- Page 1 TGS-3109XT Quick Installation Guide 04-2024 / V1.0...
-
Page 2: Table Of Contents
Contents I. Product Information ..........1 I-1. Package Contents ..............1 I-2. Hardware Overview ............. 1 I-3. LED Status................2 II. Installation .............. 2 II-1. Physically Setup ..............2 II-2. Connection ................4 III. Web-based Configuration ........5 I. More Information ............ 7 II. -
Page 3: Product Information
I. Product Information TGS-3109XT: 8-Port 2.5GbE Web Smart Switch with 1 10GbE Multi-Gigabit Port. I-1. Package Contents Power Adapter Quick Installation TGS-3109XT (12V) Guide I-2. Hardware Overview PWR LED 10GbE Multi-Gigabit 2.5GbE RJ45 Port Link/Act LED Reset RJ45 Port (Port 9) -
Page 4: Led Status
I-3. LED Status Function Color Status Description Power on Green Power off Link at 2.5/5/10Gbps Green Blinking Sending or receiving data Port disconnected or link fail Link/Act (Port 1-9) Link at 100M/1000Mpps Amber Blinking Sending or receiving data Port disconnected or link fail II. - Page 5 2. Wall-mount the switch: You can mount the switch on a wall. The switch is designed with mounting holes. Two sets of wall-mounted screws are required. For wall-mounted installation, please refer to the figure below (this product does not come with wall-mounted installation screws and accessories).
-
Page 6: Ii-2. Connection
II-2. Connection 1. Power on: Connect the power adapter to the switch and the power outlet. Turn on the power switch by clicking the power button. The switch is powered by the 100-240VAC 50/60Hz external power supply. (Note: Make sure the PWR LED is green.) 2. -
Page 7: Web-Based Configuration
III. Web-based Configuration This section describes how to navigate the web-based switch configuration utility through web browser. Be sure to disable any browser pop-up blocker. Browser Restrictions If you are using older versions of Internet Explorer, you cannot directly use an IPv6 address to access the device. - Page 8 Note: Password ONLY accept "a-z","A-Z","0-9" and the length is at least 4 and up to 20 characters. 5. For more information about Web-based Configuration Utility, please download User Manual from EDIMAX official website. https://www.edimax.com/download/...
-
Page 9: More Information
For detailed instructions, you can find user manual and all supporting documents from the link below or via the QR code: https://www.edimax.com/download/ Please search the model name “TGS-3109XT” to enter the referred page. Safety Instructions The following general safety guidelines are provided to help ensure your own personal safety and protect your product from potential damage. - Page 10 COPYRIGHT Copyright Edimax Technology Co., Ltd. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission from Edimax Technology Co., Ltd.
- Page 11 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 12 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2014/30/EU. Français: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2014/30/EU. Čeština: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanoveními směrnic 2014/30/EU.
- Page 13 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directives. Equipment: 8-port 2.5G Base-T + 1 port 10G Base-T Web-lite Switch Model No.: TGS-3109XT...
- Page 14 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the United Kingdom EMC and Safety directives. Equipment: 8-port 2.5G Base-T + 1 port 10G Base-T Web-lite Switch Model No.: TGS-3109XT...
