BVA Hydraulics PE30H2S01A Instruction Manual page 12

Note: Not all components of the device are replacement items, but are illustrated as a convenient reference of location
and position in the assembly sequence.
BVA authorized repair parts only and ALWAYS provide model and serial number when ordering.
No. Part No.
E16-4-9000-106
1
E16-4-9300-108
2 E05-6-9002-107
3 N/A
4 N/A
5 649-1-0095-204
6 E05-6-9006-105
7 622-6-0318-203
8 E05-6-9007-107
9 E30-4-4000-105
10 511-7-0064-109
11 N/A
12 649-1-0063-403
13 E10-4-6030-108
14 E05-4-8000-207
15 E05-4-2001-108
*Repair requires special skills, knowledge, and equipment. Only an authorized service center may perform the repair
and/or replacement of these items. Contact BVA technical service for list of service centers.
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419
E-mail: sales@bvahydraulics.com
To ensure safe and reliable performance, replace worn or damaged parts with
Description
1.5 HP Motor, 120 V/60
HZ
1.5 HP Motor, 230 V/50
HZ
Gasket-Motor
Reservoir Cover
Upper Plate Assembly
Screw
Eccentric 5/8 Shaft
Bearing Needle
Sleeve Eccentric Bearing
Piston Block Assembly
O-Ring
Lower Plate Assembly
Screw
Gear Pump Assembly
High Flow Block-
Unloading Assy
PF Thread Plug, 3/8" PT
Electric Pump
Service Parts
MODELS: PE50H2S03A, PE50H2S05A
* Fax: 816-448-2142
Website: www.bvahydraulics.com
Model No. E1583
Qty.
1
1
1
1
1
4
1
15
1
1
2
2
1
4
1
14
1
1
Approved By:
Date: 2022.03.21
12
Checked By:
File name: E1583_2203EXP
1
2
3
4
5
6
7
8
10
9
10
11
12
13
Drawn By: Bill Ts
