ViewSonic ViewBoard IFP50 Series Quick Start Manual

Commercial touch display
Hide thumbs Also See for ViewBoard IFP50 Series:
1
2
3
4
5
6

Advertisement

Table of Contents

1
Package Contents
● Power cable x 4
● Quick start guide
● Remote control
● RS232 adapter
● AAA battery x 2
● Clamp x 5
● USB cable
● Plate
● AV cable
● Screw x 7
● Stylus pen x 2
● Input compatible with HDMI
ViewBoard IFP50 series
Commercial Touch Display
Quick Start Guide
2
Wall Mount Kit Specifications (VESA)
inch
VESA Spec. (A x B)
IFP5550 - 55"
400 x 400 mm
IFP6550 - 65"
600 x 400 mm
IFP7550 - 75"
800 x 400 mm
IFP8650 - 86"
800 x 600 mm
Standard Screw (C x D)
Quantity
M8 x 25 mm
4
M8 x 25 mm
4
M8 x 25 mm
4
M8 x 25 mm
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ViewBoard IFP50 Series and is the answer not in the manual?

Questions and answers

Related Manuals for ViewSonic ViewBoard IFP50 Series

Summary of Contents for ViewSonic ViewBoard IFP50 Series

  • Page 1 Wall Mount Kit Specifications (VESA) ViewBoard IFP50 series Commercial Touch Display Quick Start Guide Package Contents ● Power cable x 4 ● Quick start guide ● Remote control ● RS232 adapter ● AAA battery x 2 ● Clamp x 5 ●...
