OPERATION
Note: A dump valve with 2-way, 2-position is equipped on
the pump to use with Single-acting cylinders or applications.
1. Check oil level, add oil if necessary.
2. Make sure system fittings and connections are tight and
leak free.
3. To start the motor: Toggle the ON/OFF switch located on
the control box to 'ON' position
4. To Advance: Push 'U' button on pendant control unit for
momentary use, or hold the button for continue operation
A Port Advance.
5. To Retract: Release 'U" button, if there are no any action
on pendant control unit, cylinder will be retracted.
6. To turn off the motor: Toggle the ON/OFF switch located
on the control box to 'OFF' position.
7. It is recommended to use to ON/OFF switch at the control
box to let the pump idle for a few minutes before putting
into operation.
8. Always monitor the pressure, load and position, pump's
pressure rating is 10,000 PSI.
9. Do not exceed the rated capacity of the equipment
connected to the pump. To reduce system component
stress, material fatigue, and the risk of personal injury
and property damage, never load a hydraulic application
(torque wrench, cylinder, spreader, etc.) to more than
80% of its rated capacity.
10. Depressurize all connections before disconnect
hydraulic tools. If you have any questions, call BVA
Technical Service @ (888)-332-6419.
MAINTENANCE
1. Keep areas around pump unobstructed in order to provide
good air flow around the motor and pump. Try keep the
motor and pump as clean as possible.
2. Inspect hoses and connections daily. Replace damaged
components immediately with BVA replacement parts only.
3. Tighten connections as needed. Use non-hardening pipe
thread compound when servicing connections.
4. Check hydraulic oil level every 40 hours of operation. Add
hydraulic oil if necessary.
5. Completely change the hydraulic oil every 300 hours of
operation. Change the oil more frequently when pump is
used in an extremely dusty environment or when the oil
has been overheated. Use only good quality hydraulic oil.
We recommend BVA FJZ01 or equivalent. To order the oil,
refer to service parts section.
Note: Use only a good quality hydraulic oil. Never use brake
fluid, transmission fluid, turbine oil, motor oil, alcohol, glycerin
etc. Use of other than recommended hydraulic oil, will void
warranty and damage the pump, hose, and application.
Adding Hydraulic Oil
1. Make sure electric motor is OFF.
2. Depressurize and disconnect hydraulic hose from
application.
3. Remove vent cap on the top plate of the reservoir.
4. Use a funnel to fill reservoir to about 2" from top of
reservoir plate.
5. Wipe up any spilled fluid and reinstall the vent cap.
! DANGER
TO AVOID ELECTROCUTION HAZARD:
• Owner, Operator must read, understand and
follow all printed material provided with this
device before use.
• Connect ONLY to properly grounded electrical
source. Connect to GFI outlet ONLY! For use
in dry locations.
• Avoid the use of extension cords. If used, extension cord
lengths up to 25 ft shall be SJT-14X3 or heavier. For cords
up to 50 ft, use SJT-12X3 or heavier. For extension cord
lengths up to 100 ft, use SJT-10X3 or heavier. NEVER
use a 3 prong adapter.
• Do not operate this device in an explosive atmosphere or
in the presence of conductive liquids.
Changing Hydraulic Oil
1. For best results, change hydraulic oil once a year.
2. Remove drain plug, tilt the pump then pour used fluid into
a sealable container.
3. Dispose the hydraulic oil in accordance with local
regulations.
4. Fill hydraulic oil, then reinstall vent cap.
Cleaning
Clean oil filter screen periodically with nonflammable solvent,
then blow dry before reassemble back to pump.
Storage
1. When not in use, depressurize and disconnect hydraulic
hoses from application.
2. Wipe clean, thoroughly.
3. Store in clean, dry environment. Avoid temperature
extremes.
4. For transportation or long term storage, shield pump with
a protective cover.
