Other fault codes: Consult technical sales dept. at Schmersal... -
Page 7: Start Configuration
Operating instructions Safety-monitoring module SRB-E-402ST Wiring example SRB-E-402ST +24VDC Safety function 1 Safety function 2 S 11 S 21 S 22 S 12 S 31 S 41 S 42 S 32 a) Safety inputs b) Safety outputs Safety function 2 Q1 Q2 c) Signalling outputs d) Clock outputs... -
Page 8: Sensor Configuration
Operating instructions Safety-monitoring module SRB-E-402ST Sensor configuration Dual channel signal processing NC / NO (Cat. 4 – PL e to EN ISO 13849-1 possible) Single channel signal processing Safety function 1 Safety function 2 Safety function 1 S11 S21 +24 VDC S31 S41 +24 VDC S11 S21... -
Page 9: Set-Up And Maintenance
Operating instructions Safety-monitoring module SRB-E-402ST +24 VDC +24 VDC +24 VDC +24 VDC +24 VDC Maintenance A regular visual inspection and functional test, including the following steps, is recommended: 1. Check the correct fixing of the safety-monitoring module 2. Check the cable for damages 3. -
Page 10: Eu Declaration Of Conformity
Safety-monitoring module SRB-E-402ST EU Declaration of conformity EU Declaration of conformity Original K.A. Schmersal GmbH & Co. KG Möddinghofe 30 42279 Wuppertal Germany Internet: www.schmersal.com We hereby certify that the hereafter described components both in their basic design and construction conform to the applicable European Directives.
