ViewSonic ViewBoard IN01 Series User Manual page 13

Control Panel and Front I/O - IN6501
TOUCH
1
Number
1
2
3
4
USB USB
3 3
5
USB USB
3 3 4
6
4 5
HDMI USB
2 3
Item
• USB Type B.
• USB 2.0 standard.
• Touch signal output to external computer.
TOUCH
• After connection (with an external computer), the
device connected to the USB port can directly be used
by the external computer.
• Pairs with the front HDMI port next to it.
• HDMI input.
• Connect to a computer with HDMI output, set-top box,
HDMI
or other video device.
• Supports 4K display; HDMI 2.0.
• USB Type A.
• USB 3.0 standard.
USB
• Connect USB devices such as hard disks, keyboard,
mouse, etc.
• USB Type C.
• USB 2.0 standard.
• Connect USB devices such as hard disks, keyboard,
4
mouse, etc.
Remote control receiver.
• Power indicator light.
5 6
• Press to turn on the display.
• Once on, press again to turn on or off the backlight only.
• Once on, press and hold to turn off the display.
6
USB USB
3 3
Description
5
13
4 5
6
6
