Backlight Management

Description Command Code
Set Backlight FE 09 58 42 48 43 4D
Brightness
Get Backlight FE 08 58 42 48 43 4D
Brightness
Set Backlight FE 09 58 42 48 43 4D
Mode
Get Backlight FE 08 58 42 48 43 4D
Mode
Get Backlight FE 08 58 42 48 43 4D
Switch Status
Set Backlight FE 09 58 42 48 43 4D
Switch Status
44 03 04 XX CF
44 02 04 CF
44 03 05 XX CF
44 02 05 CF
44 02 0A CF
44 03 0A XX CF
Response Code
FE 0A 58 42 48 43 4D
44 03 04 XX YY CF
FE 09 58 42 48 43 4D
44 02 04 XX CF
FE 0A 58 42 48 43 4D
44 03 05 XX YY CF
FE 09 58 42 48 43 4D
44 02 05 XX CF
FE 09 58 42 48 43 4D
44 02 0A XX CF
FE 0A 58 42 48 43 4D
44 03 0A XX YY CF
133
Return Code
Note
Description
XX: Indicates
the brightness
value (0~100),
corresponding
to hexadecimal:
00~64
YY:
00: Fail
01: Success
XX: Indicates
the brightness
value (0~100),
corresponding
to hexadecimal:
00~64
XX:
00: Standard
01: Energy Saving
02: Automatic
03: Custom
YY:
00:Fail
01: Success
XX:
00: Standard
01: Energy Saving
02: Automatic
03: Custom
XX:
00: Off
01: On
XX:
00: Off
01: On
YY:
00: Fail
01: Success
